OPERATING & ASSEMBLY INSTRUCTION
powerCON
A. OPERATING INSTRUCTION
IMPORTANT SAFETY INSTRUCTION:
The powerCON system is certified as connector without breaking capacity according IEC 61984 / VDE 0627.
In this standard the term connector (without breaking capacity) refers to components which in normal use are not to
be engaged or disengaged when under load or live.
Connector Combination & Keyways:
With the two non-interchangeable types of connectors (A type and B type) it is impossible to produce a short circuit.
Mating connectors (combination) are identified by mechanical keyways and by color.
A type (color coding blue)
POWER IN
B. ASSEMBLY INSTRUCTION
A
1.
B
C
POZIDRIV® #1
Torque Value 0.5 Nm
BDA 452
®
L I E
C H
T E
N S
T E
I N
NAC3MPA-1
NAC3FCA
2.
b
or
20 mm
[0.787"]
8 mm
[0.32"]
PE 23 mm
[0.9"]
WIRING
N
Locking 3 pole Power Connector
B type (color coding gray)
POWER OUT
A
Place the bushing (1) and the chuck (2) over
the cable.
White chuck (a):
Black chuck (b):
a
B
Prepare the cable as shown.
Cable O.D.: 6.0 - 15.0 mm
Wire size:
C
Insert the wire into the terminals and fasten
the clamping device with a POZIDRIV® #1,
L
max. Torque 0.5 Nm (0.37 lb-ft).
L I E
C H
T E
N S
T E
I N
NAC3FCB
6.0 - 11.0 mm
[0.236 - 0.433"]
9.5 - 15.0 mm
[0.374 - 0.59"]
VDE: 9.5 - 14.0 mm
[0.374 - 0.551"]
[0.236 - 0.59"]
2
2.5 mm
(AWG 14)
NAC3MPB-1
ð
