For use with HOP Single Motor Electric Height Adjustable Tables
This product is conformed to UL962 certified to CAN/CSA C22.2 No. 68.
When using an electrical furnishing, basic precautions should always be followed, including the following:
Read all instructions before using this table.
DANGER
- To reduce the risk of electric shock:
1. Always unplug this furnishing from the electrical outlet before cleaning.
WARNING
- TO REDUCE THE RISK OF BURNS, FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS:
1.
Unplug from outlet before putting on or taking off parts.
2.
Close supervision is necessary when this furnishing is used by, or near children, invalids, or disabled persons.
3.
Use this furnishing only for its intended use as described in these instructions. Do not use attachments not recom-
mended by the manufacturer.
4.
Never operate this furnishing if it has a damaged cord or plug, if it is not working properly, if it has been dropped or
damaged, or dropped into water. Return the furnishing to a service center for examination and repair.
5.
Keep the cord away from heated surfaces.
6.
Do not use outdoors.
7.
Do not operate where aerosol (spray) products are being used or where oxygen is being administered.
8.
To disconnect, turn all controls to the off position, then remove plug from outlet.
WARNING
9.
OUTLET ONLY. SEE GROUNDING INSTRUCTIONS.
This product must be grounded. If it should malfunction or breakdown, grounding provides a path of least resistance for
electric current to reduce the risk of electric shock. This product is equipped with a cord having an equipment-grounding
conductor and a grounding plug. The plug must be plugged into an appropriate outlet that is properly installed and
grounded in accordance with all local codes and ordinances.
DANGER
- Improper connection of the equipment-grounding conductor can result in a risk of electric shock.
Check with a qualified electrician or serviceman if you are in doubt as to whether the product is properly grounded.
Do not modify the plug provided with the product - if it will not fit the outlet, have a proper outlet installed by a
qualified electrician.
This product is for use on a nominal 120-volt circuit and has a grounding plug that looks like the plug illustrated in sketch A
(see Figure 1). Make sure that the product is connected to an outlet having the same configuration as the plug. No adapter
should be used with this product.
Max Static Load: 175 lbs
Electrical Rating: 120V, 60Hz, 5A for 2 leg tables
CUSTOMER SERVICE PHONE: 1-800-426-8562
IMPORTANT SAFETY INSTRUCTIONS
For Comercial Use Only
: RISK OF ELECTRIC SHOCK - CONNECT THIS FURNISHING TO A PROPERLY GROUNDED
SAVE THESE INSTRUCTIONS
E.C.O. No:
245-598
GROUNDED
OUTLET
GROUNDED
PIN
1 of 6
Page:
GROUNDED
OUTLET BOX
Part No:
6100-0011
Rev:
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Haworth Hop Series
Summary of Contents for Haworth Hop Series
- Page 1 IMPORTANT SAFETY INSTRUCTIONS For use with HOP Single Motor Electric Height Adjustable Tables For Comercial Use Only This product is conformed to UL962 certified to CAN/CSA C22.2 No. 68. When using an electrical furnishing, basic precautions should always be followed, including the following: Read all instructions before using this table.
- Page 2 HOP® Height Adjustable Tables Installation Instructions Scale 1 : 1 Tools Required #1 & #2 3mm & FOR 2 LEG TABLES (S-24) M8 x 12mm Button Head Screw (S-25) M2.9 x 19mm Pan Head Screw (S-26) S-26 S-25 S-24 M4.8 x 19 Pan Head Screw (S-27) S-26 S-26...
- Page 3 Stretch cross channel (J) to align with pilot holes (N). Attach cross channel (J) to Tighten set screws (P). legs (G) & (L). S-26 (S-27) NOTE: Attach cross channel (J) to work surface to align stretcher. M6 X 8mm Socket Cap S-27 S-27 (S-26)
- Page 4 Attach feet (E). Un-attach cross channel (J). Turn cross channel/leg assembly upright. S-28 (S-26) M4.8 x 19 Pan Head Screw S-26 (S-28) M6 x 35mm Socket Head Cap Screw Attach gear connector rod (K) to legs (C) and (L). NOTE: Make sure both columns are at the same height or at lowest position before installing gear connector rod.
- Page 5 Attach work surface. (S-26) M4.8 x 19 Pan Head Screw S-26 S-26 Attach gear connector cover (H) (S-26) M4.8 x 19 Pan Head Screw S-26 CUSTOMER SERVICE PHONE: 1-800-426-8562 E.C.O. No: 245-598 5 of 6 Rev: Page: Part No: 6100-0011...
- Page 6 Attach control box (C) and up/down handset (G). Reset table to lowest position. (S-25) M2.9 x 19mm Pan Head Screw (S-26) M4.8 x 19 Pan Head Screw S-25 CAUTION S-26 DO NOT PLUG POWER CORD INTO WALL OUTLET UNTIL LEG ASSEMBLIES AND HANDSET ARE CONNECTED TO CONTROL MODULE Handset reset and calibration.
