Choosing the correct oil for your applications
Use the following recommended guidelines for oil selection on R-12, R-22, R-123, R-134a, R-513A,
R-515B, and R-1234ze for YK, CYK (all), YKEP, YKCP, YST, YT, and YD chiller applications. The
guidelines in Table 1 are based on the chiller application and evaporator saturation temperatures.
These operating conditions lead to system operating pressures and temperatures that govern the
oil selection.
To charge the system with new oil, complete the following steps.
1. Fill the oil sump with the quantities in
2. Turn the unit on.
3. Leave the unit on for at least 12 hours. During the 12 hours the oil heaters raise the oil
temperature to the limit specified for correct operation.
Table 1: Oil application table
Refrigerant type Operating mode
134a or 513A Evap saturation ≤ 57.2°F (14°C) K
134a or 513A Evap saturation ≤ 57.2°F (14°C) SK
134a or 513A Evap saturation ≥ 57.2°F (14°C)
≤ 82.4°F (28°C)
134a or 513A > 82.4F (28C) auxiliary
compressor or condenser
venting
1234ze or 515B Evap saturation ≤ 36°F (2.2°C) J
1234ze or 515B Evap saturation ≥ 36°F (2.2°C)
≤ 65°F (18.3°C)
1234ze or 515B > 65°F (18.3°C) < 88°F (31.1 °C) AA
1234ze or 515B > 65°F (18.3°C) auxiliary
compressor or condenser
venting
CYK all All
123 All
12 or 500 Evap saturation > 0°F (-17.8°C) B
22 or 717 Evap saturation > -20°F
(-28.9°C)
22 or 717 Evap saturation > -20°F
(-28.9°C)
Table 2: YORK oil quantities
Chiller model
YK
YK or YST
YK or YST
YK or YST
CYK, H oil only
SCYK, H oil only
YD
YKEP or YKCP
YT
YT
6 YORK Oil Application, Oil Change Interval, and Oil Quality Limits Replacement Recommendations
Table 2.
YORK oil
type
H
H
H
AA
H
C
C
F
Compressor models
Q3 to Q8
J1 to J4 and P6 to P9
H, P8, K1 to K4
K7
All
All
All
All
B and C
E and F
© 2025 Johnson Controls. All rights reserved.
55 gallon P/N 5 gallon P/N
011-00534-000 011-00533-000
011-01256-000 011-01257-000
011-00550-000 011-00549-000
011-00550-000 011-00549-000
011-00550-000 011-00549-000
011-00559-000 011-00558-000
011-01369-000 011-01370-000
011-01369-000 011-01370-000
011-00559-000 011-00558-000
011-00313-000 011-00312-000
011-00311-000 011-00309-000
011-00313-000 011-00312-000
011-00426-000 011-00434-000
Quantity needed to fill the oil sump
in an empty oil system (gal)
11.0
20.0
17.5
24.0
60.0, including 20.0 gal buffer
32.5
45.0
45.0
10.0
15.0
2.5 gallon P/N
011-01046-000
011-01258-000
011-00993-000
011-00993-000
011-00993-000
011-00994-000
011-01371-000
011-01371-000
011-00994-000
n/a
n/a
n/a
n/a
