- Page 1 Safety sensor GC 342+ EN Installation and operating instructions 198709-01 47.0955 / V4 – 11.24...
-
Page 2: Table Of Contents
Safety sensor GC 342+ Contents Symbols and illustrations .................3 Revisions and validity ..................3 Product liability ....................4 Reference documents ..................4 Installation information ................4 Safety ......................4 Intended use........................4 Safety notes .........................5 Safety-conscious working ....................6 Environmentally conscious working ................6 Description ....................6 Scope of delivery ...................7 Installation ....................8 Connection to the door control ............12 Special installation situations ............14... -
Page 3: Symbols And Illustrations
Safety sensor GC 342+ Setting GS 342+ using a remote control (optional) ....27 12.1 Using the remote control..................... 27 12.1.1 Entering the access code ..................... 27 12.1.2 Saving the access code ....................27 12.1.3 Deleting the access code ..................... 27 12.1.4 Setting one or more parameters ................28 12.1.5 Checking a value ...................... -
Page 4: Product Liability
Failure to comply releases the manufacturer from its statutory liability. Reference documents Supplementary information connected to GEZE drives can be found in the specific wiring diagrams. Installation information à Remove the laser window protection before the teach-in or putting the sensor into operation. -
Page 5: Safety Notes
à Make sure that the cover of the door control is fitted correctly and earthed. à If unauthorised changes are made to the system, GEZE cannot be held liable in any way whatsoever for any resulting damage, and the state- ment of approval for use in escape and rescue routes is no longer valid. -
Page 6: Safety-Conscious Working
Description Safety sensor GC 342+ Safety-conscious working à Secure workplace against unauthorised entry. à Watch the swivelling range of long system parts. à Never carry out high-risk work alone. à Secure the cover/drive panels against falling. à Use only the cables specified on the cable plan provided. Cables must be shielded in accordance with the wiring diagram. -
Page 7: Scope Of Delivery
Safety sensor GC 342+ Scope of delivery Scope of delivery Cover Door connection cable HS/OHS Lock screw Door transmission cable Laser head DIP switch Laser window Main connector Angle adjustment screw Master-slave connector Strain relief Push button End piece and screws Mounting plate Flexible tube Spacer... -
Page 8: Installation
Installation Safety sensor GC 342+ Installation Before attaching the mounting plate, make sure that the sensor does not obstruct door movement. If the sensor is not positioned correctly, it may be crushed when the door is opened. For optimum safety, install one module on each door wing side and interconnect the two modules using a door connection cable HS/OHS. - Page 9 Safety sensor GC 342+ Installation > 5 mm Ø 2 mm Before attaching the mounting plate, make sure that the sensor does not obstruct door movement and/or that the door does not become damaged by the link arm or frame/door jamb during opening.
- Page 10 Installation Safety sensor GC 342+ Ø 10 mm Door connection cable HS/OHS...
- Page 11 Safety sensor GC 342+ Installation...
-
Page 12: Connection To The Door Control
Connection to the door control Safety sensor GC 342+ Connection to the door control Attach the flexible tube with the end piece PZ1 / PZ2... - Page 13 The Kx connection is optional à For compliance with EN 16005 and DIN 18650, the test output of the door control must be wired and able to test the sensor. à The sensor is tested with GND. Disable ECO-mode when connecting to a GEZE Powerturn.
-
Page 14: Special Installation Situations
Special installation situations Safety sensor GC 342+ Special installation situations 7. 1 Installation on fire protection doors/glass doors If a cable cannot be routed through the door, both sensors are connected individually to the door control. Use GC 342 accessories. 1 GND 60 mA 60 mA 2/4 24V... -
Page 15: Gc 342/Gc 342+ Fire Protection Adapter
Safety sensor GC 342+ Special installation situations GC 342/GC 342+ fire protection adapter Adhere to the instructions provided by the manufacturer of the fire protection door. If the manufacturer of the fire protection door permits drill holes < Ø 10 mm, use the GC 342/GC 342+ fire protection adapter. min. -
Page 16: Retrofit
Special installation situations Safety sensor GC 342+ Retrofit Makes use of an on-site cable possible. Cut the door transmission cable to the correct length. Strip the 6 cores and connect them in accordance with the wiring diagram. Pay attention to the polarity of the power supply. GC 342+ DCU 8 24 V... -
Page 17: Description Of Led Displays
Safety sensor GC 342+ Description of LED displays Description of LED displays SIO active LED flashes slowly SIS or secondary closing LED flashes quickly edge active Green LED is off LED flashes LED flashes red-green LED flashes x times Calculation in progress; move out of the detection area and wait. -
Page 18: Dip Switch 1
Parameter setting Safety sensor GC 342+ 9. 1 DIP switch 1 SIO signal (safety opening) DIP 1 ON SIO signal (safety closing) DIP 1 OFF... -
Page 19: Dip Switches 2-4
Safety sensor GC 342+ Parameter setting Recommendation: Use GC 342 on the hinge side and GC 342+ on the opposite hinge side. The GC 342+ can also be used on the hinge side on request. DIP switches 2–4 Parameter Switch position DIP 2 Environment Standard Critical... -
Page 20: Teach-In
Teach-in Safety sensor GC 342+ Teach-in 10. 1 Service mode The service mode disables the safety detection of the sensor for 15 minutes and can be useful during installation, mechanical teach-in of the drive or maintenance work. Hold the push button for > 3 seconds. Service mode is enabled for 15 minutes. -
Page 21: Pre-Conditions
Safety sensor GC 342+ Teach-in 10.3 Pre-conditions à Door control has been completely configured. à Reflecting areas and glass areas near the door have been covered. à Door is closed (switch to service mode if necessary). à Both sensors wired according to the instructions. à... -
Page 22: Virtual Opening Push Button
Teach-in Safety sensor GC 342+ Defining the detection area When the LED flashes green: Stand in front of the door and stretch your hand out. Move your hand from top to bottom along the closing edge. Move back out of the detection area. - Page 23 Safety sensor GC 342+ Teach-in Press the push button twice. The teach-in starts. The LED flashes red-blue. 2× When the green LED flashes, hold your hand in the required position so that the virtual push button is taught in there. As soon as the red LED flashes, the teach-in process is confirmed.
-
Page 24: Main Closing Edge
Teach-in Safety sensor GC 342+ 10.6 Main closing edge The main closing edge (extended detection area) monitors the main closing edge of the door leaf during the closing movement. This area is activated when the door leaf is almost closed to protect hands and fingers. -
Page 25: Test And Settings
Safety sensor GC 342+ Teach-in 10.7 Test and settings Checking the correct positioning of the detection areas Place a reference body in the detection area. The door swings open up to the reference body without touching it and then closes again. Place the reference body next to the door leaf. -
Page 26: Final Steps
Final steps Safety sensor GC 342+ Final steps Fit the cover to the sensor, starting with the narrow side. Press tightly if necessary. To open the sensor again: Insert a screwdriver in the recess at the bottom of the sensor and pull it upwards. -
Page 27: Setting Gs 342+ Using A Remote Control (Optional)
Using the remote control 12.1.1 Entering the access code GEZE recommends using a different access code for each module. This way, you avoid changing parameters from both modules at the same time. After unlocking, If the red LED flashes quickly after... -
Page 28: Setting One Or More Parameters
Setting GS 342+ using a remote control (optional) Safety sensor GC 342+ 12.1.4 Setting one or more parameters 12.1.5 Checking a value x = Number of flashes = parameter value Orange Example: = Field width 2.35 m Green 12.1.6 Resetting to factory settings Full reset Partial reset Complete reset to... -
Page 29: Settings With The Remote Control
Safety sensor GC 342+ Setting GS 342+ using a remote control (optional) 12.2 Settings with the remote control à A teach-in overwrites the values entered here. = Factory setting à Field dimensions – door leaf protection 0 0 0 0 0 1 4 0 0 –... -
Page 30: Initial Configuration
Setting GS 342+ using a remote control (optional) Safety sensor GC 342+ Initial configuration R1 NO No power R2 NC detection Detection NO = normally open contact NC = normally closed contact Depth of the protection area 1 curtain 2 curtains 3 curtains 4 curtains Reopening side: During the opening cycle, the sensor always extends the safety depth to up to 4 curtains to cover the entire... -
Page 31: Operating Mode
Safety sensor GC 342+ Setting GS 342+ using a remote control (optional) Antimasking & background DIP 3 = ON Antimasking OFF * OFF * Background OFF * OFF * à Antimasking: detects unwanted objects near the laser window which mask the viewing field. -
Page 32: Detection Areas
Detection areas Safety sensor GC 342+ Detection areas 80° 20° 100 mm max. 4 m ~h/2 Door leaf Pinch zone Uncovered zone protection Typ. object size: Typ. object size: Can be set using the 10 cm 2 cm remote control with an installation with an installation Default setting: height of 4 m (2 cm... -
Page 33: Maintenance
Safety sensor GC 342+ Maintenance Maintenance à Wipe the laser window off using a clean and damp microfibre cloth if necessary. à Do not use a dry or soiled cloth or aggressive cleaning agents or chemicals. à Avoid direct exposure to high-pressure cleaners. Fault messages and troubleshooting Effect Cause... - Page 34 Fault messages and troubleshooting Safety sensor GC 342+ Effect Cause Elimination display A parameter Wrong DIP switch Switch the corresponding DIP cannot be set position. switch to ON. using the remote control. The remote The sensor is Enter the access code. control does not protected by an respond.
- Page 35 Safety sensor GC 342+ Fault messages and troubleshooting Effect Cause Elimination display The orange LED Communication Test the wiring between master flashes 3× every fault between and slave. 3 seconds. modules. Check the wiring between printed circuit board and laser head. Press the push button for at least 3 seconds if the door connection cable HS/OHS has...
- Page 36 Permanently faulty Teach-in again with the door door position closed. readings. If the orange LED lights up again: Contact GEZE Service. The orange LED Occasional faulty Move out of the detection area flashes 6× every door position and wait until the door closes.
-
Page 37: Technical Data
Safety sensor GC 342+ Technical data Technical data Technology Laser scanner, time-of-flight measurement. Detection mode Presence Max. detection 4 m (diagonal) with 2 % reflectivity area (e.g. at W = 1.5 m max. H = 3.7 m). Opening angle Door leaf protection: 80° / pinch zone: 20° Typical min. - Page 38 Technical data Safety sensor GC 342+ Standard conformity EN 12978, EN ISO 13849-1Pl “d”/ CAT2; IEC 60825-1; EN 62061 SIL 2; DIN 18650-1 Chapter 5.7.4 (reference body CA); EN 16005 Chapter 4.6.8 (reference body CA); EN 62061 SIL 2; DIN 18650-1 (reference body CA); EN 16005 (reference body CA).
-
Page 39: Accessories / Spare Parts
Safety sensor GC 342+ Accessories / Spare parts Accessories / Spare parts Material no. Left: 210490 stainless steel 210491 black 210492 white GC 342+ covers left GC 342+ covers right Right: 210493 stainless steel 210494 black 210495 white 167793 black GC 342/GC 342+ 167794 white mounting plates 167795 stainless... - Page 40 Accessories / Spare parts Safety sensor GC 342+ Material no. 199498 Retrofit interface Fire protection adapter 210921 Spare cable set 167759 Spot finder 112321...
- Page 41 Safety sensor GC 342+ Accessories / Spare parts...
- Page 42 Accessories / Spare parts Safety sensor GC 342+...
- Page 43 Safety sensor GC 342+ Accessories / Spare parts...
- Page 44 Germany China Romania GEZE GmbH GEZE Industries (Tianjin) Co., Ltd. GEZE Romania S.R.L. Niederlassung Süd-West E-Mail: chinasales@geze.com.cn E-Mail: office-romania@geze.com Tel. +49 (0) 7152 203 594 www.geze.com.cn www.geze.ro E-Mail: leonberg.de@geze.com Russia GEZE Industries (Tianjin) Co., Ltd. GEZE GmbH Branch Office Shanghai OOO GEZE RUS Niederlassung Süd-Ost...
