- Page 1 AIR CURTAIN INSTRUCTION MANUAL The cautions and instructions in this manual cannot cover all possible conditions or situations that could occur. SAVE THESE INSTRUCTIONS...
-
Page 2: Table Of Contents
Contents PRODUCT INTRODUCTIONS ..............- 2 - INSTALLATION PLANNING & CAUTIONS ..........- 2 - MOUNTING INSTRUCTIONS ..............- 4 - OPERATING INSTRUCTIONS ..............- 5 - LIMIT SWITCHES ................... - 6 - CONNECTION DIAGRAM ..............- 8 - MAINTENANCE AND CLEANING ............- 8 - TECHNICAL PARAMETERS .............. -
Page 3: Product Introductions
1. PRODUCT INTRODUCTIONS Air curtains can effectively block the convection of indoor and outdoor air. They can reduce penetration outside dust, insects, unconditioned air to improve indoor air quality and maintian indoor temperate. Air curtains can be commercial and is widely used in shopping malls, supermarkets, theaters, restaurants, warehouses, shops, bakeries, kitchens, home living rooms etc. - Page 4 DO NOT use the unit where Unauthorized modification may there is a risk of fire or an impair the function or affect the explosion life of the profuct. - 3 -...
-
Page 5: Mounting Instructions
3. MOUNTING INSTRUCTIONS Installation on the concrete wall: Step 1: Please ensure that the Step 2: Unpack the machine and machine is at least 10 cm from check any damage. the roof. TZ-6003 TZ-8108 Brackets Step 3: Unscrew the fixing screws Step 4: Determine the installation and take off the mounting plate position with the mounting plate. -
Page 6: Operating Instructions
B. Other installation methods Installation on the wooden wall Installation on the steel framwork Refer to Step 1 and determine the Refer to Step 1 and determine the installation position with installation position with mounting plate. Secure the wood mounting plate. Secure the bolts in screws in place. -
Page 7: Limit Switches
5. LIMIT SWITCHES Each air curtain is equipped with two types of limit switches, TZ-6003 and TZ8108, to allow the air curtain to run at selected speed when the door is open and be inactive when the door is closed. DETAILS FOR LIMIT SWITCHES TZ-6003 TZ-8108... -
Page 8: Connection Diagram
CONNECTION DIAGRAM TZ-6003 TZ-8108 Note: We have connected TZ-6003 to each air curtain for curtomers. Customers choose the type of switch according to the actual situation of the door. If the customer needs to use TZ-8108, cut the TZ-6003 off and then connect the wires to the TZ-8108. -
Page 9: Maintenance And Cleaning
TZ-6003 Step 1: Mount the TZ-8108 limit switch on the wall beside the A sliding door frame. door ended Step 2: Use the in the side brackets (included) to assist in opening the switch. 6. CONNECTION DIAGRAM Two-speed model Three-speed model 7. - Page 10 Medium speed Low speed Voltage Frequency Model Input Power Input Power Input Power (Hz) (���� /������) (ft/min) (���� /������) (ft/min) (���� /������) (ft/min) 1506001V1 1007 2165 1968 1509001V1 1511 2165 1372 1968 15010001V1 1666 2165 1490 1968 15012001V1 2014 2165 1831...
