GB
Instructions for use, mounting and connection
Glass ceramic cooking hob

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 430C and is the answer not in the manual?

Questions and answers

Summary of Contents for Gorenje 430C

  • Page 1 Instructions for use, mounting and connection Glass ceramic cooking hob...
  • Page 2: Table Of Contents

    Glass ceramic cooking hob Dear customer The glass ceramic cooking hob is used for households. Our products are packed with environment-friendly and harmless materials that can be recycled, disposed and destroyed. That’s why the packagings are suitably marked. When the appliance is no longer used, try not to laden the environment.
  • Page 3: Important Warnings

    Important warnings • The appliance can be built in and plugged in onto the electricity grid by a professional only. • Some parts of the appliance heat up during operation (the area around cooking zones). • Make sure that children don’t get immediately close to the appliance and are timely warned against the danger of getting burned.
  • Page 4: Glass Ceramic Cooking Hob

    Glass ceramic cooking hob 1 - Front right cooking zone 2 - Back cooking zone 3 - Front cooking zone- duo zone 4 - Control panel Control panel А - lock functions sensor (key) N - symbol for cooking zone activation В...
  • Page 5 There are four cooking zones in the glass ceramic cooking hob. • The cooking hob surface is fl at with no edges to collect dirt. • The cooking zone quickly reaches certain temperature heating, but surroundings remains cold. • The cooking zone is resistant to temperature changes. •...
  • Page 6: Tips On Energy Saving

    Tips on energy saving • While shopping, make sure the diameter of pots is marked on their upper part, i.e cover, which is usually larger than the diameter of the base. • Pressure cookers, using higher pressure in an impermeable internal area, are even more economic in terms of time and energy.
  • Page 7: Managing The Cooking Zone

    Managing the cooking zone Sensor calibration During sensor adjustment/calibration in surrounding conditions: • Place no objects on its surface or the appliance will go into error regime. • The surface of the appliance sensors always has to be clean • Don’t expose the appliance to strong lightning, like halogen bulbs or bright sunbeams, etc.
  • Page 8 • With repeated pressing on the sensor “-“ (within 8 seconds), select the required preheating time and after the expiry of this time interval, select the power level (See table). • If you don’t activate stove preheating, level 9 remains adjusted and the preheating function will automatically deactivate.
  • Page 9: Switching Off The Cooking Zone

    Switching off the • Activate the appropriate cooking zone cooking zone • By simultaneously pressing both sensors D (+) and C (-), the cooking zone switches off or by pressing C (-) sensor, subsequently turn the power level to “0”. •...
  • Page 10: Minute Counter

    • In case of an attempt to turn the cooking hob on, the displays turno on showing symbol L. Dectivating - turning of • Switch on the cook hob by pressing sensor “B” the child safety lock • The symbol L appears on the display. •...
  • Page 11 • Within 8 seconds, set the operating time of the cooking zone • After expiry of the time interval set, a beep sound is heard, which you may turn off by pressing any sensor. • To change the setting, press the sensor »P« and the symbol »R«...
  • Page 12: Care And Maintenance Of Glass Ceramic Cooking Hob

    Care and maintenance of glass ceramic cooking hob Cooled off glass ceramic cooking hob has to be cleaned after each use, because even small amount of dirt will catch fi re on heated zone during the next use. Use special cleaners with protective anti-dirt fi...
  • Page 13: Cooking Hob Installation

    Cooking hob installation Important • The appliance may be installed into a kitchen element and connected to the power grid only by a professional. • Veneers or lining of kitchen furniture element should be processed with heat-resistant adhesives (100), otherwise they may change the color and form due to inadequate temperature resistance. •...
  • Page 14: Installation Procedure

    • The back side ofthe furniture element must have an opening with a minimum height of 100 mm along the element’s width. • A minimum opening on the front side must be provided. Installation procedure • The worktop must be placed completely fl at •...
  • Page 15: Connecting The Cooking Hob To The Electric Grid

    Connecting the cooking hob to the electric grid • Connections may be carried out only by a qualifi ed technician. The protection of the electric installation must comply with the applicable regulations and standards. • Connection clutches are available when the lid of connecting portion is opened.
  • Page 16: Connection Scheme

    Connection scheme: • Incorrect connection may destroy parts of the appliance and in such cases the right to warranty is lost! • Before connecting the appliance, make sure the voltage on the rating plate is equal to the current voltage of your power grid. The connection voltage of the appliance (230 V against N) must be checked by an authorized person with voltage meter.
  • Page 17: Technical Data

    Technical data Type 430C 430B ECT330BC ECT300BC ECT331CSC Electrical socket AC 230 V Operation voltage 230 V, 50 Hz Types of sockets Eletronic sensors - – TOUCH CONTROL Cooking zones (ø mm/kW) HL = HI-easy heating Front 180/120/1,7/HL 180/1,8/HL Back...
  • Page 20 en (06-17)
