- Page 1 LoRa Node Controller LN Series LoRa Node Controller LN1130, LN1140 and LN502 - 1 -...
-
Page 2: Fcc Compliance Statement
PLANET. PLANET assumes no responsibility for any inaccuracies that may be contained in this User’s Manual. PLANET makes no commitment to update or keep current the information in this User’s Manual, and reserves the right to make improvements and/or changes to this User’s Manual at any time without notice. -
Page 3: Ce Mark Warning
WEEE separately. Trademarks The PLANET logo is a trademark of PLANET Technology. This documentation may refer to numerous hardware and software products by their trade names. In most, if not all cases, these designations are claimed as trademarks or registered trademarks by their respective companies. -
Page 4: Table Of Contents
LoRa Node Controller LN Series Table of Contents Chapter 1. Product Introduction ..................... 5 Package Contents ...................... 5 Overview ........................6 Features ........................10 Product Specifications ..................... 11 Chapter 2. Hardware Introduction ..................15 Physical Descriptions ....................15 Hardware Installation ....................18 2.2.1 LoRa Antenna Installation .............. -
Page 5: Chapter 1. Product Introduction
LoRa Node Controller LN Series Chapter 1. Product Introduction Thank you for purchasing PLANET LoRa Node Controller, LN series. The descriptions of these models are as follows: LN1130 Industrial IP30 LoRa Node Controller (Modbus RS232, RS485G) LN1140 Industrial IP30 LoRa Node Controller (2 DI, 2 DO) -
Page 6: Overview
1.2 Overview Build a Smart IoT Environment with PLANET Industrial LoRa Node Controllers PLANET LN1130, LN1140, and LN502 Industrial LoRa Node Controllers offer cutting-edge solutions for efficient data acquisition and scalable IoT deployment across diverse applications. LN1130 and LN1140: Tailored for flexible and reliable LoRaWAN network deployments, these devices simplify data collection and device management. - Page 7 LN Series LoRaWAN-based Controller with Rich Industrial Interfaces PLANET Industrial LoRa Node Controllers, including the LN1130, LN1140, and LN502, are designed to connect various sensors, meters, and appliances while enabling seamless integration of legacy systems into IoT environments. These controllers bridge Modbus data between serial and Ethernet networks via LoRaWAN and are fully compatible with standard LoRaWAN gateways, including PLANET’s LCG-300 series.
- Page 8 RU864 (864 to 870 MHz) in Russia Easy Installation in Limited Space The compact-sized LN1130/LN1140 is specially designed to be installed in a narrow environment, such as wall enclosure. It can be installed by fixed wall mounting or DIN rail, thereby making its usability more flexible and easier in any space-limited location.
- Page 9 The integration of PLANET Industrial LoRa Node Controllers into the NMS-AIoT platform enhances the system’s capabilities by enabling seamless connectivity via LoRa, HaLow, wireless, and wired options. This allows PLANET LoRa Node Controllers to contribute to real- time data collection and AI-driven insights for applications in smart cities, agriculture, and industrial environments, strengthening the platform's overall ecosystem.
-
Page 10: Features
LoRa Node Controller LN Series 1.3 Features Key Features LN1130 One RS232 serial interface and one RS485 serial interface Compliant with standard LoRaWAN gateways and network servers. Ultra-wide-distance transmission up to 10km with line of sight ... -
Page 11: Product Specifications
LoRa Node Controller LN Series 1.4 Product Specifications Product LN1130 Wireless Transmission Technology LoRaWAN Antenna Connector 1 × 50 Ω SMA Connector (Center Pin: SMA Female) Frequency IN865, EU868, RU864, US915, AU915, KR920, AS923 Work Mode OTAA/ABP Class A/B/C Data Interfaces... - Page 12 LoRa Node Controller LN Series Product LN1140 Wireless Transmission Technology LoRaWAN Antenna Connector 1 × 50 Ω SMA Connector (Center Pin: SMA Female) Frequency IN865, EU868, RU864, US915, AU915, KR920, AS923 Work Mode OTAA/ABP Class A/B/C Data Interfaces Interface Type 6-pin Removable Terminal Block Pin 1 (DI 0) Level 0: -24V~2.1V (±0.1V)
- Page 13 LoRa Node Controller LN Series Product LN502 Wireless Transmission Technology LoRaWAN Antenna 1 × 50 Ω SMA Connector (Center Pin: SMA Female) Frequency IN865, EU868, RU864, US915, AU915, KR920, AS923 Tx Power 16dBm(868)/20dBm(915) Sensitivity -148dBm Work Mode OTAA/ABP Class A/B/C Data Interfaces Interface Type 2 x M12 A-Coded Male...
- Page 14 LoRa Node Controller LN Series Physical Characteristics Operating -10°C to +65°C Temperature -40°C to +65°C (without batteries) Ingress Protection IP67 Dimensions 88 x 55.3 x 194.8 mm Power Connector 1 × M12 A-Coded Male Interface Power Supply Solar powered with two 18650 rechargeable batteries for the backup 9-48 VDC External Power Installation...
-
Page 15: Chapter 2. Hardware Introduction
LoRa Node Controller LN Series Chapter 2. Hardware Introduction 2.1 Physical Descriptions LN1130/LN1140 LN1130 LN1140 Front View Definition Description Definition Description RS232 D-(A) D+(B) RS485 Ground View - 15 -... - Page 16 LoRa Node Controller LN Series LN502 LN502 Bottom View Left Right Definition Definition Digital Output 1 5V DC out Digital Input 1 3.3V DC out Digital Input 0 RS232 Tx 9 – 48V DC in (+) RS232 Rx 9 –...
- Page 17 LoRa Node Controller LN Series LED Definition LN1130/LN1140 Color Function Power is activated. Lights Green Power is inactivated. Lights LoRa module is connected and ready. Blinks LoRa module is sending or receiving. LoRa Green LoRa module is not able to connect.
-
Page 18: Hardware Installation
Refer to the illustration and follow the simple steps below to quickly install your LoRa Node. LoRa Antenna Installation 2.2.1 Step 1: Rotate the antenna into the antenna connector accordingly. Step 2: The external LoRa antenna should be positioned vertically for a good signal. LN1130/LN1140 LN502 - 18 -... -
Page 19: Wiring Power Input
2.2.2 The 2-contact terminal block connector on the top panel of LoRa Node is used for one DC power input or one AC power input for LN1130 and LN1140. Please follow the steps below to insert the power wire. When performing any of the procedures like inserting the wires or tightening the wire-clamp screws, make sure the power is OFF to prevent from getting an electric shock. -
Page 20: Mounting Installation
DIN-rail and wall. Please read this chapter completely before continuing. LN1130/LN1140 This following pictures show the user how to install the device, and the device is not LN1130 or LN1140. 2.2.3.1 DIN-rail Mounting Installation 2.2.3.2 Wall-mount Plate Mounting - 20 -... -
Page 21: Side Wall-Mount Plate Mounting
LoRa Node Controller LN Series 2.2.3.3 Side Wall-mount Plate Mounting Caution: You must use the screws supplied with the wall-mounting brackets. Damage caused to the parts by using incorrect screws would invalidate your warranty. LN502 Mark the four holes on the wall you prefer to place the device and drill the marked four holes for the wall plugs (anchors). -
Page 22: Application Wiring
LoRa Node Controller LN Series 2.2.3.4 Application Wiring RS232 & RS485: RS232 Device LN1130 D-(A) D+(B) RS485 Device (Modbus RTU) Read the sensor and controller manuals before installing the RS485 Modbus sensor. Understand the wiring and communication requirements, such as termination resistors or baud rates. -
Page 23: Chapter 3. Preparation
Power on the LoRa Node device and then connect it to computer via micro USB port. LN1130/LN1140 LN502 The box of the LN1130/LN1140/LN502 does not contain any USB cable. Open the Tool and select “Serial port", and then enter password to log in Utility. (Default password: admin) - 23 -... -
Page 24: Chapter 4. Operations Management
LoRa Node Controller LN Series Chapter 4. Operations Management This chapter provides operations details of the LoRa node controller. 4.1 Managing LoRa Node Open the Tool and select “Serial port", and then enter password to log in Utility. (Default password: admin) For security reason, please change and memorize the new password after this first setup. - Page 25 LN Series The function menu on the top of the tool lets you access all the commands and configuration the LoRa Node Controller provides. LN1130 Function Menu LN1140 Function Menu LN502 Function Menu Now, you can use the LoRa Node Controller Tool software to continue the LoRa Node Controller management.
-
Page 26: Lorawan Setting
LoRaWAN setting is used for configuring the transmission parameters in LoRaWAN ® network. Basic LoRaWAN Settings: Go to “LoRa > LoRaWAN” of PLANET LoRa Node Controller Tool to configure join type, App EUI, Application Key and other information. You can also keep all settings by default. Object Description Unique ID of the device can be found on the label. - Page 27 To reset the frame-counter reset LoRaWAN Frequency Settings: Go to “LoRa > Frequency” of PLANET LoRa Node Controller Tool to select supported frequency and select channels to send uplinks. Make sure the channels match the LoRaWAN gateway. If frequency is one of AU915/US915, you can enter the index of the channel that you want to enable in the selection box, making them separate by commas.
-
Page 28: Interface Setting
The LN series supports data collection by multiple interfaces including serial ports or digital input and output. Besides, they can also power the terminal devices by power output interfaces. Basic settings are as follows: Go to “General > Basic” of PLANET LoRa Node Controller Tool to change the reporting interval. Object Description Reporting interval of transmitting data to network server. -
Page 29: Rs232 Settings
1. Connect RS232 device to RS232 port on the interface of LN1130 or LN502. 2. Go to “I/O Interface > RS232” of PLANET LoRa Node Controller Tool to enable RS232 and configure serial port settings. Serial port settings should be the same as RS232 terminal devices. -
Page 30: Rs485 Settings
1. Connect RS485 device to RS485 port on the interface of LN1130 or LN502. 2. Go to “I/O Interface > RS485” of PLANET LoRa Node Controller Tool to enable RS485 and configure serial port settings. Serial port settings should be the same as RS485 terminal devices. - Page 31 LoRa Node Controller LN Series Max. Retry Determines the maximum number of retries when data reading fails. Times Channel Name Defines the name of the channel for identification. Slave ID Specifies the unique ID of the Modbus slave device. Address Sets the starting address of the Modbus register for data reading or writing.
-
Page 32: Di/Do Settings
1. Connect DI/DO device to I/O port on the interface of LN1140 or LN502. 2. Go to “I/O Interface > DIDO” of PLANET LoRa Node Controller Tool to enable RS232 and configure serial port settings. Serial port settings should be the same as RS232 terminal devices. -
Page 33: Maintenance
LoRa Node Controller LN Series 4.4 Maintenance 4.4.1 Upgrade Go to “Maintenance > Firmware Upgrade” of PLANET LoRa Node Controller Tool, click “Choose File and Upgrade” to import firmware and upgrade the device - 33 -... -
Page 34: Reset To Factory Default
LoRa Node Controller LN Series 4.4.2 Reset to Factory Default Please select one of following methods to reset device: Hardware reset: Hold on the Reset button for more than 5s. LN1130/LN1140 LN502 - 34 -... -
Page 35: Chapter 5. Customer Support
Thank you for purchasing PLANET products. You can browse our online FAQ resource and User’s Manual on PLANET Web site first to check if it could solve your issue. If you need more support information, please contact PLANET switch support team.
