- Page 1 FusionCharge SmartModule1000A01 Quick Guide Issue: 01 Part Number: 31500KCT Date: 2024-11-10 HUAWEI TECHNOLOGIES CO., LTD.
- Page 2 (10) 12 V input power port (DC IN 12V, 1A) (11) 24 V input power port (DC IN 24V, 0.8A) (12) GE ports (GE1, GE2, GE3, GE4) (13) RST button (RST) Copyright © Huawei Technologies Co., Ltd. 2024. All rights reserved.
-
Page 3: Device Installation
Device Installation Installing the SmartModule Behind the Main Control Front Door of the Power Unit Electrical Connections • Connect cables in accordance with the installation laws and regulations of the country or region where the project is located. • Before connecting cables to ports, leave enough slack to reduce the tension on the cables and prevent poor cable connections. -
Page 4: Connecting The Pe Cable
Connecting the PE Cable • To enhance the corrosion resistance of the PE terminal, you are advised to apply silicone grease or paint on it after connecting the PE cable. • If the SmartLogger is connected to the SmartModule over a connecting plate, connect a PE cable to the PE terminal on the... - Page 5 Connecting the 12 V Input Power Cables Busbar of the power unit Connecting the RS485 Communications Cable • The recommended RS485 communication distance is less than or equal to 1000 m. • The SmartModule can connect to RS485 communications devices, such as a solar inverter, an environmental monitoring instrument (EMI), and a power meter over the COM port.
-
Page 6: Check Before Power-On
Port Identifier Description RS485A, RS485 differential signal+ COM1, COM2, COM3 – RS485B, RS485 differential signal– Check Before Power-On Criterion The SmartModule is installed correctly and securely. All cables are connected securely. Routing of power cables and signal cables meets the requirements for routing strong-current and weak-current cables and complies with the cable routing plan. -
Page 7: Rst Button
Within 3 minutes after the SmartModule is powered on, hold down the RST button for more button for more than 60s to restart the SmartModule and restore it to than 60s. factory settings. Contact Information https://digitalpower.huawei.com Path: About Us > Contact Us > Service Hotlines... - Page 8 Huawei Technologies Co., Ltd. Huawei Industrial Base, Bantian, Longgang Shenzhen 518129 People's Republic of China solar.huawei.com...
