Patiowell T-PS23-0404-86BG Assembly Instructions Manual

Resin garden shed
Hide thumbs

Advertisement

Table of Contents

BE
YOUR
LIFE BUILDER
www.patiowell.com
ASSEMBLY INSTRUCTIONS
RESIN
GARDEN SHED
SKU: T-PS23-0404-86BG
Resin Garden House
Installation Tutorial
https://www.patiowell.com/
pages/video-t-ps23-0404-868g
saleservice@patiowell.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T-PS23-0404-86BG and is the answer not in the manual?

Questions and answers

Related Manuals for Patiowell T-PS23-0404-86BG

Summary of Contents for Patiowell T-PS23-0404-86BG

  • Page 1 ASSEMBLY INSTRUCTIONS RESIN GARDEN SHED SKU: T-PS23-0404-86BG YOUR Resin Garden House LIFE BUILDER Installation Tutorial https://www.patiowell.com/ pages/video-t-ps23-0404-868g www.patiowell.com saleservice@patiowell.com...

  • Page 2: Site Preparation

    SITE PREPARATION Level the ground surface. Recommendation: Construct a wooden or concrete base as a foundation. The external dimensions of the product : 94.5” 66.1” 98” Before installation, please measure the ground with a tool and make sure the ground is level before installation.

  • Page 3: Before Starting Assembly

    Requires two people and takes 2-3 hours for Installation. Recommended to wear gloves to avoid scratches. Please read the manual carefully before installation. DO NOT RETURN YOUR UNIT TO THE STORE Contact us first saleservice@patiowell.com...
  • Page 4 FLOOR PARTS A1 X2 A2 X2 A3 X2 A4 X1 WALL PARTS B1 X1 B2 X6 B3 X1 B4 X1...
  • Page 5 WALL PARTS B5 X1 B6 X1 B2-1 X6 B2-2 X2 B2-3 X4 B2-4 X2 WINDOW PARTS W1 X2 W2 X1...

  • Page 6: Door Parts

    ROOF PARTS D1 X2 D2 X4 D3 X2 E1 X2 CL X2 CR X2 DD X1 D2-1 X2 D2-2 X1 D2-3 X4 D2-4 X2 E1-1 X2 DOOR PARTS DL X1 DR X1 DF X2 DZ X2...
  • Page 7 ACCESSORIES (3pcs) M4*10 (4pcs) M4*16 DH1 X2 DH2 X2 DG X2 DS X1 DC X1 DDZ X2 E3 X2 E4 X1 CRI X2 CLI X2 D4 X16 A5 X2 A1-1 X1 B1-1 X2 D2-5 X2 D2-6 X2 M6 X31 Z6 X6...
  • Page 8 SCREW inch inch SP6-15 M6*15 SP6-20 M6*20 inch inch SP6-25 M6*25 M6-10 M6*10 inch inch M6-15 M6*15 M6-55 M6*55 inch inch SPF6-20 M6*20 SF4-15 M4*15 inch inch M5-8 M5*8 M5-12 M5*12...
  • Page 9 CONTENTS 10-14 Floor Part Instruction (page) 14-25 Wall Part Instruction (page) 26-35 Roof Part Instruction (page) 36-40 Door Part Instruction (page)
  • Page 10 STEP 1 STEP 2...
  • Page 11 STEP 3 ① ② ③ STEP 4 ① ② ③...
  • Page 12 STEP 5 STEP 6...
  • Page 13 STEP 7 SPF6-20 SPF6-20 6 pcs STEP 8 SPF6-20 SPF6-20 4 pcs...
  • Page 14 STEP 9 SF4-15 A1-1 SF4-15 2 pcs STEP 10 ① ② FINISH ③...
  • Page 15 STEP 11 First pre-fold B1, B1 placed in a U-shaped groove on the floor, bend 90 degrees after alignment. (When installing B1, press on the top of B1 so that the clips below B1 are flush with the floor clips.You can use your foot to kick B1 flat.) CLICK...
  • Page 16 STEP 12 CLICK Place B3 at an angle on the floor Align the B1 clips and rotate to snap into place. (When installing B3, hold the top of B3 so that the bottom of B3 is flush with the floor clips, and then kick B3 with the flat of your foot.) STEP 13 Refer to the STEP 12 installation procedure.
  • Page 17 STEP 14 Pre-fold B4. CLICK CLICK...
  • Page 18 STEP 15 CLICK STEP 16 CLICK...
  • Page 19 STEP 17 CLICK...
  • Page 20 STEP 18 Pre-fold B6. CLICK CLICK...
  • Page 21 STEP 19 CLICK STEP 20 CLICK...
  • Page 22 STEP 21 Pre-fold B5 CLICK CLICK...
  • Page 23 STEP 22 B2-1 SP6-15 B2-1 SP6-15 SP6-15 SP6-15 30 pcs STEP 23 B2-1 SP6-15 B2-1 SP6-20 SP6-15 SP6-15 30 pcs...
  • Page 24 STEP 24 B2-4 B2-3 M6-10 M6-10 4 pcs 4 pcs STEP 25 B2-3 SP6-15 SP6-15 B2-3 SP6-15 SP6-15 40 pcs SP6-15...
  • Page 25 STEP 26 B2-2 B2-2 SP6-15 SP6-15 10 pcs...
  • Page 26 STEP 27 M6-55 D2-2 D2-1 D2-1 SP6-15 M6-55 SP6-15 5 pcs 1 pcs 5 pcs STEP 28 M6-15 D2-6 E1-1 M6-15 D2-5 M6-15 4 pcs 4 pcs...
  • Page 27 STEP 29 E1-1 M6-15 M6-55 D2-3 D2-4 D2-3 M6-55 M6-15 4pcs 4 pcs 8 pcs STEP 30 SP6-20 SP6-20 4 pcs...
  • Page 28 STEP 31 M6-15 M6-15 6 pcs 6 pcs 6 pcs STEP 32 M5-8 M5-8 ① ② M5-8 6 pcs...
  • Page 29 STEP 33 SP6-15 SP6-15 4pcs STEP 34 SP6-15 SP6-15 4pcs...
  • Page 30 STEP 35 STEP 36 M5-8 SP6-20 SP6-20 M5-8 6 pcs 2 pcs...
  • Page 31 STEP 37 M5-8 SP6-20 SP6-20 SP6-20 M5-8 18 pcs 2 pcs STEP 38 √ × Note the mounting direction of D4. 16 pcs...
  • Page 32 STEP 39 D1 and D3 are placed in the grooves of the iron frame, aligned with the grooves of the CL CR respectively and pushed forward. √ × SP6-20 D4 should fit perfectly on the tripod. SP6-20 SP6-20 32 pcs...
  • Page 33 STEP 40 SP6-20 SP6-20 8 pcs...
  • Page 34 STEP 41 Tilt D2 into place, find the corresponding position and put it down. SP6-20 SP6-20 SP6-20 48 pcs...
  • Page 35 STEP 42 SP6-25 SP6-25 12 pcs STEP 43...
  • Page 36 STEP 44 STEP 45 Do not push in hard when there is an obstruction, rotate DZ to adjust. Push DZ completely down below, ensuring the bottom surface is level.
  • Page 37 STEP 46 Take the DR and DL inside. Push it forward into position. ① ② Push it into the groove of the floor. Press the DZ downwards. ③ ④ Tilting the DR and DL and After inserting the DDZ, push the snapping it into the DDZ.
  • Page 38 STEP 47 SP6-20 M5-12 4 long screws for mounting part DS (lock part) SP6-20 M5-12 4 pcs 4 pcs...
  • Page 39 STEP 48 Remember to unplug the DC when closing the door and put it down when the door is closed. 3 short screws for mounting part DS (hinge section)
  • Page 40 STEP 49 Two people are needed. One person closes the door and inserts the pin, while the other person adjusts the gap outside the door. After making sure the gap is even, the person inside installs DDZ screws SP6-20. SP6-20 M5-12 B1-1 SP6-20...

  • Page 41: Care And Safety

    CARE & SAFETY • In case of fire, do not attempt to extinguish any burning polypropylene with water Unsuitable for storage of flammable or corrosive substances. • It is of utmost importance to assemble all of the parts according to the directions. Do not skip any step.
