Mooreco CTDA1A1B D0 Series Assembly Instructions Manual

Advertisement

Quick Links

Product Name
Part Numbers: CTDA1A1BXXD0-XXXX-XXXX
INSTRUCCIONES DE
INSTRUCTIONS DE
ASSEMBLY INSTRUCTIONS
ENSEMBLAJE
MONTAGE
DO NOT THROW AWAY!
NO LA TIRE
NE PAS JETER
Revised: 6 Jan 2025
Page 1 of 8

Advertisement

loading
Need help?

Need help?

Do you have a question about the CTDA1A1B D0 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Mooreco CTDA1A1B D0 Series

  • Page 1 Product Name Part Numbers: CTDA1A1BXXD0-XXXX-XXXX INSTRUCCIONES DE INSTRUCTIONS DE ASSEMBLY INSTRUCTIONS ENSEMBLAJE MONTAGE DO NOT THROW AWAY! NO LA TIRE NE PAS JETER Revised: 6 Jan 2025 Page 1 of 8...
  • Page 2 Parts List Hardware P1 - Compass Cabinet Set A - #10 x 1” Wood Screws P2 - Teacher Desk Top 24” x 72” P3 - Modesty Panel P4 - Risers Revised: 6 Jan 2025 Page 2 of 8...
  • Page 3: Warranty

    WARNINGS AND DISCLAIMERS ADVERTENCIAS Y RENUNCIAS AVERTISSEMENTS Review full assembly instructions and Por favor leer las instrucciones previo a Avant de commencer l’ assamblage check that all parts are present before comenzar el proceso de ensamblaje o veuillez consulter instructions beginning assembly.
  • Page 4 PART No.: MATL: INFORMATION WHICH IS THE EXCLUSIVE PROPERTY DO NOT SCALE DRAWING DWG SIZE OF MOORECO. IT MAY NOT BE REPORDUCED, USED OR DISCLOSED WITHOUT SHEET 1 OF 1 WRITTEN PERMISSION OF SAID COMPANY Revised: 6 Jan 2025 Page 4 of 8...
  • Page 5 STEP 1 For both cabinets: Take out drawers if necessary. Remove casting retainer screws from positions shown inside cabinet. Set screws aside. Repeat for other side of cabinet. STEP 2 For both cabinets: Insert Risers into slots in mount castings. Replace screws removed in previous step being careful to raise Risers to equal heights when lining up screw holes.
  • Page 6 STEP 3 Flip Teacher Desk Top upside down and align Modesty Panel to pre-drilled holes in Top. STEP 4 Secure Modesty Panel to Teacher Desk Top with six (6) screws. Revised: 6 Jan 2025 Page 6 of 8...
  • Page 7 STEP 5 Flip Teacher Desk Top and Modesty Panel sub-assembly back over and align the pre-drilled holes to the risers of the Cabinets. The interior risers of each Cabinet should align directly to Cabinet-specific pairs of holes in the top while the exterior risers align with a single multi-purpose hole.
  • Page 8 SUPPORT HEIGHT ADDENDUM Use the distances below while setting Support Tubes in Step 2 to ensure correct transaction top height. Distances are provided for each of three cabinet height options and are measured from ground to top of Support Tube. H1: 27.75”...
