- Page 1 Compass MakerSpace Tables Part Numbers: 9169X-X-XXXX, 9169X-X-BUTCHER ASSEMBLY INSTRUCTIONS INSTRUCCIONES DE ENSEMBLAJE INSTRUCTIONS DE MONTAGE DO NOT THROW AWAY! NO LA TIRE NE PAS JETER 1 of 6 UPDATED AS OF: 07/21/2021...
- Page 2 Parts Hardware A - #10 x 1” Wood Screw (x18 - 48”) P1 - Table Top (size will vary) B - 1/4-20 x 3” Bolt P2 - Leg Bracket C - 1/4-20 Lock Nut P3 - Leg D - Locking Casters (length will vary) E - Non-Locking Casters P4 - Support Bracket...
-
Page 3: Warranty
WARNINGS AND DISCLAIMERS ADVERTENCIAS Y RENUNCIAS AVERTISSEMENTS Review full assembly instructions and Previo a comenzar el proceso de Avant de commencer l’ assamblage check that all parts are present before ensamblaje favor revisar veuillez consulter instructions beginning assembly. Heavy or large instrucciones y asegurarse que cuenta con complètes et vérifier si vous avez toutes furniture may require multiple persons in... - Page 4 Attach two Leg Parts (P3) to the Leg Bracket (P2) using bolts (B) and nuts (C). Repeat STEP 1 step for other bracket. Connect Leg Bracket (P2) to Support Bracket (P4) using bolts (B) and nuts (C). Repeat STEP 2 step for other leg.
- Page 5 STEP 3 Lay frame on top of underside of table. Use holes as guides for placement. Mount frame to table using screws (A). Each leg receives six screws. Number of STEP 4 Support Bracket screws will vary by model. 5 of 6 UPDATED AS OF: 07/21/2021...
- Page 6 STEP 5 Install casters (D,E) with lock washers (F) using the wrench to screww in caster stems. Locking casters should be installed on opposite ends of the table. With two or more people, flip table upright. STEP 6 THIS COMPLETES ASSEMBLY INSTRUCTION 6 of 6 UPDATED AS OF: 07/21/2021...
