EKI-2701PSI/EKI-2711PSI

Industrial 802.3af/at PoE Splitter

Startup Manual

Overview

PoE splitter is powered by PoE and can split PoE input

into individual power output and data output. This device

can easily connect legacy devices like IP cameras or WiFi

Access Points to a PoE network architecture and also

works as a power supply to power up devices where power

is beyond coverage as alternative power source to save

cabling deployment cost.

EKI-2701PSI/EKI-2711PSI plays the role of powered device

(PD) and splits power from PoE to Ethernet devices. In this

case, both power and data can be transmitted up to 100

meters (328 feet) with one single Ethernet CAT5 cable from

power source equipment (PSE) with the power up to 12.95

(EKI-2701PSI)/25 (EKI-2711PSI) watts at 24V

Packing List

Before installation, please make sure that you have re-

ceived the following:

• 1 x EKI-2701PSI or EKI-2711 PoE splitter

• 1 x DlN-rail mounting bracket with 4 screws (M3 x 5L)

• 2 x Wall mounting brackets with 8 screws (M3 x 5L)

• 1 x EKI-2701PSI/EKI-2711PSI Startup Manual

If anything is missing or damaged, contact your distributor

or sales representative immediately.

For more information about this or other Advantech

products, visit the Advantech website at

http://www.advantech.com

For technical support and customer service, visit the

Advantech support website at

http://www.advantech.com/support

This manual is for EKI-2701PSI/EKI-2711PSI.

Part No. 2049271110

Specifications

General

• Compatibility:

- EKI-2701PSI: IEEE 802.3, 802.3u, 802.3ab, 802.3af

- EKI-2711PSI: IEEE 802.3, 802.3u, 802.3ab, 802.3af/at

• LAN: 10/100/1000Base-TX

• Transmission Distance: Up to 100 m

• Connectors: 2 x 10/100/1000Base-T(X) (PoE IN x1 +

DATA OUT X1)

• Power Input: 44~57V

• Power Output:

- EKI-2701PSI: 12.95W@24V

- EKI-2711PSI: 25W@24V

• Power Consumption:

- EKI-2701PSI: Max. 17.76W

- EKI-2711PSI: Max. 30W

• Dimensions (W x H x D): 30 x 140 x 95 mm

• Enclosure: IP30

• Operating Temperature: -40 ~ 75°C (-40°F ~ 167°F)

• Storage Temperature: -40 ~ 85°C (-40°F ~ 185°F)

• Operating Humidity: 5 ~ 95% (non-condensing)

• Storage Humidity: 5 ~ 95% (non-condensing)

• Safety: UL60950 (EKI-2701PSI)

• EMC: CE, FCC Class A

• Warranty: 5 years

Edition 1

August 2024

EKI-2701PSI/EKI-2711PSI Startup Manual 1

Need help?

Do you have a question about the EKI-2701PSI and is the answer not in the manual?

Questions and answers

Summary of Contents for Advantech EKI-2701PSI

Page 1 • Operating Temperature: -40 ~ 75°C (-40°F ~ 167°F) ceived the following: • Storage Temperature: -40 ~ 85°C (-40°F ~ 185°F) • 1 x EKI-2701PSI or EKI-2711 PoE splitter • Operating Humidity: 5 ~ 95% (non-condensing) • 1 x DlN-rail mounting bracket with 4 screws (M3 x 5L) • Storage Humidity: 5 ~ 95% (non-condensing)
Page 2 Overview Power Connection The EKI-2701PSI/EKI-2711PSI supports 24V power output. 1. Insert the positive and negative wires into the V+ and V- contacts on the terminal block connector. 2. Tighten the wire-clamps screws to prevent the DC wires coming loose. Warning: Ensure that the voltage of the power source is correct before connecting the equipment to a power outlet.
Page 3 Mounting Wall 1. Secure the wall brackets to the device with M3 screws, see the following figure. Align the wall mount plate over the screw on the wall. 2. To mount the wall plate, use screws of the size shown in the following illustration. Wall Mounting Screw Dimensions EKI-2701PSI/EKI-2711PSI Startup Manual 3...
