Summary of Contents for 7RYMS AU02
- Page 1 AU02 RGB Cardioid Condenser USB Microphone User manual...
- Page 3 Do not use the equipment in rain or in a damp environment to avoid short-circuit danger Please keep the product in a dry environment When used on computer, please follow the steps below: 1. Connect AU02 to the computer 2. Click sound setting and set the "7Ryms_AU02" as the input and output device...
-
Page 4: Packing List
Product Model: Vendor's information Customer information Vendor: Customer Name: Vendor Tel: Address: Date of Purchase: Email Address: Tel: AU02 Product SN: Vendor's Signature: RGB Cardioid Condenser USB Microphone User manual WARRANTY CARD 2 in 1 Audio Cable User Manual Warranty Card... - Page 5 Components and Instruction ① ② ③ ⑧ ⑥ ④ ⑦ ⑤ 1. Capsule 2. Mute Touch Control Short touch to turn on/o Mute, blue light on when mic working normally, red light on when muted 3. Sound Presets Switch Button Touch to switch podcast/streaming/sing sound presets.
- Page 6 Usage Connect the microphone to smartphone/computer through 2 in 1 Audio Cable and related audio adapter cable/adapter; Choose whether to monitor according to your needs. Adapter Adapter When using with Lightning interface devices, please purchase a USB-Lightning adapter/cable that supports the OTG function...
- Page 7 Specifications Polar Pattern Cardioid Pattern Sensitivity -37dB±2dB Frequency Response 20Hz ~ 20kHz Maximum SPL 120dB 70dB Equivalent Noise 24dBA Dynamic Range 96dB Sampling Rate 48kHz Bit Depth 24-bit Output Port USB-C Monitoring Port 3.5mm TRS/TRRS 400g Weight Dimension 55x63x165mm 0 ℃ ~+50 ℃ Working Temperature Storage Temperature -20 ℃...
- Page 9 AU02 RGB心型电容USB麦克风 用户使用说明书...
- Page 11 前言 感谢您购买七语 AU02 产品主要功能 . 16mm 心型电容咪头，专业棚级音质 . 48kHz/24bit 录音，智能降噪 . USB-C 数字输出，广泛兼容电脑、手机 . 动态 RGB 灯效，增添氛围感 . 内置声卡， 3 种声音预设选择 . 支持无级增益及监听音量可调 . 支持实时监听，一键静音 . 全金属制造，超强屏蔽性 注意事项 搭配Lightning接口设备使用时，请自行购买支持OTG功能的USB-Lightning 转接线/转接头 为获得更好的录音效果，请将麦克风的正面对准音源 请勿将本设备放置在热源或干扰源附近使用，如散热器、烤箱、冰箱、空 调、手机和WIFI热点旁边 本产品属于高精密仪器类产品，请避免使用时掉落、碰撞或重击 不要在雨中或潮湿的环境中使用该设备，否则会有短路的危险 请在干燥环境中对该产品进行保存 当用于电脑时，请按以下步骤进行操作： 1.将AU02连接电脑 2.打开声音设置界面，选择“7Ryms_AU02”为输出和输入设备...
- Page 12 配件： Errun Electronic Technology www.7ryms-audio.com Product Model: Vendor's information Customer information Vendor: Customer Name: Vendor Tel: Address: Date of Purchase: Email Address: Tel: AU02 Product SN: Vendor's Signature: RGB Cardioid Condenser USB Microphone User manual WARRANTY CARD 二合一音频连接线 说明书 保修卡...
- Page 13 部件介绍及说明 ① ② ③ ⑧ ⑥ ④ ⑦ ⑤ 1.麦克风咪头 2.静音触控键 短触开启/关闭静音，正常工作时蓝灯长亮，静音时红灯长亮 3.声音预设切换触控键 轻触切换播客/直播/唱歌声音预设。播客模式下，亮蓝色；直播模式下， 亮绿色；唱歌模式下，亮黄色 4.麦克风增益调节 5.监听音量调节 6.RGB动态灯效开关 7.3.5mm TRS/TRRS监听耳机插孔 8.USB-C音频输出接口...
- Page 14 使用方法 通过二合一音频连接线和相关音频转接线/转接头连接麦克风和手机/电脑； 根据个人需求选择是否监听 转接头 转接线 搭配Lightning接口设备使用时，请自行购买支持OTG功能的USB-Lightning 转接线/转接头...
- Page 15 技术规格 心型指向 指向性 -37dB±2dB 咪头灵敏度 20Hz ~ 20kHz 麦克风频率响应 120dB 最大声压级 70dB 信噪比 24dBA 等效噪声 96dB 动态范围 48kHz 采样率 24-bit 位深 USB-C 输出接口 3.5mm TRS/TRRS 监听接口 400g 产品重量 55x63x165mm 产品尺寸 0 ℃ ~+50 ℃ 工作温度 -20 ℃ ~+60 ℃ 储存温度...
