IM35, IM60, IM35P,
and IM60P Meters
For dispensing petroleum-based oils, diesel, antifreeze, gear lube, automatic transmission
fluid (ATF), and diesel exhaust fluid (DEF). For professional use only.
Not approved for use in explosive atmospheres or hazardous (classified) locations.
1500 psi (10.3 MPa, 103 bar) Maximum Working
Pressure
Meter measures in gallons, quarts, pints, and liters. The
meter is factory set to gallons.
See page 3 for model information.
Important Safety Instructions
Read all warnings and instructions in this
manual before using the equipment. Be
familiar with the proper control and
usage of the equipment. Save these
instructions.
IM35 / IM60
IM35P / IM60P
3A9515B
EN
Advertisement
Table of Contents
Related Manuals for Graco IM35
Summary of Contents for Graco IM35
- Page 1 Instructions - Parts List IM35, IM60, IM35P, and IM60P Meters 3A9515B For dispensing petroleum-based oils, diesel, antifreeze, gear lube, automatic transmission fluid (ATF), and diesel exhaust fluid (DEF). For professional use only. Not approved for use in explosive atmospheres or hazardous (classified) locations.
-
Page 2: Table Of Contents
IM35P / IM60P Models....20 IM35 and IM60 ......11 Pressure Drop Chart. -
Page 3: Models
Petroleum-based oil, diesel, antifreeze, gear 2004291 IM60P 1 1/2 1 1/2 Aluminum Alloy lube, ATF Display Meter, Petroleum-based oil, diesel, antifreeze, gear 2004292 IM35 Aluminum Alloy lube, ATF Display Meter, Petroleum-based oil, diesel, antifreeze, gear 2004293 IM60 1 1/2 1 1/2 Aluminum Alloy... -
Page 4: Safety Symbols
Safety Symbols Safety Symbols The following safety symbols appear throughout this manual and on warning labels. Read the table below to understand what each symbol means. Symbol Meaning Symbol Meaning Do Not Stop Leaks with Hand, Equipment Misuse Hazard Body, Glove or Rag Follow Pressure Relief Procedure Fire and Explosion Hazard Ground Equipment... -
Page 5: General Warnings
General Warnings General Warnings The following warnings apply throughout this manual. Read, understand, and follow the warnings before using this equipment. Failure to follow these warnings can result in serious injury. WARNING SKIN INJECTION HAZARD High-pressure fluid from dispensing device, hose leaks, or ruptured components will pierce skin. This may look like just a cut, but it is a serious injury that can result in amputation. - Page 6 General Warnings WARNING EQUIPMENT MISUSE HAZARD Misuse can cause death or serious injury. • Do not operate the unit when fatigued or under the influence of drugs or alcohol. • Do not exceed the maximum working pressure or temperature rating of the lowest rated system component.
-
Page 7: Typical Installation
. 1 is only a guide for selecting and installing system components and accessories. The components shown are typical; however, it is not a complete system design. Contact your Graco distributor for assistance in designing a system. Additionally, these dispense valves can be installed on a console. -
Page 8: Installation
Installation Installation Grounding Flush Lines For a new installation or if the fluid in the lines is contaminated, flush the lines before installation of the dispense valve. To avoid contamination of the fluid with oil, flush the equipment with a compatible solvent The equipment must be grounded to reduce the risk before using the equipment. -
Page 9: Installation Of Batteries
The numbers used in these instructions refer to F . 3. page 7. NOTE: This process is only for IM35 / IM60 models. 1. Follow Pressure Relief Procedure, page 11. 2. Remove the four screws (2) from the meter housing (3). - Page 10 Installation 5. Pull the battery retention ribbon, located under the batteries, up to unseat the batteries (F . 4). NOTE: Dispose of the batteries according to local regulations. 6. Insert new batteries, follow the indicated positions on the battery holder, and press down firmly on the batteries.
-
Page 11: Operation
Loosen the fitting nut completely. c. Clear any obstruction in the hose or tip. IM35 and IM60 Function of RESET Activate the Digital Display Press RESET to clear the quantity of the last dispense cycle and return the digital display to zeros (F . -
Page 12: Setup
Operation Setup 1. Press TOTAL and RESET together and hold for one second (F . 8). • All segments of the digital display illuminate for approximately six seconds. • The software revision displays for approximately two seconds. • The meter goes blank and the volume unit blinks. 2. -
Page 13: Restore The Default Calibration Factor13
Operation IM35P and IM60P 5. If the dispense was not accurate and needs to be performed again, repeat Steps 1 - Step 4. The meter requires a Logic Control Device to operate. NOTE: The Logic Control Device interprets pulse signals from the meter and converts them into a fluid quantity. -
Page 14: Verify Accuracy
Operation Verify Accuracy The meter sensor design allows for both PNP and NPN Logic Controller Devices (F . 12). 1. Set the pump air pressure to the lowest possible setting to dispense fluid. 2. Place the top of the nozzle at the bottom of a clean, calibrated container. -
Page 15: Recycling And Disposal
Recycling and Disposal Recycling and Disposal End of Product Life At the end of the product’s useful life, dismantle and recycle it in a responsible manner. • Perform the Pressure Relief Procedure, page 11. • Drain and dispose of fluids according to applicable regulations. -
Page 16: Troubleshooting
Increase the pump pressure. Shut off valve is not fully open Fully open the shut off valve. The meter element is jammed Contact your local Graco distributor for repair or replacement. Fluid leaks from cover (7) Damaged or worn o-ring (3) Replace the o-ring (3) and torque the cover to 15.8 - 17 ft-lb... -
Page 17: Notes
Notes Notes 3A9515B... -
Page 18: Parts
Parts Parts IM35 / IM60 Models Part No. 2004292, 2004293, and 2007587 3A9515B... - Page 19 Parts Part No. 2004292, 2004293, and 2007587 Ref. Part Description Housing, meter, 1 NPT (Model 2004295 2004292) Housing, meter, 1 1/2 NPT (Model 2004294 2004293) Housing, SST meter, 3/4 BSPP 2007585 (Model 2007587) 29A703 Identification, serial label 3◆ 2004313 Packing, o-ring 2004299 Pin, dowel Gear, oval 2004307 Pin, location...
-
Page 20: Im35P / Im60P Models
Parts IM35P / IM60P Models Part No. 2004290, 2004291, and 2007588 3A9515B... - Page 21 Parts Part No. 2004290, 2004291, and 2007588 Ref. Part Description Housing, meter, 1 NPT (Model 2004295 2004290) Housing, meter, 1 1/2 NPT (Model 2004294 2004291) Housing, SST meter, 3/4 BSPP 2007585 (Model 2007588) 29A703 Identification, serial label 3◆ 2004313 Packing, o-ring 2004299 Pin, dowel Gear, oval 2004307 Pin, location...
-
Page 22: Pressure Drop Chart
Pressure Drop Chart Pressure Drop Chart 3A9515B... -
Page 23: Technical Specifications
Technical Specifications Technical Specifications IM35, IM60, IM35P, and IM60P Metric Maximum Operating Pressure All Models 1500 psi 10 MPa, 102 bar Maximum Flow Rate IM30 and IM35P 35 gpm 132.5 lpm IM60 and IM60P 60 gpm 227.1 lpm Minimum Flow Rate IM30 and IM35P 1.5 gpm... -
Page 24: Graco Standard Warranty
With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
