December 2021© Kubota BX25 Deluxe ROPS Cab Installation Manual
Kubota BX25 Deluxe ROPS Cab
** Shown with optional equipment
Kubota BX25 Deluxe ROPS Cab
This ROPS cab is designed and built to fit the Kubota BX25.
Designed and Built by:
Tektite Manufacturing Inc:
427 Buffalo Street
P.O. Box 639
Winkler, MB
R6W 4A8
Canada
PH: 204-331-3463
Fax: 204-331-4159
sales@tektite.ca
www.tektite.ca
One year standard product warranty provided by Tektite.

Advertisement

loading
Need help?

Need help?

Do you have a question about the BX25 Deluxe ROPS Cab and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kubota BX25 Deluxe ROPS Cab

Summary of Contents for Kubota BX25 Deluxe ROPS Cab

  • Page 1 December 2021© Kubota BX25 Deluxe ROPS Cab Installation Manual Kubota BX25 Deluxe ROPS Cab ** Shown with optional equipment Kubota BX25 Deluxe ROPS Cab This ROPS cab is designed and built to fit the Kubota BX25. Designed and Built by: Tektite Manufacturing Inc: 427 Buffalo Street P.O.
  • Page 2 December 2021© Kubota BX25 Deluxe ROPS Cab Installation Manual DO NOT PROCEED FURTHER UNTIL YOU HAVE READ THE INFORMATION BELOW 1) Always wear personal protective equipment 2) A minimum of two people is necessary to safely install the cab 3) This ROPS cab is heavy. A lift assist device such as an overhead hoist or high lift forklift is required.
  • Page 3 December 2021© Kubota BX25 Deluxe ROPS Cab Installation Manual Tektite Manufacturing Incorporated thanks you for purchasing a Kubota BX25 ROPS cab! Tektite has worked very hard to design and build this ROPS product and we hope that it provides you with many years of ROPS protection.
  • Page 4 December 2021© Kubota BX25 Deluxe ROPS Cab Installation Manual Parts List Standard Cab: Description PTO Selector 90° Weather seal 8” PTO Engage 90° Weather seal 7 ½” Back Inner RH 90° Weather seal 4 ¾” Throttle 90° Weather seal 8 ¼”...

  • Page 5: Installation Instructions

    December 2021© Kubota BX25 Deluxe ROPS Cab Installation Manual Installation Instructions: 1. Take the under-seat upholstery and position it under the seat. Ensure there is adequate clearance for the seat and controls, and then glue into place. 2. Go to the left fender and take the 8” piece of 90° weather seal and slide it onto the edge of...
  • Page 6 December 2021© Kubota BX25 Deluxe ROPS Cab Installation Manual 3. Take the 7 ½” piece of 90° weather seal and slide it onto the edge of the PTO engage cover. 4. Go to the right fender and take the 4 ¾” piece of 90° weather seal and slide it onto the edge of the back inner slot that is open.
  • Page 7 December 2021© Kubota BX25 Deluxe ROPS Cab Installation Manual 8. Take the 4” piece of 180° weather seal and slide it the edge of the sheet metal at the diff lock pedal opening. Standard Cab Installation Instructions: 1. Disconnect rear flasher light harness and remove two-post ROPS from machine. Save fasteners to re-use later.
  • Page 8 December 2021© Kubota BX25 Deluxe ROPS Cab Installation Manual 4. Repeat steps 2 and 3 for the right front bracket. 5. Return to the cab to install lift brackets next. To remove the gas shock on the left cab door, slide a flat screwdriver underneath the small clip on the end cap that must be pulled UP order to pop the shock off of the ball stud.
  • Page 9 December 2021© Kubota BX25 Deluxe ROPS Cab Installation Manual 6. Using a chain or lift strap, connect the lift bolts to an over head hoist or forklift. 7. Un-bolt the cab from the front and rear shipping brackets and lift the cab off of the shipping pallet.
  • Page 10 December 2021© Kubota BX25 Deluxe ROPS Cab Installation Manual 9. Once all isolators are started, torque the isolator fasteners to 200 ft-lbs. The M12 rear nuts should be torqued to 98 ft-lbs. The front bracket M14 fasteners should be torqued to 130 ft- lbs.
  • Page 11 December 2021© Kubota BX25 Deluxe ROPS Cab Installation Manual 15. Take the cotter pin off of the pin located at the bottom of the 2-post ROPS that normally locks the rotated seat into position. Take the long pin to rear of the cab and install between the...
  • Page 12 December 2021© Kubota BX25 Deluxe ROPS Cab Installation Manual NOTE: the cab for the BX is designed to provide protection from the winter elements. The tractor air intake will draw air through the cab. If cab is used in the summer, remove all vinyl panels, side glass pieces, and doors to ensure engine receives enough fresh air.
  • Page 13 December 2021© Kubota BX25 Deluxe ROPS Cab Installation Manual 5. Route 3/8” ID hoses from bypass fittings through the floorboard and to the heater. Connect hoses to the fittings with provided HS-6 hose clamps.
  • Page 14 December 2021© Kubota BX25 Deluxe ROPS Cab Installation Manual 6. Re-fill tractor with engine coolant.
  • Page 15 December 2021© Kubota BX25 Deluxe ROPS Cab Installation Manual 7. Start engine, turn heater on and run engine to purge system of air. Run with radiator cap off and at higher throttle in order to get thermostat to open and cycle coolant into radiator system.
  • Page 16 December 2021© Kubota BX25 Deluxe ROPS Cab Installation Manual . Wrap the winter front around the shroud, ensure it is tight, and mark the holes for the opposite side retainers. . Drill 1/16” holes and fasten button snap backs to the plastic shroud.
  • Page 17 December 2021© Kubota BX25 Deluxe ROPS Cab Installation Manual . Re-install the shroud onto machine. NOTE: the cab for the BX is designed to provide protection from the winter elements. The tractor air intake draws air through the cab. If cab is used in the summer, remove all side windows and doors to ensure engine receives enough fresh air.
  • Page 18 June 2021© Kubota BX25 Deluxe ROPS Cab Operator Manual Kubota BX25 Deluxe Cab Please note: Shown with optional features. Kubota BX25 Cab This ROPS cab is designed and built to fit the Kubota BX25. Designed and Built by: Tektite Manufacturing Inc: 427 Buffalo Street P.O.
  • Page 19 June 2021© Kubota BX25 Deluxe ROPS Cab Operator Manual Tektite Manufacturing Incorporated thanks you for purchasing a Kubota BX25 ROPS cab! Tektite has worked very hard to design and build this ROPS product and we hope that it provides you with many years of ROPS protection.
  • Page 20 June 2021© Kubota BX25 Deluxe ROPS Cab Operator Manual Tektite Limited Warranty Tektite Manufacturing Inc. (“Tektite”) warrants to the original purchaser (the “Claimant”), that Tektite products will be free from defective materials or workmanship, under normal use and service, for a period of (1) full year from the original invoice date.

  • Page 21: Safety Precautions

    June 2021© Kubota BX25 Deluxe ROPS Cab Operator Manual Safety Precautions Safety First Read these instructions carefully. It is essential that you read the instructions and safety regulations before you attempt to assemble or use the features that are on this cab/ROPS.

  • Page 22: General Safety

    June 2021© Kubota BX25 Deluxe ROPS Cab Operator Manual General Safety 1. Never let an unqualified or untrained driver operate the tractor. 2. Keep a fire extinguisher, with ABC rating securely fastened in the ROPS. Maintain it and be familiar with its use.
  • Page 23 June 2021© Kubota BX25 Deluxe ROPS Cab Operator Manual Safe Operation on Rough Terrain 1. Drive the tractor slowly on hillsides and curves to eliminate the danger of tipping. Avoid slopes which are too steep for safe operation. Avoid sharp uphill turns.
  • Page 24 June 2021© Kubota BX25 Deluxe ROPS Cab Operator Manual 9. Use your turn signals, checking for traffic well in advance of turning. If the tractor is not equipped with turn signals and law requires them, install them prior to operating on or near public roads.
  • Page 25 June 2021© Kubota BX25 Deluxe ROPS Cab Operator Manual Operating Instructions Important The following section locates, identifies and briefly describes the functions of all cab controls. All operators should familiarize themselves with control location and function prior to operating the tractor. Failure to do so may result in unsafe operation of the tractor and possible injury or death to operators and bystanders.
  • Page 26 June 2021© Kubota BX25 Deluxe ROPS Cab Operator Manual 4. Rear Work Light Rocker Switch (optional) Low position: Off High position: On Note: indicator light activates when work light is on. 5. Wiper Washer Rocker Switch (optional) Low position: Off High position: On Note: indicator light activates when the front washer is on.
  • Page 27 June 2021© Kubota BX25 Deluxe ROPS Cab Operator Manual 1. Clear the operator platform of all tools. Tools left in or around the ROPS and tractor can cause operator interference which could lead to bodily injury and/or damage the machine.
  • Page 28 Index Service Part # File Name Description A00-0001 DLP-HANDLE Outside Push Button Handle A00-0002 LEFT-LATCH Suicide Door Left Latch A00-0013 TEKT-0009 5MM Bushing A00-0018 STEP-BOLT1-4X1-1-2 Step Bolt, 1/4" x 1 1/2", MB A00-0019 STEP-BOLT1-4X1 Step Bolt, 1/4" x 1", MB A00-0020 STEP-BOLT1-4X1-1-4 Step Bolt, 1/4"...
  • Page 29 Index Service Part # File Name Description A00-0001 DLP-HANDLE Outside Push Button Handle A00-0003 RIGHT-LATCH Suicide Door Right Latch A00-0013 TEKT-0009 5MM Bushing A00-0018 STEP-BOLT1-4X1-1-2 Step Bolt, 1/4" x 1 1/2", MB A00-0019 STEP-BOLT1-4X1 Step Bolt, 1/4" x 1", MB A00-0020 STEP-BOLT1-4X1-1-4 Step Bolt, 1/4"...
  • Page 30 Index Service Part # File Name Description A00-0013 TEKT-0009 5MM Bushing A00-0019 STEP-BOLT1-4X1 Step Bolt, 1/4" x 1", MB A00-0021 FLANGE-NUT-1-4 Flange Nut, 1/4", YD A00-0044 TEKT-ASM-002 Side Window Hinge Weldment A00-0045 TEKT-0004 Side Window Slider Bracket, 1" tube A00-0057 TEKT-0020MIR Side Window Latch, L60776 A00-0058...
  • Page 31 Index Service Part # File Name Description A00-0013 TEKT-0009 5MM Bushing A00-0019 STEP-BOLT1-4X1 Step Bolt, 1/4" x 1", MB A00-0021 FLANGE-NUT-1-4 Flange Nut, 1/4", YD A00-0045 TEKT-0004 Side Window Slider Bracket, 1" tube A00-0046 TEKT-ASM-002R Side Window Hinge Right A00-0056 TEKT-0020 Side Window Latch, L60775 A00-0058...

  • Page 32: Windshield Assembly

    Index Service Part # File Name Description A00-0013 TEKT-0009 5MM Bushing A00-0014 THICK-BUSHING 8MM Bushing A00-0019 STEP-BOLT1-4X1 Step Bolt, 1/4" x 1", MB A00-0020 STEP-BOLT1-4X1-1-4 Step Bolt, 1/4" x 1 1/4", MB A00-0021 FLANGE-NUT-1-4 Flange Nut, 1/4", YD A00-0033 315-080 Rear Wiper Shaft Grommet A00-0043 WWF-MOTOR...
  • Page 33 Index Service Part # File Name Description A00-0013 TEKT-0009 5MM Bushing A00-0014 TEKT-0092 Thick Bushing A00-0019 STEP-BOLT1-4X1 Step Bolt, 1/4" x 1", MB A00-0033 315-080 Rear Wiper Shaft Grommet A00-0043 WWF-MOTOR WWF Wiper Motor, 1" Shaft A00-0076 TEKT-0026 1/4" Panel Nut A00-0108 TEKT-ASM-037 WWF, Adjustable Radial Arm, 15"...
  • Page 34 Index Service Part # File Name Description A00-0024 BUSS-15600-08-11 Power Block/Ground A00-0055 TEKT-0019 Fir Tree Fastener A00-0065 TEKT-ASM-005 On-Off Switch w/Lens A00-0067 TEKT-ASM-007 Mom-Off-Mom Rocker Switch A00-0223 TEKT-ASM-013 Steel Top Switchplate w/Decal A00-0224 TEKT-0104 3" Plug, Steel Top Tektite Manufacturing Inc. 24157 Hwy 3, Box 639, Winkler MB, R6W 4A8, Canada Req'd: CNC:...
  • Page 35 Index Service Part # File Name Description KUBX25-ASM-005_SHIELD Cab Weldment A00-0021 FLANGE-NUT-1-4 Flange Nut, 1/4", YD A00-0023 FLANGE_BOLT_1-4X3-4 Flange Bolt, 1/4" x 3/4", YD A00-0059 FLANGE-NUT-5-16 Flange Nut, 5/16", YD A00-0061 TEKT-0021 Striker Mounting Plate A00-0084 TEKT-0070 Gas Shock A00-0085 TEKT-0069 Gas Shock Stud A00-0101...
  • Page 36 Index Service Part # File Name Description K05-0020 KUBX25-073 Wide Flap Seal, 3 sides, 14FT K05-0020 KUBX25-074 Wide Flap Seal, 3 sides, 14FT K05-0020 KUBX25-073R Wide Flap Seal, 3 sides, 14FT K05-0021 KUBX25-076 Hood Shield Rubber K05-0022 KUBX25-075 Front Seal Cab, Over Platform KUBX25-ASM-010 BX25 Cab 1,2,3...
