- Page 1 EQUIPMENT MANUAL UC25 COMPACT UNDER-COUNTER DISHWASHER 11.09.02 \\Fileserver\sales\MANUALS\ESWOOD MANUALS 2006\UC25\UC25 Operation Manual.DOC...
-
Page 2: Table Of Contents
ABLE OF CONTENTS Important: Prior to Installation General Description Technical Specifications Installation Initial Start-up Procedure Washing Operation Shutdown and Maintenance Trouble Shooting UC-25 Export Model Eswood Australia Branches \\Fileserver\sales\MANUALS\ESWOOD MANUALS 2006\UC25\UC25 Operation Manual.DOC... -
Page 3: Important: Prior To Installation
(Note: Travel time not covered by warranty) In no event will ESWOOD AUSTRALIA be liable for loss of facilities or other property and such things as, but not limited to, additional labour costs, loss of revenue or anticipated profits, and other damages of any kind whether direct, indirect, incidental or consequential. -
Page 4: General Description
150mm. The UC25 has an attractive and easy to clean satin finish stainless steel cabinet. Full tank width strainer pans prevent pump, drain and wash arm blockages, and wash arms, strainer pans and the overflow tube are easily accessible from the front of the machine and are all removable without tools. - Page 5 Electrical and Water Consumption Electrical Input 240V, 50Hz, 1 phase, 15 Amps max Water Input C minimum @ 200 kPa to 400 kPa Water Inlet Hose with ” B.S.P. fitting Drain Outlet ” B.S.P. gravity fed \\Fileserver\sales\MANUALS\ESWOOD MANUALS 2006\UC25\UC25 Operation Manual.DOC...
-
Page 6: Installation
Note that all plumbing work is to be done in accordance with local plumbing codes. Ensure that the rotary switch is “OFF” and connect the three pin plug lead to a 15 Amp, 240V, 50Hz, 1 phase power outlet. \\Fileserver\sales\MANUALS\ESWOOD MANUALS 2006\UC25\UC25 Operation Manual.DOC... - Page 7 Figure 1: Internals of the UC25. \\Fileserver\sales\MANUALS\ESWOOD MANUALS 2006\UC25\UC25 Operation Manual.DOC...
- Page 8 \\Fileserver\sales\MANUALS\ESWOOD MANUALS 2006\UC25\UC25 Operation Manual.DOC...
-
Page 9: Initial Start-Up Procedure
The machine will not start until the water in the booster has reached 82 C, as indicated by the temperature gauge. At this temperature, or above, the machine will start and stop automatically. Check for leaks. \\Fileserver\sales\MANUALS\ESWOOD MANUALS 2006\UC25\UC25 Operation Manual.DOC... - Page 10 “DRAIN”, close the door and press “START”. After 15 to 20 seconds open the door, remove the strainers and overflow tube and close the door. The machine will continue to drain and will stop automatically. Figure 2: Overflow tube Figure 3: Strainer pan. \\Fileserver\sales\MANUALS\ESWOOD MANUALS 2006\UC25\UC25 Operation Manual.DOC...
-
Page 11: Washing Operation
To wash another rack repeat from step 5. After every four to five washes add 1/4 cup of detergent. Note that the “START” button should not be re-pressed until the wash cycle is complete. HUTDOWN AND MAINTENANCE \\Fileserver\sales\MANUALS\ESWOOD MANUALS 2006\UC25\UC25 Operation Manual.DOC... - Page 12 Clean the exterior of the machine with a damp sponge. Do not pass water over the electrical controls and avoid abrasive or strong detergents. Check for leaks and ensure that the arms rotate freely. Leave the door open to allow the machine to air. \\Fileserver\sales\MANUALS\ESWOOD MANUALS 2006\UC25\UC25 Operation Manual.DOC...
-
Page 13: Troubleshooting
O-ring of the pipe. (c) Check for obstruction in the water supply solenoid valve and clean if necessary. Check diaphragm and replace if punctured. \\Fileserver\sales\MANUALS\ESWOOD MANUALS 2006\UC25\UC25 Operation Manual.DOC... - Page 14 (b) Check rinse jets for foreign matter and clean if necessary. (c) Check that the water supply solenoid valve is functioning correctly. (d) Check that the line strainer is not partially blocked. If so, remove and clean filter. \\Fileserver\sales\MANUALS\ESWOOD MANUALS 2006\UC25\UC25 Operation Manual.DOC...
- Page 15 Problem Possible cause and remedy Insufficient rinse (a) Ensure that temperature of incoming temperature water supply is at least (b) Check that boiler thermostat is set correctly and functioning. (c) Check element controls as appropriate. \\Fileserver\sales\MANUALS\ESWOOD MANUALS 2006\UC25\UC25 Operation Manual.DOC...
-
Page 16: Export Model
UC25 E XPORT MODEL The UC25 supplied for export differs from Australian models as follows: A rinse pressure booster pump is fitted as standard to cope with incoming hot water pressure as low as 47 kPa. The hot water supply hose should be fitted to the rinse pump and not to the ”... - Page 17 Suite 26, 10 Wittenberg Drive, 283-287 Sir Donald Bradman Drive Canning Vale, Brooklyn Park, Western Australia, 6155. South Australia, 5032. Phone: (08) 8238 3423 Phone: (08) 9456 0559 Fax: (08) 8238 3400 Fax: (08) 9456 0554 \\Fileserver\sales\MANUALS\ESWOOD MANUALS 2006\UC25\UC25 Operation Manual.DOC...
