Upside 120 Bench
Assembly Instructions
Congratulations on your
purchase of a new Upside 120
Bench!
For assembly assistance, visit haworth.com, call 800 426 8562, or email support@haworth.com
Let's start to assemble your new Bench?
Follow all the steps carefully before using your Bench.

Advertisement

loading
Need help?

Need help?

Do you have a question about the Upside 120 Bench and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Haworth Upside 120 Bench

Summary of Contents for Haworth Upside 120 Bench

  • Page 1 Assembly Instructions Congratulations on your Let’s start to assemble your new Bench? purchase of a new Upside 120 Follow all the steps carefully before using your Bench. Bench! For assembly assistance, visit haworth.com, call 800 426 8562, or email support@haworth.com...

  • Page 2: Important Safety Instructions

    Upside Assembly Instructions Important Safety Instructions WARNING For use with Upside electric height-adjustable benches - Risk of injury, Not to be used in locations For Commercial or Household Use where children, or people with cognitive disabilities are This product conforms to UL962 and UL1286 and is certified to anticipated to be present and not supervised.

  • Page 3: Top View

    Upside Assembly Instructions Tools Required 1/8” Drill Electrical Tape Magnetic Tip Assembly Overview S370 S368 S200 Scale 1 : 1 S200 S200 (S-90) M6 X 8mm Set Screw (S200) M6 X 10mm Button Head S200 (S201) S201 M5 X 20mm Truss Head Screw (S24) (S370) (S368)
  • Page 4 Upside Assembly Instructions (A) Worksurfaces - Qty. 3 (D) Column (Left) - Qty. 3 (D1) Column (Right) - Qty. 3 (M) Column Crossmember - Qty. 3 (H) Frame - Qty. 6 (S200) M6 X 10mm Button Head - Qty. 36 (B) Worksurface Bracket - Qty.
  • Page 5 Upside Assembly Instructions Assembly Overview S200 S201 S200 S378 S200 S200 S201 Scale 1 : 1 (S-90) M6 X 8mm Set Screw (S200) M6 X 10mm Button Head (S378) M4 x 14mm ButtonScrew (S201) M5 X 20mm Truss Head Screw S201 (S24) TOP VIEW...
  • Page 6 Upside Assembly Instructions (D2) Column (Center) - Qty. 3 (H) Frame - Qty. 3 (M2) Center Crossmember (intersection) - Qty. 3 (H3) Center Column Bracket - Qty. 3 (H2) Center Rail - Qty. 3 (O) Center Cover with Bottom Tray - Qty. 1 - Qty.
  • Page 7 Upside Assembly Instructions Pull frame (H) o rails (H1) as shown Customer Service: 800 426 8562 E.C.O. No 500000048016 Part No Rev 1 Page 7 of 22 6100-0269...
  • Page 8 Upside Assembly Instructions Attach column (D1) to frame (H) - Slightly lift column to align holes LOOSE TIGHT Important Install screws (S200) (S200) LOOSELY M6 X 10mm Button Head S200 4mm Allen Wrench S200 Repeat 2nd step 2 to attach 2nd column (D2) to frame (H) Important LOOSE TIGHT...
  • Page 9 Upside Assembly Instructions Attach bracket (B1) to column (D) - Tilt column (D) and frame (H) slightly to align holes Important Left Column Right Column LOOSE TIGHT Install screws (S200) LOOSELY (S200) M6 X 10mm Button Head 4mm Allen 4mm Allen S200 S200 Wrench...
  • Page 10 Upside Assembly Instructions Install crossmember (M) to Left (D2) & Right (D) Columns NOTE: If installing in ll panels refer to instructions 61000288 and install in ll bracket (AB). Left Column Right Column S200 NOTE: Install extra bolts (S200) for end covers or transistion trays optional.
  • Page 11 Upside Assembly Instructions Tighten all screws (S200) TIGHTEN Important (S200) TIGHTEN all screws (S200) M6 X 10mm Button Head TIGHTEN S200 TIGHTEN TIGHTEN TIGHTEN TIGHTEN TIGHTEN 4mm Allen Wrench TIGHTEN TIGHTEN S200 TIGHTEN Customer Service: 800 426 8562 E.C.O. No 500000048016 Part No Rev 1 Page 11 of 22...
  • Page 12 Upside Assembly Instructions Attach frame (H2) to bracket (H3) FOR 120° TABLES S200 (S200) M6 X 10mm Button Head LEFT Important Make sure to install frame (H2) in correct direction. Attach crossmember (M2) to column (D2) Attach bottom tray (O) NOTE: Parts have been removed for clarity to show how the bottom tray (O) installs.
  • Page 13 Upside Assembly Instructions Flip frame assembly to feet and slide rail (H1) and frames (H) & (H2) together TOP VIEW Important Install rails (H1) as shown with slots facing each other NOTE: Install stanchions (L) are optional. Refer to instructions 61000286.
  • Page 14 Upside Assembly Instructions Install cable trough (K) to frame as shown S370 S368 S368 NOTE: Adjust frame to t cable trough. NOTE: Communications bracket (L3). (S370) (S368) 6mm Nylon Flat Washer M6 x 8mm Screw Customer Service: 800 426 8562 E.C.O.
  • Page 15 Upside Assembly Instructions Attach frame to desk top (A) - Align holes in brackets (B1) & (B2) with holes in desk top (A) TOP VIEW S201 Important Only install the screws (S201) shown. The other screws will be installed on the nal step. (S201) M5 X 20mm Truss Head Screw Customer Service: 800 426 8562...
  • Page 16 Upside Assembly Instructions Install 12 set screws (S-90) per work top (A) as shown 3mm Allen Important Wrench Make sure set screw (S-90) engage rails (H1). (S-90) S-90 M6 X 8mm Set Screw Install 6 screws (S201) per work top (A) as shown NOTE: Drill 1/4”...
  • Page 17 Upside Assembly Instructions Install control box (F) as shown Important S201 Make sure control box (F) (S201) is rmly attached to the worksurface M5 X 20mm Truss Head Screw Plug motor extension cable (J) to columns (D2) as shown Customer Service: 800 426 8562 E.C.O.
  • Page 18 Upside Assembly Instructions Plug power cable (G) into control box (F) as shown Install paddle handset (C) Important Install wire clips (K) close to cable box to reduce stress on cable connectors. S201 Screwdriver (S201) M5 X 20mm Truss Head Screw Customer Service: 800 426 8562 E.C.O.
  • Page 19 Upside Assembly Instructions SYNCHRONIZE DESK Lower desk all the way down using paddle handset (C) NOTE: This PAGE is for this paddle shown. Important Lower desk all the way down and Prior to rst use, synchronize release paddle the motors in the columns (D) - If table is already at lowest position skip to step 20.
  • Page 20 Upside Assembly Instructions Raise table to install screws (S201) as shown (S201) Raise Table up M5 X 20mm Truss Head Screw S201 Install 3 screws (S201) per worksurfaces Install PDA (P) NOTE: You will need to remove cover to install PDA. NOTE: Refer to instructions Reinstall cover when done.
  • Page 21 Upside Assembly Instructions Install screws (S378) as shown Install cover (O) as shown NOTE: Parts have been removed for clarity to show where screws (S378) are located. DO NOT remove any parts. S378 LOOSE TIGHT S378 (S378) (S378) M4 x 14mm ButtonScrew M4 x 14mm ButtonScrew Install cover (L) as shown NOTE: Parts have been removed for clarity to...
  • Page 22 Upside Assembly Instructions SYNCHRONIZATION INTERVALS Be sure to synchronize your desk as noted on page 19 to keep it calibrated and functioning properly. 1) Before rst use 2) After any cables/cords are disconnected/reconnected or after servicing any component (swapping out paddles, disconnecting/reconnecting the cables/cords, etc.) 3) After any interruption in power or loss of power (or any time the power cord is unplugged from the outlet and plugged back in)
