Digital Password Combination Security Desk Mount
CONTENTS:
A
x1
INSTALLATION:
1. Assembling base
x4
G
1A. Connect base (B) with body (A). Take
the body (A) and align the mounting holes. Rotate in (4) screws
(G) with provided allen key (H) until securely tightened.
3. Attaching Kiosk Body to Enclosure
F
M5x12
X4
M5 Hex Nut
X4
3A. Align VESA holes of the enclosure (K) to the VESA holes of the kiosk body (A). Rotate in screws (E) from above using provided tool (H) whie holding hex nuts (F)
from behind from within the storage compartment until securely fastened.
w/ Printer Shelf Compartment
PAD-FPDMDC
INSTRUCTION - MANUAL
C
B
x1
I
H
x1
M5 Allen Key
A
H
B
A
E
D
x1
x1
M5x12
J
x4
x1
2. Attaching Base Pads
2A. Flip over the now combined base section. Find the base pads
(component I) and peel off the sticker to expose the adhesive. Place the
foam pads (adhesive face down on base) at the corners and give it a firm
press for a few seconds until it's securely attached.
E
H
K
888-733-4448
F
x4
x4
M5 Hex Nut
K
x1
I
G
x4
M5 x 6
L
x1
Advertisement
Related Manuals for CTA PAD-FPDMDC
Summary of Contents for CTA PAD-FPDMDC
- Page 1 Digital Password Combination Security Desk Mount w/ Printer Shelf Compartment PAD-FPDMDC INSTRUCTION - MANUAL CONTENTS: M5 Hex Nut M5 x 6 M5x12 M5 Allen Key INSTALLATION: 2. Attaching Base Pads 1. Assembling base 2A. Flip over the now combined base section. Find the base pads (component I) and peel off the sticker to expose the adhesive.
- Page 2 5. Inserting Tablet into Enclosure 4. Setting up the Foam Adapters 5A. With the enclosure open, insert tablet into the foam adapters (L). 4A. Identify the double sided adhesives (J). Peel away the backing on both sides. Make sure the adhesives have been placed ahead of time or tablet will Adhesive four of them behind the foam pieces (L) as illustrated.
