Gorenje ora-ito Instructions For Use Manual

Glass-ceramic built-in coking hob
Hide thumbs Also See for ora-ito:

Advertisement

Table of Contents

See also: Instructions for Use, Installation, and Connection
Instructions for use, installation,
MT
IE
GB
and connection
Glass-ceramic built-in coking hob

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ora-ito and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Gorenje ora-ito

Summary of Contents for Gorenje ora-ito

  • Page 1 Instructions for use, installation, and connection Glass-ceramic built-in coking hob...

  • Page 2: Table Of Contents

    Glass-ceramic built-in cooking hob Dear customer! Glass-ceramic hob is intended for use in households. Our products are packed in environment-friendly materials which can be recycled, disposed of, or destroyed without imposing any burden on the environment. Instructions for use Instructions for use Instructions for use are intended for the user.

  • Page 3: Important Warnings

    Important warnings • Installation of the appliance into a kitchen worktop and its connection to the power mains and the gas supply may only be performed by an adequately qualifi ed technician. • Do not leave small children unattended when the appliance is in operation. Risk of burning and scalding! •...

  • Page 4: Appliance Description

    Appliance description 1. Cooking zone rear left 2. Cooking zone front left 3. Cooking hob control unit 4. Cooking zone front right 5. Cooking zone rear right Cooking hob control elements (depending on the model) Control sensor keys: A Coking hob on/off sensor F Power level / residual heat displays B Child lock sensor F1 Active function decimal point...

  • Page 5: Cooking Zones

    Cooking zones Before using the Before using the Clean the glass-ceramic surface with a damp cloth and appliance for the fi rst appliance for the fi rst some manual dishwashing detergent. Do not use aggressive time time detergents such as abrasive cleaners that can scratch the surface, abrasive dishwashing sponges, or stain removers.

  • Page 6: Energy Saving

    Cookware Cookware Tips on using the cookware Use high-quality cookware with a fl at and stable bottom. • Transmission of heat is best when the pan bottom and the cooking zone are of the same diameter, and the pan is placed on the middle of the cooking zone.

  • Page 7: Operating The Cooking Zones

    Operating the cooking zones • The cooking hob is fi tted with electronic sensor keys which are activated, respectively, when the indicated surface of a particular sensor is touched with a fi nger for at least one second. • Activation of a sensor key is confi rmed by a beep. •...

  • Page 8: Activating The Child Lock

    Turning off the cooking Turning off the cooking • Select the cooking zone by pressing the relevant sensor key zones zones (H). The decimal point (F1) next to the display for the selected cooking zone will light up. • Press the “–” (I) sensor key to set the power level to “0”. •...
  • Page 9 hot. Be careful, as there is a risk of burning. If a power failure has occurred when the cooking zones were hot, the indicator “H” or “h” will fl ash. This is to warn you that the cooking zone may still be hot, but not necessarily, depending on how long the power supply was out of order.

  • Page 10: Operation Time Limit

    Dish/cooking mode quantity power level cooking duration (min) Soup/reheating 0,5 – 1 lit A7 - 8 4 - 7 milk/reheating 0,2 – 0,4 lit A1 - 2 4 - 7 125 – 250 g rice/simmering approx. 300ml - 600ml A2 - 3 20 - 25 water 750g –...
  • Page 11 Power level Maximum operation time in hours Temporary cooking Temporary cooking The STOP & GO function enables you to temporarily suspend, or progress suspension progress suspension pause the cooking progress (urgent other tasks), while keeping - STOP & GO - STOP & GO all the settings.
  • Page 12 B Timer with the option to turn off the cooking zone The switch-off timer facilitates the cooking process by allowing you to set the cooking time for a particular cooking zone. In order to set the switch-off timer, the power level must already have been set (see section “Turning on the cooking zones”).
  • Page 13 To deactivate the timer before the set time has elapsed: • Select the desired timer display (see section Changing the timer setting) – the set time and the corresponding dot that indicates the cooking fi eld will fl ash. • Press the “–” (I) sensor key to set the value to “00”, or press the “+”...

  • Page 14: Cleaning And Maintenance

    Cleaning and maintenance Cleaning After each use of the glass-ceramic hob, wait for it to cool down and clean it; otherwise, even the smallest food residue will be burnt onto the hot surface next time you use the appliance. For regular cleaning and maintenance of the glass-ceramic surface, use special conditioning agents which form a protective layer on the surface, shielding it from dirt.

  • Page 15: Installation

    Installation Important warnings • Installation of the appliance into a kitchen worktop and its connection to the power mains may only be performed by an adequately qualifi ed technician. • Veneer or other fi nish of the piece of kitchen furniture into which the hob is to be built in should be treated with heat resistant glue (100°C);...

  • Page 16: Worktop Cutout

    Worktop cutout dimensions • Cooking hobs can be installed into worktops that are 30 to 50 mm thick. • The kitchen furniture element underneath the hob should not be fi tted with a drawer. If the kitchen furniture element as a horizontal partition wall, it should be installed no less than 60 millimeters from the lower surface of the worktop.

  • Page 17: Connecting The Appliance To The Power Mains

    Connecting the appliance to the power mains Important warnings • The appliance may only be connected by an authorized skilled technician. • Electric system protection should comply with all relevant regulations. • The connection clips can be accessed when the connection clip covers are opened / removed. •...
  • Page 18 Connection diagram Connection diagram • Incorrect connection may destroy parts of the appliance, making the warranty void. • Before connecting the appliance, make sure the voltage indicated on the rating plate is consistent with the voltage in your home network. Connection voltage (230 V through N) should be checked by a qualifi...

  • Page 19: Technical Characteristics

    Technical characteristics Rating plate A Serial number B Code C Model D Type E Trademark F Technical information G Compliance indications / symbols WE RESERVE THE RIGHT TO MAKE ANY CHANGES THAT DO NOT AFFECT THE FUNCTIONALITY OF THE APPLIANCE.
  • Page 20 SVK_ORAITO 243910/en (03-10)
