Instructions Manual
Paint Resistivity
Meter
For measuring electrical resistivity of paint used for electrostatic coating. For professional
use only.
Not approved for use in explosive atmospheres and hazardous (classified) locations.
2002584 - Meter (includes 722860
Probe and 2002582 Meter Cable)
2011042 - Meter (includes 2002582
Cable)
Important Safety Instructions
Read all warnings and instructions in this
manual before using the equipment. Be
familiar with the proper control and
usage of the equipment. Save these
instructions.
3A9405B
EN
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Graco 2002584
Summary of Contents for Graco 2002584
- Page 1 For measuring electrical resistivity of paint used for electrostatic coating. For professional use only. Not approved for use in explosive atmospheres and hazardous (classified) locations. 2002584 - Meter (includes 722860 Probe and 2002582 Meter Cable) 2011042 - Meter (includes 2002582...
-
Page 2: Table Of Contents
Controls and Screens ..... . 10 Graco Standard Warranty....16 Home screen . -
Page 3: Safety Symbols
Safety Symbols Safety Symbols The following safety symbols appear throughout this manual and on warning labels. Read the table below to understand what each symbol means. Symbol Meaning Symbol Meaning Follow Pressure Relief Procedure Equipment Misuse Hazard Ventilate Work Area Fire and Explosion Hazard Wear Personal Protective Equipment Pressurized Equipment Hazard... -
Page 4: General Warnings
General Warnings General Warnings The following warnings apply throughout this manual. Read, understand, and follow the warnings before using this equipment. Failure to follow these warnings can result in serious injury. WARNING FIRE AND EXPLOSION HAZARD Flammable fumes, such as solvent and paint fumes, in work area can ignite or explode. Paint or solvent flowing through the equipment can cause static sparking. - Page 5 General Warnings WARNING TOXIC FLUID OR FUMES HAZARD Toxic fluids or fumes can cause serious injury or death if splashed in the eyes or on skin, inhaled, or swallowed. • Read Safety Data Sheets (SDSs) to know the specific hazards of the fluids you are using. •...
-
Page 6: Overview
Overview Overview The Graco Paint Resistivity Meter is an essential tool 2. Meter: The meter houses the electronics, batteries, used in the coatings industry to measure the electrical and the display. It calculates the resistivity of paint resistivity of paint. The resistivity of paint is a critical in Megohm-centimeters. -
Page 7: Installation
Installation Installation Carefully unbox the Graco Paint Resistivity Meter and all its components: the probe, cable, and meter. NOTICE Do not damage the probe, as this may bend the elec- trodes and affect the accuracy of the meter readings. Typical Installation . -
Page 8: Assembly: Connecting Meter, Probe, And Cable
Installation Assembly: Connecting Meter, Probe, and Cable Connecting the Meter Cable to the Meter and Probe Connect the cable at the port and the probe as shown in the figure above. Verify the cable is securely attached at both ends. 3A9405B... -
Page 9: Battery Installation Procedure
Installation Battery Installation Procedure Note: Ensure that the batteries installed are new. Lower mAh batteries will start with a <100% reading on the display. It is recommended to replace the battery if the The paint resistivity meter uses four AA batteries and is charge falls below 5%. -
Page 10: Controls And Screens
Controls and Screens Controls and Screens Key: Menu Back key (Power on) Enter key Up key Press the Enter key (M) to display the menu. The menu Down key will display the following options: Display Screen 1. Settings Home screen 2. - Page 11 Controls and Screens Settings 5. Factory Reset Restore the meter to its original factory settings. All custom settings and stored data will be erased. • Scroll to Factory Reset. • Select Factory Reset and confirm by selecting Yes when prompted. •...
-
Page 12: Operation
Megohm-centimeters. grounded containers. Power On Display Screen Colors Press and hold the Back key (L), until the Graco logo 1. Materials with resistivity readings in the “G” appears on the screen. green-colored display screen will give the best electrostatic results. -
Page 13: Calibration
Operation Calibration 1. Select the Standard Solution: Use a standard resistivity solution with a known resistivity value. 2. Clean the probe thoroughly to remove any contaminants that could affect calibration accuracy. 3. Immerse the probe in the standard solution until the hole in the probe is submerged halfway. -
Page 14: Dimensions
Dimensions Dimensions . 12 3A9405B... -
Page 15: Technical Specifications
Technical Specifications Technical Specifications Paint Resistivity Meter Metric Batteries AA (Qty 4) (2850 mAh minimum recommended) Operating temperature range 32°–122°F 0°–50°C Storage temperature range -22°–140°F -30°–60°C Materials of Construction Probe Wetted Parts Chrome Plated Aluminum Enclosure degree of protection IP51 Weight Meter weight (with cable, probe, and batteries) 1.3 lb. -
Page 16: Graco Standard Warranty
With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
