Precautions Before Use
Preassembly Information
Electrical Requirements
Sauna Assembly
Electrical Connection-Under Bench
Electrical Connection-Inside Ceiling
Control Panel Instructions
Lighting Operation
Audio System
Wi-Fi Pairing Information
How to Use Sauna
Tips & Troubleshooting
Wiring Diagram
Warranty
71-0174
Rev. 01
S5-Series
4 Person Infrared Sauna
IL2 and Bluetooth
S840 User Manual
This Product is covered by:
US Patents No. 8,692,168
Canadian Patents No. 2,729,500
2,794,059 & 2,813,340
and other Patents Pending.
Page 1
Sauna360 Inc.
2
2
3
4
6
10
14
15
15
16
17
18
19
20
02/08/2023
R.D.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Finnleo S5 Series
Summary of Contents for Finnleo S5 Series
- Page 1 S5-Series 4 Person Infrared Sauna IL2 and Bluetooth S840 User Manual This Product is covered by: US Patents No. 8,692,168 Canadian Patents No. 2,729,500 2,794,059 & 2,813,340 and other Patents Pending. Precautions Before Use Preassembly Information Electrical Requirements Sauna Assembly Electrical Connection-Under Bench Electrical Connection-Inside Ceiling Control Panel Instructions...
-
Page 2: Pre-Assembly Information
Precautions before Use: Warning (Room Configuration & Use): • Proper Electrical Grounding is Required • Electrical Receptacles not Allowed in the Room • Do not Apply Water to any Heating Element • Do not Add a Locking or Latching System to the Door •... - Page 3 Electrical Requirements: The IR Sauna Room is designed for a 120 Volt AC / 15 or 20 Amp Circuit Breaker! A 120 Volt AC (dedicated) circuit is recommended to avoid unnecessary tripping of the breaker. The Sauna should be plugged into a NEMA (5-15R or 5-20R) Amp electrical outlet. IG 810SH 15 Amp IG 820SH...
- Page 4 Sauna Assembly Instructions Floor Panel (Box #1): • Locate the Floor Panel on a level surface (3-6) inches from wall and no more than (5 ft) from 120 Volt AC / 20-amp dedicated receptacle. • Position the Floor panel so that the Ceramic tiles / IR Floor Heaters are to the front of the room Note: place the Ceiling, Bench Skirt and Bench to the side until the appropriate steps.
- Page 5 Right Wall (Box #2): • Place Right Wall section into the right slot of the Floor Panel • Attach Back Wall to the Right Wall by lifting up the Right Wall sliding into the corner interlock brackets. Left Wall (Box #2): •...
- Page 6 Ceiling (Box #1): • Place the Ceiling panel with the speakers towards the back of the room. • Prop the ceiling up with the cam locks. • Once the Ceiling panel is lined up directly above the Wall panels; insert the wires harnesses from the wall panels into the holes in the Ceiling panel.
- Page 7 Front Glass (Box #2): Note: Use Caution while installing glass panels. Always have two people, wear grippy gloves, and do not let the glass touch hard ground; it will shatter. • Carefully place the smaller left glass window. • Carefully pick up the large glass piece and place the skinnier panel in the corner slot. •...
- Page 8 Bench Skirt (Box #1): • Fold out the attached bench supports against the glass wall. • Insert the Bench Skirt in between the bench support and back wall tracks. • Slide Bench Skirt all the way to the floor. Do not pinch any wires under the skirt. •...
- Page 9 Electrical Connections (under bench - right side): • Connect wire #4 from distribution plate to #4 from Back Wall harness. • Connect wire #5 from the distribution plate to #5 from the Back Wall harness. • Connect wire R1 from the distribution plate to R1 from the Right Wall junction box. •...
- Page 10 Electrical Connections (under bench - left side): • Connect wire L1 from the distribution plate to L1 from the Left Wall panel. • Connect wire B1 from the distribution plate to B1 from the Back Wall panel. • View of the finished connections. •...
- Page 11 • Use the buckles to latch the skirt to the walls. • Bench top can now be fit into place. Bench must tuck under the back-heater guard and then push all the way to the side walls. • The Bench Top should fit down flush from front to back. It may be necessary to use the openings on the bench skirt to apply pressure either forward or rearward on the skirt to allow bench to drop into place.
- Page 12 Electrical Connections (inside the Ceiling panel-back right corner): • Open all hatch doors on the ceiling to locate the necessary electrical plugs. • Access the connectors and connect them according to the labels on the harness. • Connect wire #4 from the Back Wall harness to the Ceiling wire #4. •...
- Page 13 Sauna Room 120 Volt AC Power Cord: • Plug the Sauna room power cord into the 20 amp 5-20R wall receptacle as noted in page 3. Note: It is important that the sauna be plugged into a dedicated outlet of the correct rating. Plugging your sauna into a shared circuit through can cause poor performance, circuit breaker tripping, or overheating of the circuit.
- Page 14 Control Panel Instructions: Power ON or OFF Set/View Time Set/View Temperature Bench Skirt Heat Interior/Color Therapy Lights Bench Top Heat Floor Heat Main Power: Press POWER to switch room ON or OFF Timer Functions: Press the Set/View Time icon to adjust or view sauna duration. Press and hold “+” or “-” to set room operating time.
- Page 15 Interior/Color Therapy Lights: Press Interior/Color Therapy Lights to turn the lights on. Press the button to cycle through color options. Note: at any point the lights can be turned off by long pressing Interior/Color Therapy Lights for 3 seconds. 1st press – White 2nd press –...
- Page 16 IL2 Control is Wi-Fi Compatible: • Download the SaunaLogic App and install onto your smart phone or tablet by scanning the QR Code below or searching for “SaunaLogic” in the appropriate app store. (Note) The IL2 Control is completely compatible with the “SaunaLogic” App. •...
- Page 17 How to Use Infrared Sauna: • Avoid eating large meals and excessive alcohol intake before using Sauna. • Never smoke or drink alcohol or exercise inside of Sauna. • If you are taking any medications or under the care of a Physician, consult with them prior to Sauna usage.
-
Page 18: Troubleshooting Tips
Maintenance / General Cleaning Tips: DO NOT USE: Alcohol or any strong Cleaning Chemicals Note: Some chemicals can damage clear finish and wood surfaces. • Interior: Perspiration and dirt may absorb into the wood, so periodic cleaning is needed, scrubbing benches, back supports, floorboards and walls with a stiff brush and mild detergent is normally sufficient. - Page 19 71-0174 Page 19 02/08/2023 Rev. 01 R.D. Sauna360 Inc.
- Page 20 71-0174 Page 20 02/08/2023 Rev. 01 R.D. Sauna360 Inc.
