CAUTION
Risk of minor or moderate injury through crushing
Gripping the Side Rails' moving parts may lead to minor or moderate injury through crushing.
▪ Do not touch moving parts when lifting or moving the Side Rails. Only grip the fixed parts

STEP 2: ATTACHING THE LEGS

A B
C
14 // COSMO VIENNA ADJUSTABLE BED FRAME – OWNER'S MANUAL
1. Position the first Leg (C) below
the Side Rail (A/B) as shown in
the picture.
2. Turn the Leg to screw it into
the Side Rail. It should be hand
tight.
3. Repeat Steps 1 and 2 to Screw
in the other 3 Legs.
4x
REMOVE STRAPPING TAPE
STEP 3: MOUNTING THE HEAD PLATFORM
4x
M
O1
F
STEP 4: PLACING THE MASSAGE MOTOR
CAUTION
Risk of minor or moderate injury through tripping
While mounting the Platforms, you may have to step over the Power Cable. Tripping over the Cable may lead
to injury.
▪ Be careful not to trip over the Cable
2x
O1
F
G1
1. Place the head platform (F)
on the frame and slide the
massage motor (O1) on the
platform.
2. Turn the screws (M) until hand
tight.
1. Ensure that the massage motor
(O1) is placed centrally.
2. Slide the platform (G1) into the
massage motor and turn the
screws until hand tight.
COSMO VIENNA ADJUSTABLE BED FRAME – OWNER'S MANUAL // 15
