MIO-5154 Intel
Intel® Processor N-series 3.5" SBC
(Code name: Alder Lake N)
Startup Manual
Packing List
Before you begin installing your card, please make sure that
the following items have been shipped:
1. 1 x MIO-5154 SBC
2. 1 x Startup Manual
3. 1 x SATA Cable
4. 1 x Audio Cable
5. 2 x COM Cable
6. 1 x USB 3.0 Cable
7. 1 x SATA Power Cable
8. 1 x Heatsink for 15W/12W CPU P/N: 1970005854T001
9. 1 x Heatsink for 6W CPU
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note 1:
For detailed contents of MIO-5154, please refer
to the Advantech website for detailed informa-
tion.
Note 2: Acrobat Reader is required to view any PDF file.
Acrobat Reader can be downloaded at: http://get.
adobe.com/reader/ (Acrobat is a trademark of
Adobe.)
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://advantech.com/support
This manual is for the MIO-5154 Series.
Part No. 2046515400
Printed in China
Core™ i3-N305 Processor,
®
P/N: 2046515400
P/N: 1700006291
P/N: 1700019584-01
P/N: 1700030404-01
P/N: 1700032181-01
P/N: 1700031583-01
P/N: 1960064228T021
Edition 1
Jan. 2024
Specifications
General
• CPU:
- Intel® Core™ i3-N305 Processor, 8 cores,
- Max Frequency 3.8GHz
- Intel
Processor N-series N97, 4 cores,
®
- Max Frequency 3.6GHz
- Intel
Processor N-series N50, 2 cores,
®
- Max Frequency 3.4GHz
• System Memory: Single Channel, SODIMM DDR5-4800
MT/s, up to 16 GB
• CPU TDP:
- Core™ i3-N305: 15W
- N-series N97: 12W
- N-series N50: 6W
• BIOS: AMI uEFI 256 Mbit
• Watchdog Timer: 65536 levels, 0~65535 sec, program-
mable by software. Multi-level WDT (set by iManager)
• Battery: Lithium 3 V/210 mAh
• Audio: High definition audio (HD), Line-in, Line-out,
Mic-in
Expansion Interface
• 1 x M.2 E-Key 2230
• 1 x M.2 B-Key 2280
• 1 x M.2 B-Key 3052
Display
• Controller: Intel
UHD Graphics (SoC integrated)
®
• Maximum Resolution:
- LCD:
LVDS dual channel 18-/24-bit up to 1920 x 1080
- DisplayPort:
DP 1.4a, up to 4096 x 2304 x 36bpp@60Hz
- HDMI:
HDMI 2.0, up to 4096 x 2160 x 24bpp@48-60Hz
• Multiple Displays:
Triple Simultaneous Displays: LVDS + HDMI + DP
Ethernet Interface
• Speed: 10/100/1000 BASE-T
• Controller: 2 x Realtek RTL8111K
Mechanical and Environmental
• Dimensions: 146 x 102 mm (5.7" x 4")
• Power Supply Type: ACPI support
• Power Requirement: +12 V ± 10% (Default supports
ATX 2x2pin 90D, DC Jack by T-P/N)
• Operating Temperature:
0 ~ 60°C (32 ~ 140°F)
MIO-5154 Startup Manual 1
Advertisement
Related Manuals for Advantech MIO-5154
Summary of Contents for Advantech MIO-5154
- Page 1 • Watchdog Timer: 65536 levels, 0~65535 sec, program- mable by software. Multi-level WDT (set by iManager) Note 1: For detailed contents of MIO-5154, please refer • Battery: Lithium 3 V/210 mAh to the Advantech website for detailed informa- • Audio: High definition audio (HD), Line-in, Line-out, tion.
-
Page 2: Jumpers And Connectors
M.2 B-Key (SATA / PCIe x1) M2_E1 M.2 E-Key (PCIe x1 / USB 2.0) BAT1 RTC Battery Connector SIM1 Nano SIM Connector Jumper Settings JCMOS1 CMOS Clear Switch Setting Function (1-2)* Keep COMS Data (Default) (2-3) Load CMOS Date 2 MIO-5154 Startup Manual... - Page 3 (2-3) MIO-5154 Connector Locations JCMOS1 VDD1 AT_ATX1 DIMMA1 GPIO1 LVDS1 FAN1 RI_VDD1 AUDIO1 COM2 COM3 SATAP1 COM5 SATA1 COM1 COM4 COM6 I2C_SMB1 DCIN1/2 LAN1 LAN2 USB2_1 USB3_1 HDMI1 USB1 Figure 1: MIO-5154 Mechanical Drawing (Top Side) MIO-5154 Startup Manual 3...
- Page 4 MIO-5154 Connector Locations (Cont.) M2_B1 M2_E1 SIM1 M2_B2 BAT1 Figure 2: MIO-5154 Mechanical Drawing (Bottom Side) Figure 3: MIO-5154 Mechanical Drawing (Coastline) MIO-5154 Mechanical Drawing 102.0 98.7 92.7 82.5 31.5 27.2 20.5 Figure 4: MIO-5154 Mechanical Drawing (Top View) 4 MIO-5154 Startup Manual...
- Page 5 MIO-5154 (Cont.) Mechanical Drawing 102.0 98.7 92.7 92.3 73.3 27.2 20.5 17.9 Figure 5: MIO-5154 Mechanical Drawing (Bottom View) 10.8 Figure 6: MIO-5154 Mechanical Drawing (Side View) MIO-5154 Startup Manual 5...
- Page 6 102.0 98.7 92.7 82.5 31.5 27.2 20.5 Figure 7: MIO-5154 Mechanical Drawing with CPU Heatsink (Top View) 24.0 10.8 Figure 8: MIO-5154 Mechanical Drawing with 15W/12W CPU Heatsink (Coastline) 16.2 14.6 10.8 Figure 8: MIO-5154 Mechanical Drawing with 6W CPU Heatsink (Coastline)
