STEP 5: MOUNTING THE INNER PLATFORMS
F
G1
H
J
G3
A
J
B
H
O2
Z2
16 // COSMO VIENNA ADJUSTABLE BED FRAME – OWNER'S MANUAL
1. Place the platform with the
control box (H) and the platform
with the pre-assembled
massage motor (G3) on the
frame facing upwards. Connect
all cables as seen in the next
picture.
2. Rotate the Platforms (H, G3)
and ensure that the all Platforms
are correctly positioned.
F
G1
H
G3
Z2
1. Connect the 4 Motor Cables
from the Side Rails (A, B) into
the Plug Ports on the Control
Box (I). Ensure that the color of
the Plug matches the color of
the Plug Port.
2. Connect the Massage Motor
cables (O1,
Connectivity Box (Z1).
3. Connect the Power Converter
I
Cable (J) into the Control Box.
Lay the Cable flat along the floor
to reduce the risk of tripping.
IMPORTANT:
▪
Make sure all cables are below
the platforms
H
O1
Z1
STEP 6: ATTACHING THE RETAINER BAR

STEP 7: CONNECTING THE POWER CABLES

O2) to the
1
10x
G2
L
D3
J
2
1. Place the remaining platforms
(G2, L) and turn the screws until
hand tight.
2. Move the Retainer Bar (N)
into position. The two ends of
the Bar should be inside the
Brackets at the end of the Foot
Platform (L).
3. Press the Retainer Bar (N)
firmly towards the Bed Frame
to click it into place.
4. Push corner connector covers
N
(D3) to click into place.
IMPORTANT:
▪ Use the labels on the Side Rails
(A, B) to ensure the Platforms
are at the right end.
▪
Ensure the the Platforms are
oriented correctly. The curved
edges should face outwards and
the Brackets for the Retainer
Bar should face downwards.
1. Connect the Power Cable (J)
from the Control Box to the
cable of the Power Converter
(K).
2. Connect the main power cable
to the Power Converter then to
the main.
K
3. Lay the main power cable along
the wall behind the Bed Frame
to minimize the risk of tripping.
COSMO VIENNA ADJUSTABLE BED FRAME – OWNER'S MANUAL // 17
