Premium Cab p/n: 1KB01PR
Standard Cab p/n: 1KB01ST
Fits Tractor Models: B2301 and B2601
While this cab kit was designed to fit on the vehicle(s) listed above, manufacturing tolerances and vehicle
assembly may affect cab fitment. It is the responsibility of the cab installer to check all vehicle pedals and
levers for full functionality and, as required, adjust the cab fitment to prevent any interference of the cab
components with the travel of pedals or levers.
Premium Cab Shown with Optional Front and Rear LED Work Lights
Available Options:
1. Front LED Work Lights (P/N: 9LEDW4)
2. Rear LED Work Lights (P/N: 9LEDW3)
3. Strobe Light (P/N: 9LEDS2)
4. Dome light (P/N 9LEDD14)
5. Heater (P/N: 9PH20S62)
6. Switch Panel (P/N: 9PSF1)
7. Side View Mirrors (P/N: 9PM5)
9. Rear View Mirror (P/N: 9PM3)
8. Rear Wiper (P/N: 9PWK85F)
Note: Front wiper (P/N: 9PWK110) is supplied with premium cab kit only.
Approximate Installation Time *
Experienced Dealer Technician – 3.5 Hours
Average Dealer Technician – 4.5 Hours
Do-It-Yourself – 5.5 Hours
(*=Not including accessories)
The contents of this envelope are the property of the owner. Leave with the owner when installation is complete.
Kubota B01
Approximate Product Specifications
Floorboard to Roof Height: 62 inches
Weight: 290 lbs. (
Cab Width: 41 inches
), 221 lbs. (
)
Premium
Standard
Rev. D, 07/12/2019
p/n: IM-1KB01PR
1 of 29

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the B01 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Kubota B01 Series

Summary of Contents for Kubota B01 Series

  • Page 1 1 of 29 Kubota B01 Premium Cab p/n: 1KB01PR Standard Cab p/n: 1KB01ST Fits Tractor Models: B2301 and B2601 While this cab kit was designed to fit on the vehicle(s) listed above, manufacturing tolerances and vehicle assembly may affect cab fitment. It is the responsibility of the cab installer to check all vehicle pedals and levers for full functionality and, as required, adjust the cab fitment to prevent any interference of the cab components with the travel of pedals or levers.

  • Page 2: Table Of Contents

    2 of 29 TABLE OF CONTENTS WARNINGS, TIPS, & REQUIRED TOOLS ............3 CAB INSTALLATION .................. 4-20 CAB FEATURES & OPERATION ............. 21-22 CARE AND MAINTENANCE ................. 22 SWITCHED POWER WIRING HARNESS SCHEMATIC ....... 23 SERVICE PARTS ..................24-27 OPTIONAL ACCESSORIES ................. 28 BOLT TORQUE SPECIFICATIONS ..............

  • Page 3: Warnings, Tips, & Required Tools

    3 of 29 WARNINGS, TIPS, & REQUIRED TOOLS Curtis cabs feature an assembly of parts designed for your vehicle which require adjustment and alignment of components to accommodate vehicle variations and provide proper weather protection. For accurate installation, proper operation, and years of satisfaction, please read and understand the installation and owner’s manual fully prior to installing the cab.

  • Page 4: Cab Installation

    4 of 29 CAB INSTALLATION STEP 1: (VEHICLE PREP) 1.1 Per figure 1.1, remove and discard the cup holder found on the top left fender. 1.2 Per figure 1.2, remove and discard the left and right fender handles. 1.3 Install the hardware listed below into the exposed handle mounting holes found on the vehicle’s left and right fender.
  • Page 5 5 of 29 CAB INSTALLATION STEP 1: (VEHICLE PREP cont’d.) 1.6 Per figure 1.6, remove and discard the middle piece discard this of hardware found on the fenders near the ROPS. If the discard this leave hardware vehicle includes the hardware closest to the seat, hardware installed remove and discard.
  • Page 6 6 of 29 CAB INSTALLATION STEP 1: (VEHICLE PREP cont’d.) remove tabs 1.8 Peel up both the right and left sides of the rubber mat. Using a utility knife, remove the (3) outer tabs on both sides of the mat for a total of (6) tabs. See fig 1.8. Re-install both sides of the mat in place.
  • Page 7 7 of 29 CAB INSTALLATION STEP 2: (SEAL KIT) 2.4” 1.3” 1.3” Seal Kit is included on Premium Cabs only. Note: the flattest side of the flex brush should face down for best fit and finish. Bristles to butt up against 5”...
  • Page 8 8 of 29 CAB INSTALLATION STEP 3: (FLOOROARD MOUNTS) 3.1 Using the hardware listed below, install the left and right floorboard mounts per fig. 3.1. Hardware Used 5/16-18 X 1 FHCS 5/16-18 Flange Nut Fig. 3.1 (left floorboard mount installation) STEP 4: (SIDEFRAMES/REAR LEGS) For Premium Cab only.
  • Page 9 9 of 29 CAB INSTALLATION STEP 4: (SIDEFRAMES/REAR LEGS cont’d.) 4.4 Using hardware listed below, bolt the left fender bracket to the left sideframe/rear leg. Making sure to fully tighten hardware down. See fig. 4.4. Repeat the process for the right fender bracket. Hardware Used 5/16-18 X 3/4 FHCS 5/16 Plastic Washer...
  • Page 10 10 of 29 CAB INSTALLATION STEP 6: (MOUNTING SIDEFRAMES) 6.1 With assistance, place the left sideframe on top of the left floorboard mount and the vehicle’s left fender. Fasten the sideframe to the floorboard mount and then the vehicle’s fender (requires longer hardware). Repeat step for the right sideframe.
  • Page 11 11 of 29 CAB INSTALLATION STEP 9: (SWITCH POWER WIRING heater switch location HARNESS) 9.1 Start by removing both engine side covers. 9.2 Per figure 9.2, remove the smallest dome plug from wire tie slots the lower right side of the cowl. Insert the switch end of the harness (see page 23) from the outside of the cowl remove dome wire harness...
  • Page 12 12 of 29 CAB INSTALLATION STEP 10: (WINDSHIELD SUPPORT) carriage bolts 10.1 Install windshield support, inserting the (2) carriage bolts thru the top flange and the (2) Flange Hex Screws and Plastic washers thru the bottom flange. See fig. 10.1. Hardware Used 5/16-18 X 1 Carriage Bolt 5/16-18 X 3/4 FHCS...
  • Page 13 13 of 29 CAB INSTALLATION STEP 12: (REAR PANEL HEADER) For Standard Cab only. If installing a premium cab, proceed to step 13 below. 12.1 Remove the (4) factory install 5/16-18 flange hex nuts from the bottom of the roof. Install the Rear Panel Header Assembly to the bottom side of the roof.
  • Page 14 14 of 29 CAB INSTALLATION STEP 14: (REMOVABLE REAR PANEL) For Premium Cab only. Pin / Receiver If installing a standard cab, proceed to step 15 below. 14.1 Before installing the rear panel, lift the pop-up roof by pressing up on the yellow lever on the quick release latches.
  • Page 15 15 of 29 CAB INSTALLATION STEP 17: (UNDERSEAT FILLER, rear PREMIUM CAB) seat belt slots For Premium Cab only. edge “A” left side If installing a standard cab, proceed to step 18 on the next page. 17.1 Move and tip the seat forward. Figures 17.1a and 17.1c thru 17.1e show the underseat filler.
  • Page 16 16 of 29 CAB INSTALLATION STEP 18: (UNDERSEAT FILLER, rear STANDARD CAB) seat belt slots For Standard Cab only. edge “A” left side If installing a premium cab, proceed to step 19 on the next page. 18.1 Move and tip the seat forward. Figures 18.1a and 18.1c thru 18.1e show the underseat filler.
  • Page 17 17 of 29 CAB INSTALLATION STEP 19: (WIPER KIT) wire tie slot A wiper is included on Premium Cabs only. 19.1 Install the front windshield wiper motor arm and blade per the installation instructions included with the wiper kit. 19.2 Apply the wire loom to the wiper harness. Remove (2) of the right side dome plugs, one on the windshield support and the other on the top flange of the cowl.
  • Page 18 18 of 29 CAB INSTALLATION STEP 20: (DOORS) 20.1 Start out by applying grease to the hinge pins, reinstall all (4) door hinge washers per fig. 20.1. Reinstall the doors into their respective hinge sleeves located on the sideframes. See fig. 20.2c. Note: Holding the door perpendicular to the sideframe will ease installation.
  • Page 19 19 of 29 CAB INSTALLATION STEP 21: (TURN SIGNAL LIGHTS) 21.1 Re-install turn signal lights to the cab’s fender brackets using the O.E.M. (original equipment manufacturer) hardware. See fig. 21.1. Reconnect the wiring. Fig. 21.1 (re-install turn signal lights - left fender) STEP 22: (ROPS WARNING DECAL) 22.1 Install ROPS warning decal on the left side of the right ROPS tube just below the previously installed...

  • Page 20: Cab Installation

    20 of 29 CAB INSTALLATION STEP 23: (FINISHING TOUCHES cont’d.) 23.2 Remove caution label from inside of windshield. See fig. 23.2. Installation of Premium Cab is complete. For Standard Cab only. 23.3 Install the hardware listed below into the exposed rivet nuts found on the back of the sideframes.

  • Page 21: Cab Features & Operation

    LIFT-OFF DOORS For added ventilation, the doors on the B01 series cab lift off in seconds without tools. To lift off: 1) Disconnect the gas shock from the side frame by depressing the orange activator.

  • Page 22: Care And Maintenance

    22 of 29 CAB FEATURES & OPERATION REMOVABLE REAR CURTAIN Included on Standard Cabs Only In order to use the backhoe on B2301 & B2601 model vehicles, some conversion of the cab is necessary. First, remove the rear curtain then raise the roof per the instructions on the previous page (pop-up roof section).

  • Page 23: Switched Power Wiring Harness Schematic

    23 of 29 SWITCHED POWER WIRING HARNESS (P/N: 9SV-WH-00004)

  • Page 24: Service Parts

    24 of 29 KUBOTA B01 PREMIUM CAB & STANDARD CAB COMMON PARTS (P/N 1KB01PR & 1KB01ST) ROOF ASSEMBLY WINDSHIELD ASSEMBLY WINDSHIELD SUPPORT ASSEMBLY P/N: 8SV-102-00009 P/N: 8SV-103-00005 P/N: 8SV-101-00005 SIDEFRAME ASSEMBLY, LEFT COWL ASSEMBLY SIDEFRAME ASSEMBLY, RIGHT P/N: 8SV-109-00005-L P/N: 8SV-109-00005-R...
  • Page 25 25 of 29 KUBOTA B01 PREMIUM CAB PARTS (P/N 1KB01PR) DOOR, PREMIUM, LEFT DOOR, PREMIUM, RIGHT SEAL KIT (P/N: 8SV-SLK-00001) P/N: 8SV-107-00008-R P/N: 8SV-107-00008-L REAR LEG ASSEMBLY, LEFT REAR LEG ASSEMBLY, RIGHT REAR PANEL ASSEMBLY P/N: 8SV-108-00003-L P/N: 8SV-108-00003-R P/N: 8SV-106-00008...
  • Page 26 26 of 29 KUBOTA B01 STANDARD CAB PARTS (P/N 1KB01ST) DOOR, STANDARD, LEFT DOOR, STANDARD, RIGHT REAR CURTAIN P/N: 8SV-107-00011-R P/N: 8SV-112-00011 P/N: 8SV-107-00011-L REAR PANEL HEADER ASSEMBLY, STANDARD P/N: 8SV-113-00018...
  • Page 27 27 of 29 ADDITIONAL SERVICE PARTS PART NUMBER DESCRIPTION 9SV-RFL ROOF LATCH KIT (INCL. L & R) 9SV-HRR1 ROOF HINGE KIT #1 (INCL.1 SET OF L & R W/SLEEVE) 9SV-SPL STRIKER PIN, 1" LONG (PAIR OF PINS, WASHERS & NUTS) 9SV-GH GRAB HANDLE KIT (SET OF 2) 9SV-DL-195...

  • Page 28: Optional Accessories

    28 of 29 OPTIONAL ACCESSORIES FOR PREMIUM AND STANDARD CABS FRONT LED WORK LIGHTS (P/N: 9LEDW4) REAR LED WORK LIGHTS (P/N: 9LEDW3) STROBE LIGHT (P/N: 9LEDS2) HEATER (P/N: 9PH20S62) DOME LIGHT (P/N: 9LEDD14) SWITCH PANEL (P/N: 9PSF1) SIDE VIEW MIRRORS (P/N: 9PM5) REAR VIEW MIRROR (P/N: 9PM3) PREMIUM CAB ONLY REAR WIPER KIT, 85 DEGREE SWEEP, 12V W/ 16"...

  • Page 29: Bolt Torque Specifications

    29 of 29 BOLT TORQUE BOLT TORQUE SPECIFICATIONS GENERAL TORQUE SPECIFICATION TABLE Use the following torques when special torques are not given. These values apply to fasteners as received from suppliers, dry, or when lubricated with normal engine oil. They do not apply if special graphited or moly disulphide greases or other extreme pressure lubricants are used.
