D&R Airlab-DT Quick Start Manual

Before you begin:
•
Download the user manual:
Visit www.dnrbroadcast.com, click the Support button on the homepage, and select Brochures /
Manuals / software. Download the Airlab-DT user manual and read it at least once.
•
Safety reminder:
Turn OFF both the Airlab-DT and other equipment before connecting them to avoid grounding
issues that may damage input circuits.
Power up the equipment in the following order:
1. Turn ON the Airlab-DT
2. Turn ON the connected equipment.
•
Maintenance tips:
o
Clean the front panel periodically.
o
Avoid smoking, eating, or drinking near the console.
What's in the box:
•
1x Airlab-DT console
•
Chip card (for saving user presets)
•
USB cable
•
RS232 to USB cable
•
Power cable
•
Printed quick start manual
Before you begin:
•
Ensure mains voltage (90–240V AC) matches power input range.
•
Do not turn the console off/on within 10 seconds to avoid internal power issues.
•
Always ground your console via the back-panel connector.
Basic connections:
1. RS232 to USB → Connect to your PC for programming.
2. USB Cable → Connect for meter display and audio control.
3. Power Cable → Connect to grounded outlet. Power on from rear panel.
AIRLAB-DT
QUICK START MANUAL
Version: 2025-04-07
