PRODUCT MANUAL
Combo E Series
1
Connector installation
Example (NCJ6FE-V) of Delivery.
Equipment /
Panel
B
2x Screws
C
BDA 724
3 pole XLR female receptacle with
1/4" stereo jack
Panel thickness:
Panel thickness recommendation is based only
on metal panels and may differ for other
materials.
Step 1:
A
A
Insert the receptacle from the back into the
panel.
B
Position the screw and fasten it.
(Recommended screw look at Point 2. B)
1 - 3 mm [0.04 - 0.12"]
Assembly
C
AT T E N T I O N :
Tightening torque M = 40 - 60 Ncm
POZIDRIV® #1
A
ð
Page 1
