PRODUCT MANUAL
powerCON TRUE1
1
APPLICATION & SAFETY INSTRUCTION
P
IP 65 & IP 67 RATED
APPLICATION:
The powerCON TRUE1 system is certified as appliance couplers with breaking capacity according to
®
·
IEC 60320-1, EN IEC 60320-1, UL 60320-1, CSA C22.2 No. 60320-1.
It serves to supply power to an appliance and from an appliance to other equipment.
·
To be installed by qualified person only.
·
Appliance couplers acc. to IEC 60320-1 are suitable to be used in cord sets and interconnection cord
·
sets acc. to IEC 60799
POWER IN
APPLIANCE INLET
NAC3MPX-TOP
NAC3MPX-WOT-TOP
NAC3MPX-TRUE1
CONNECTOR
NAC3F-TRUE1-S
NAC3F-TRUE1-L
Products are in
compliance with:
Ratings:
Conductor cross section:
CABLE LIST
CABLE LIST
Approved cables:
H07RN-F
H05VV-F
Approved cables:
SOOW
SJOOW
BDA 705 V5
®
®
POWER OUT
APPLIANCE OUTLET
NAC3FPX-TOP
NAC3FPX-WOT-TOP
NAC3FPX-ST-TOP
NAC3FPX-TRUE1
PLUG CONNECTOR
NAC3M-TRUE1-S
NAC3M-TRUE1-L
IEC 60320-1
EN IEC 60320-1
16A 250V AC
2
1.5 - 2.5 mm
2
3 x 1.5 mm
-S
-S
|
NAC3M-TRUE1-S
®
NAC3M-TRUE1-L
POWER IN / POWER OUT
Combination
u
APPLIANCE INLET / APPLIANCE OUTLET
NAC3PX-TOP
NAC3PX-TRUE1
CONNECTOR
NAC3F-TRUE1-S
NAC3F-TRUE1-L
UL 60320-1
CSA C22.2 No. 60320-1
20A 250V AC
14 - 12 AWG
2
3 x 2.5 mm
L -
-S
14/3 AWG
PLUG CONNECTOR
NAC3M-TRUE1-S
NAC3M-TRUE1-L
12/3 AWG
-L
-L
-S
-L
ð
