  • Page 1 Centurion w/ SL2 Control Installation Guide 185 F...
  • Page 2 This Page Intentionally Blank. 4215-140 Page 1 71-0169 Rev. C 01/22/2025...
  • Page 3: Table Of Contents

    Contents General Installation Information Receiving Shipment Base Rail Assembly Wall Panel Installation Top Plate Installation Ceiling Panel Installation Bench Installation Leg Support Installation Backrest Installation Heater Placement/ Electrical Connection Glass Panel Installation Door Panel Installation Door/Handle Installation Temp Sensor Installation SL2 Control Mounting Corner Cap/ Trim Installation 16/17...
  • Page 4 Foam Gasket Installation of Sauna Room If the sauna is to be placed against existing walls, panel installation should begin away from the wall starting with the right panel. After these panels are all in place, the sauna can be slid back towards the walls, keeping 1”...
  • Page 5: Receiving Shipment

    Receiving Shipment Please immediately check for any hidden damage that may have occurred in shipping. If any damage is found, you must notify the delivering carrier within seven days. Taking a few minutes with the following instructions will ensure quick and proper assembly, and many years of enjoyment and relaxation.
  • Page 6: Base Rail Assembly

    Base Rail Assembly 1. Position the base frame in the desired location on a level surface. The stamped numbers on the base frame should be readable from inside the room and the sequence will run counter- clockwise. (Photo A) 2. Fasten the corners of the base frame using a 3” screw at each corner in the pre-drilled holes.
  • Page 7: Wall Panel Installation

    Wall Panel Installation 4. Starting with a back wall corner panel, position a wall panel over its corresponding numbered location on the base rail and hold it in place. Remove protective foam block from bottom of wall panel before placing on base rail. (Photo 5.
  • Page 8: Top Plate Installation

    10. Secure the remaining back corner panels together using the pre-drilled holes and supplied 3” screws. Top Plate Installation NOTE: Before installing top plates, ensure that all panels are fully connected on top and on the corners. 11. Install the back top plate first. Matching the numbered top plate to the corresponding wall panel number.
  • Page 9: Ceiling Panel Installation

    Ceiling Panel Installation 17. Using two people, carry the first roof panel over the sauna. Having one person inside the sauna room and another outside, feed the back ceiling panel over the top of the walls being careful not to scratch the panels. When in position it will rest on the top plate.
  • Page 10 Right wall length of 2 supports: Top: 16” Qty 1 Bottom: 38” Qty 1 Left wall length of 3 supports: Top: 16” Qty 2 Bottom: 63” (cut at wall joint) Qty 2 Note: Do not put weight on front of lower Platform until leg support is installed.
  • Page 11: Leg Support Installation

    Leg Support Installation 22. Locate the 4 support legs. 3 will have an adjustable foot and 1 will not. 23. The three with adjustable feet will be installed on the lower platform. Two in front of the heater in each corner with the notch side facing the front.
  • Page 12: Backrest Installation

    Backrest Installation 26. Locate the backrests and remove the backrest mounting hardware from the back of the backrests. The longest backrest will be installed on the back wall and the other backrest will be installed on the left wall. Install the back backrest first.
  • Page 13 Heater Placement 30. The lower platform has a precut location for the Himalaya heater. (Photo T) Note: It will ease the installation of the heater If your electrician connects the power and high limit cable before the heater is installed in the bench opening.
  • Page 14: Glass Panel Installation

    Glass Panel Installation 35. Uncrate and identify all the glass panels and hardware. 36. Hardware includes (1) Allen wrench, (4) Phillips head screws, (4) Allen head screws, (3) glass to glass hinges and (12) gaskets. Note: Always use some type of clean covering or padding between the glass panels and the floor or wall.
  • Page 15: Door Panel Installation

    Door Panel Installation Note: The following instructions are for a right hinged door but the same applies to a left hinge door. 41. Install door hinges to the stationary glass panel. The articulating portion of the hinge should swing out of the sauna, not inward. Be sure to install the included gaskets on both sides of the glass.
  • Page 16: Door/Handle Installation

    Door Handle Installation 45. Refer to the installation instructions included in the door handle box. Temp Sensor Installation 46. Locate the predrilled hole in the front ceiling panel. It will be in the front right corner. Feed the temp sensor cable through the hole with 3 to 4 inches of cable exposed.
  • Page 17: Sl2 Control Mounting

    SL2 Control Mounting 51. Feed cable from the hole in the ceiling panel (yellow control cable access sticker) down to the first support bar on the open panel on the right wall. ( Photo Z) 52. Follow the instructions included with the SL2 control kit to connect and mount the control.
  • Page 18 59. Cut the front top facia trim piece so that it covers the front ends of both side trim pieces and attach with finish nails. 60. Cut to length the interior ceiling trim pieces starting with the back wall and then the two side walls and secure with finish nails.
  • Page 19 Frequently Asked Questions CLEANING Yes, cleaning is needed! Perspiration and dirt may absorb into the wood so periodic cleaning is needed. Scrubbing the benches and floorboards with a stiff brush and mild detergent is normally sufficient. Light sanding with 220 grit sandpaper can also be used for heavy staining or water marks. INTERIOR PAINT OR STAIN You should never apply any paint or stain to the interior of your sauna! Off-gassing from these products could be harmful to your health when the room is heated.
  • Page 20 Heater Serial Number Date of installation Dealer purchased from Enjoy Your Sauna! Follow Finnleo (@Finnleosauna) on social media. Tag Finnleo & include #MyFinnleo for a chance to be featured on our page. https://www.finnleo.com 575 Cokato Street East., Cokato, MN 55321...
