System description and manual
V 1.0
D&R Electronica B.V. | Rijnkade 15b | 1382GS Wees | Netherlands
Phone: +31 (0)294-418014 | www:
http://www.dnrbroadcast.com
| E-Mail:
sales@d-r.nl

Advertisement

loading
Need help?

Need help?

Do you have a question about the AURON and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for D&R AURON

Summary of Contents for D&R AURON

  • Page 1 System description and manual V 1.0 D&R Electronica B.V. | Rijnkade 15b | 1382GS Wees | Netherlands Phone: +31 (0)294-418014 | www: http://www.dnrbroadcast.com | E-Mail: sales@d-r.nl...

  • Page 2: Table Of Contents

    We are confident that you will be using the AURON for many years to come, and wish you lots of success in your business. And… please take some time to read this manual first to avoid unnecessary questions to yourself...

  • Page 3: Table Of Contents

    ACKGROUND NFORMATION EATURES SYSTEM ARCHITECTURE VERVIEW ARDWARE RCHITECTURE 4.2.1 FDR units 4.2.2 MSTR UNIT (Auron Master Unit) OFTWARE RCHITECTURE 4.3.1 DNR Operating System (Linux) 4.3.2 Embedded Software (Firmware) 7’’ Display Web-based User Interface DESIGN 4.3.3 4.3.4 Desktop web-based User Interface DESIGN...
  • Page 4 7.7.13 CONSOLE-CONFIGURATION 7.7.14 SYSTEM-NETWORK 7.7.15 SYSTEM-LOG 7.7.16 SYSTEM - MISCELLANEOUS GPIO – GPIO 1-2-3-4 7.7.17 SPECIFICATIONS D&R AURON | USER MANUAL...

  • Page 5: Introduction

    The scope of this document will start to focus on the general design choices which are made during the design phase of the project in combination with the corresponding implementations in hard- and software. Only the current status of the AURON Broadcast mixer will be discussed, no future features. 2.2.1...

  • Page 6: Design Overview

    3 Design Overview 3.1 Background Information The AURON, offers a true analogue signal path with flexible digital control. The console uses a split unit topology, a Master Unit connects to one or multiple 10 FADER units. The AURON features a 7” HD touch display for metering and system control with K-ALPS or Motor faders and optional modules for DANTE AoIP, Dual Telco cards, USB Audio insert card and BT cards for wireless connection to phones.

  • Page 7: System Architecture

    4 System Architecture 4.1 Overview The AURON system consists of one MSTR UNIT (master section) and one or more FDR units (10 channel sections). For a minimal system a master and one 10 channel fader unit is needed. If more than 10 modules is desired, additional FDR units can be daisy chained in the system as can be seen below: In the image below, a minimal system comprising 10 faders and a master section is depicted.

  • Page 8: Hardware Architecture

    To control 10 channel boards, five Auron-4 control boards are required. Additionally, an Auron-5 base board and an Auron-6 power supply are necessary to provide power to all the internal PCBs. These PCBs are interconnected using one or more interfaces, which will be explained in greater detail later in this manual.
  • Page 9 D&R AURON | USER MANUAL...
  • Page 10 4.2.1.1 AURON-1 Channel Board Mic/Line The AURON-1 is an analog input channel board mainly used for connecting a microphone. On the PCB there are several digitally controlled analog switches (DCAS) which controls the analog audio path. Potentiometer controls: The potentiometers on the PCB have the following functions from top to bottom: GAIN, EQ-high, EQ-mid, EQ-low, AUX-send.
  • Page 11 The connector layout will be the same as the AURON-1 Channel Board Mic. The RJ45 will be a stereo- balanced input (compatible with AXUM patch panels). The XLR is a balanced mono input, GPO is off course available, and finally the CF/INS Jack has a to-be-determined function.
  • Page 12 4.2.1.4 AURON-4 Control Board 4.2.1.5 AURON-5 10-Fader Unit Base Board D&R AURON | USER MANUAL...

  • Page 13: Mstr Unit (Auron Master Unit)

    4.2.1.6 AURON-6 Power Supply 4.2.2 MSTR UNIT (Auron Master Unit) The Auron Master Unit consists of the following PCB’s: Auron-12 Master Left Auron-13 Master Right Auron-14 Master AES3 Auron-15 Master UI Auron-16 Master Engine The MASTER UNIT has a fixed configuration of the above-mentioned PCBs. The MSTR UNIT doesn’t have a separate PSU since it is implemented on the Master Engine PCB.
  • Page 14 CUE bus (balanced on RJ45) SUB bus (balanced on RJ45) AUX bus (balanced on RJ45) MASTER (balanced on RJ45) MASTER buss insert jacks for L and R MASTER Left output on XLR (can be PGM or NonStop source) D&R AURON | USER MANUAL...
  • Page 15 (Stereo Tools). 4.2.2.4 AURON-15 Master AES3 MASTER digital AES3 output (can be PGM or NonStop source) STUDIO bus insert jacks for L and R EXT input on cinch CRM bus output on cinch D&R AURON | USER MANUAL...
  • Page 16 Speaker Level potentiometer The encoders are used for hardware control and the application on a 7 inch display. This could be helpful when the touch is not working, of the user prefers encoder control above touch control. D&R AURON | USER MANUAL...

  • Page 17: Software Architecture

    4.3.2 Embedded Software (Firmware) The entire system contains of four different node types, auron-4, 5, 14, 16, each with a Microchip SAM E51 microcontroller on board. These controllers are interconnected by the CAN-FD bus. Each node has its own application code and they share a common bootloader which is used for updating firmware via CAN bus.
  • Page 18 4.3.2.3 Auron-address The Auron address process is responsible for providing a valid node ID. This node ID is stored in the internal EEPROM (non-volatile memory). To obtain a unique node ID , the node sends an identification message every second, this happens from the bootloader.

  • Page 19: 7'' Display Web-Based User Interface Design

    The Mic settings panel is shown with mic preamp gain settings (this is NOT the gain potentiometer above the channels!). Insert and phantom can be enabled/disabled by pressing the buttons. Yellow colour indicates active and grey is inactive (intuitive look and feel ). MODULE-SOURCE D&R AURON | USER MANUAL...
  • Page 20 Module source for a VoIP/USB module. All mic related settings are not present of course. D&R AURON | USER MANUAL...
  • Page 21 Fader and at last the mix busses routing for PGM, SUB, VT, PFL. Aux cannot be set, it is fixed routed via the aux potentiometer. Module path with EQ and DYN disabled. (Dynamics is not implemented yet) D&R AURON | USER MANUAL...
  • Page 22 Module GPIO settings for mic module. (has two additional GPIs via studio remote RJ45 connector). The GPO trigger can be configured to a Auron Function described in chapter 6.2. This can be a function of the Boolean data type. An example could be: Module 9: Phantom on/off. The GPO will now be triggered when phantom power is applied to module 9.
  • Page 23 Module clean feed settings for mic module are not available. Only VoIP/USB modules have clean feed. Module clean feed settings for VoIP/USB module. Send level can be set here Module clean feed settings for VoIP/USB module. Send level can be set here. D&R AURON | USER MANUAL...
  • Page 24 Module Console Module Console settings panel is used for assigning Auron Functions (chapter 6.2) to the UI buttons on FDR units. A button can have a function to control and an ON and OFF colour for the two states the function can have.
  • Page 25 Future Module Control settings with ON-state configured in slow blinking between red and off color. D&R AURON | USER MANUAL...
  • Page 26 On the channel boards there is a VCA located which can be used to do dynamics processing like gate, compressor, downward expander, and limiter. This functionality needs to be implemented in the Auron 4 control board module which controls the VCA in the channel board over interface I1 (analog voltage over 10 pin connector).
  • Page 27 Module Dynamics Compressor tab view. With additional Make-up gain parameter. Module Dynamics Limiter tab view. D&R AURON | USER MANUAL...
  • Page 28 Master source settings for Non Stop and Silence detection settings Master Insert switch D&R AURON | USER MANUAL...
  • Page 29 Master Output levels for CUE, SUB, AUX and Master MONITOR CRM SETTINGS D&R AURON | USER MANUAL...

  • Page 30: Studio Settings

    STUDIO SETTINGS CONSOLE CONTROL MODE FOR GENERAL SETTINGS D&R AURON | USER MANUAL...

  • Page 31: Console Configuration Settings

    CONSOLE CONFIGURATION SETTINGS SYSTEM NETWORK SETTINGS D&R AURON | USER MANUAL...
  • Page 32 AURON LOG FILES FOR RESEARCH AND DEBUGGING AURON SYSTEM SETTINGS D&R AURON | USER MANUAL...
  • Page 33 AURON GPIO ASSIGNMENTS FOR ON-AIR 1,2,3,4 | VT ACTIVE | NON STOP ACTIVE | VoIP active PULSE continuous | Pulse by ON | Pulse by OFF | Pulse by CHANGE D&R AURON | USER MANUAL...

  • Page 34: Desktop Web-Based User Interface Design

    With settings such as creating users, setting user rights etc. Desktop applications are more for advanced settings. The internal 7-inch display is for normal operation control of the mixing console. 4.4 Interface Architecture 4.4.1 FDR units 4.4.2 MSTR UNIT D&R AURON | USER MANUAL...

  • Page 35: Interface Detailed Design

    SL1_CF2 output Slot 1 Channel 2 Clean feed SUB_M input Mono SUB mix bus VT_M input Mono Voice Track mix bus Ground AUX_M input Mono AUX mix bus PFL_M input Mono PFL mix bus Ground D&R AURON | USER MANUAL...

  • Page 36: I12 - Mstr Unit Mixbus Interface

    : PGM, SUB, AUX, VT, PFL, TB1/2, NS, MASTER Mix bus Monos: PGM, SUB, AUX, VT, PFL Monitor bus : CRM Insert Send I14 – MSTR UNIT Display USB Interface 4.5.3 USB connection between 7” D&R AURON | USER MANUAL...

  • Page 37: External Hardware Interface Design

    Mix bus Voice Track Return Left VT_RET_R input Mix bus Voice Track Return Right TB1_RT input Mix bus Talkback 1 Return TB2_RT input Mix bus Talkback 2 Return PROG_MONO input Mono PROG mix bus SUB_MONO input Mono SUB mix bus D&R AURON | USER MANUAL...

  • Page 38: I8 - Shuttle Cable (From Extender) Interface

    Mix bus Aux Return Right Ground VT_RET_L output Mix bus Voice Track Return Left VT_RET_R output Mix bus Voice Track Return Right TB1_RT output Mix bus Talkback 1 Return TB2_RT output Mix bus Talkback 2 Return D&R AURON | USER MANUAL...
  • Page 39 Mono AUX mix bus VT_MONO output Mono Voice Track mix bus PFL_MONO output Mono PFL mix bus ~RESET output System reset line Ground CANH in/out CAN bus High line CANL in/out CAN bus Low line Ground D&R AURON | USER MANUAL...

  • Page 40: How To Use The Auron

    6 How to use the AURON As described in the above 39 design pages the AURON , we developed the Auron with the goal of delivering a console that offers both ultimate sound quality and the versatility of a software-controlled mixer.

  • Page 41: Connection Back Panel

    7 Connection back panel 7.1 AURON 10 CHANNEL UNIT 7.1.1 MIC INPUTS The MIC|LINE input connects microphones to the AURON. The AURON supports 48 volts DC phantom power if it is switched on in the software. Female XLR Function Comment +Audio Audio in phase –Audio...

  • Page 42: Rem/Bal Usb

    GP-In 7.1.5 INPUT CONNECTORS On the back of your AURON you will also find Two unbalanced line input RCA Cinch connectors (stereo input) for connecting CD players or any play-back devices such as cart machines, cassette players, or iPods.

  • Page 43: Slot-1 And Slot-2

    7.1.6 SLOT-1 AND SLOT-2 The Auron has 2 card slots on the back for extra in and output options. Slot-1 can accept - Telco (POTS) card. - BT card for wireless connection with your phone. - AES3 input card. (not yet available) - RIAA phono card.

  • Page 44: Master Backpanel

    7.2 MASTER BACKPANEL The AURON master has the following connectors to interface with your equipment. 7.2.1 MAIN BALANCED OUTPUTS MASTER LEFT / RIGHT and AES-3 OUTPUT Male XLR Function Comment + Audio Audio in phase – Audio Audio out phase...

  • Page 45: Master|Aux|Sub|Cue

    Photo MOS (TTL) relay nGP-In GPIO A=1 (max 50V, 200mA) (TTL) GP-Out GPIO A=2 Photo MOS (TTL) see chapter 7.1.4.1 relay nGP-In GPIO A=2 (max 50V, 200mA) (TTL) Audio ground and Shield reference for GP-In D&R AURON | USER MANUAL...
  • Page 46 A redundant power supply can be provided for by 2 external 12V 5A adapters connected to the master unit by 5 pin XLR connectors replacing the Mains Inlet. ALL RJ 45 connectors can be connected to Break out panels that are available in the following formats, see the next page. D&R AURON | USER MANUAL...

  • Page 47: 19" Patch Panels / Breakout Panels

    60881648, Line output XLR with 12 balanced Line out XLRs (male) and 12 remote jacks. 60881649, Line I/O XLR with 8 balanced Line in XLRs (female), 4 balanced Line out XLRs (male) and 12 remote jacks. 60881650, Dig I/O with 6 stereo digital inputs and 6 stereo digital outputs. D&R AURON | USER MANUAL...

  • Page 48: Mic/Line Channel Functions

    7.4 MIC/LINE CHANNEL FUNCTIONS There are at the moment 2 versions of Auron channels to choose from, the Mic/Line channel and the USB/VoIP channel. These pcb’s can be put anywhere in the 10 channel frame and in any sequence. For instance 1-8 Mic/Line channels and 2 USB/VoIP channel on 9/10.

  • Page 49: Oip Channel Functions

    7.5 USB/VoIP CHANNEL FUNCTIONS There are at the moment 2 versions of Auron channels to choose from, the Mic/Line channel and the VoIP channel. These pcb’s can be put anywhere in the 10 channel frame and in any sequence. For instance 1-8 Mic/Line channels and 2 VoIP channel on 9/10.

  • Page 50: Master Module Functions

    Here are all the input sources for the Control Room Monitor. STUDIO Here are all the input sources for the Studio Monitor. Below this section you see the level controls Phones and Monitor for both the CRM and Studio areas in your building. D&R AURON | USER MANUAL...

  • Page 51: Display Functions

    It shows the outputs of Main Master, Sub output and on 4 smaller meters CRM/STUDIO/AUX/PFL(CUE) A clock runs in the centre of this screen. There are buttons for Silence detection, ON-AIR and VoIP indicators. To enter the configuration display please touch “CONFIGURE AURON” . 7.7.1 MODULE-SOURCE This Display shows the audio routing of module 1.

  • Page 52: Line Settings

    This display shows the complete routing of the input module 1. The greyed out section are not active, you can click on the function blocks to activate the section you want. The AUX signal is always active and routed to its output op amps. D&R AURON | USER MANUAL...

  • Page 53: Module-Gpio

    Here you can select what action per channel and input (also from the card slots S1 and S2) will trigger the ON-AIR light when connected to one of the 4 GPO outputs on the console. D&R AURON | USER MANUAL...

  • Page 54: Module-Microphone

    STUDIO This functionality is not available for a USB/VoIP module. You can also send the mic signal to one of the 8 Dante inputs in Slot 2 (if you have chosen for the Dante option) D&R AURON | USER MANUAL...

  • Page 55: Module-Cleanfeed

    The AUTODIM function reduces the level of the caller when the DJ speaks. Here you select for which bus this works. You can also send the Cleanfeed signal to one of the 8 Dante inputs in Slot 2 (if you have chosen for the Dante option) D&R AURON | USER MANUAL...

  • Page 56: Module-Console

    10dB extra fader gain moving the 0dB position 10dB lower on the front panel. AUTOMATIC ACTIVATION AUTO ON The module is automatically set to ON status when the fader is above -120dB. AUTO OFF The module is automatically set to OFF status when the fader is below -120dB. D&R AURON | USER MANUAL...

  • Page 57: Master-Sources

    7.7.7 MASTER-SOURCES This display shows all the settings for the master section of the AURON MASTER SOURCE Here you select which signal goes to the main program outputs. It is the normal Program output or the NON STOP signal NON STOP SOURCE The source of the NON STOP signal can be selected in the drop down menu.

  • Page 58: Master-Path

    Here you can select the final output levels of the CUE | SUB | AUX | MASTER program signal. MUTE ALL OUTPUTS All outputs can be muted (yellow) Here you select the digital sample frequency the be 48kHz or 96kHz . D&R AURON | USER MANUAL...

  • Page 59: Master-Crm

    If you talk to the 2 Talk Back busses you can select to have the Program output dimmed on these busses. TALK BACK TO PHONES If you talk to the 2 Talk Back busses you can select to have the Program output dimmed on these busses. D&R AURON | USER MANUAL...

  • Page 60: Master-Studio

    If you talk to the 2 Talk Back busses you can select to have the Program output dimmed on these busses. TALK BACK TO PHONES If you talk to the 2 Talk Back busses you can select to have the Program output dimmed on these busses. D&R AURON | USER MANUAL...

  • Page 61: Console-Mode

    7.7.12 CONSOLE-MODE This CONSOLE CONTROL MODE display gives you the possibility to switch above settings for all the input modules in one fast action. These settings will overrule all individual settings. D&R AURON | USER MANUAL...

  • Page 62: Console-Configuration

    When the rotary encoder is turned past the last item, it starts over (enabled) or hang at the end (disabled, which is the default setting now. MENU TIME OUT When the encoder button is pressed on the module, how long does it take before the menu closes itself in milliseconds (0 = never, default). D&R AURON | USER MANUAL...

  • Page 63: System-Network

    In this SYSTEM NETWORK display you can enter all the basic info for proper network functioning. 7.7.15 SYSTEM-LOG This SYSTEM LOG display will show saved log files important for debugging and knowing what happened in case there was a problem. D&R AURON | USER MANUAL...

  • Page 64: System - Miscellaneous

    Here you refresh the display, restart your software and power down the systems software. CALIBRATE This display is not for users but for the software engineers, Whenever clicking on any item it will switch to SYSTEM-MISC, in production consoles it will be removed. D&R AURON | USER MANUAL...

  • Page 65: Gpio - Gpio

    • You can enter the Pulse time between 0 and 255 mSec This concludes all the settings in the display of the AURON to make the console work as you would like to see it working. D&R AURON | USER MANUAL...

  • Page 66: Specifications

    : 36VA per section. Emberplus via Ethernet Interface. OPTIONS 10 channel Fader extenders Motorfaders AES-3 Program outputs Dante card BT card Telco card (POTS) Several Break out panels to convert RJ11 connections into XLR’s and/or Jacks. D&R AURON | USER MANUAL...

  • Page 67: Channel Section

    Space below front panel: 20mm for table top. Weight: 3 kg. For Drop through mounting cut a hole of W 205 x F/B 385 mm (console height at the backside is 116mm, frontside 70mm). Shipping dimensions carton : 48x34x26cm D&R AURON | USER MANUAL...
  • Page 68 : EMC-Directive 89 / 336 / EEC. as amended by Directive 93/68/EEC The product is tested in a normal user environment. Signed for and on behalf of: D&R Electronica BV Weesp, 1-1-2024 Duco de Rijk, CEO Place and date of issue Name, function, signature D&R AURON | USER MANUAL...

  • Page 69: Service Information

    9 SERVICE INFORMATION D&R AURON | USER MANUAL...
  • Page 70 Below you see the part numbers of the used parts for service. D&R AURON | USER MANUAL...
  • Page 71 D&R AURON | USER MANUAL...
  • Page 72 D&R AURON | USER MANUAL...
  • Page 73 D&R Electronica BV | Rijnkade 15b | 1382 GS | Weesp | Netherlands +31 (0)294 418 014 | www.dnrbroadcast.com | sales@d-r.nl D&R AURON | USER MANUAL...
