Page 1: Table Of Contents
Centurion Indoor Series Owner’s Manual Centurion Indoor Sauna with Himalaya Heater and SL2 Control *Actual sauna may vary from image displayed. Receiving Shipment Read Before Installation Room Assembly Top Plate Ceiling Panel & Bench Leg Support Back Rest & Heater Placement... -
Page 2: Receiving Shipment
Receiving Shipment Please immediately check for any hidden damage that may have occurred in shipping. If any damage is found, you must notify the delivering carrier within seven days. Taking a few minutes with the following instructions will ensure quick and proper assembly, and many years of enjoyment and relaxation. -
Page 3: Read Before Installation
Read all instructions carefully before WARNING: Prolonged exposure to elevated installation including instructions packaged temperatures is capable of inducing separately with the sauna heater. Please leave hyperthermia. Hyperthermia occurs when the all instructions and warranty with the owner. internal temperature of the body reaches several degrees above the normal body Disclaimer: This manual is based off a right temperature of 98.6°F. -
Page 4: Room Assembly
INSTALLATION OF SAUNA ROOM If the sauna is to be placed against existing wall(s), panel installation should begin away from the wall starting with the right panel. After these panels are in place, the sauna can be slid back towards the wall(s) keeping it 1/2” to 1” separation from wall and sauna. -
Page 5: Top Plate
Note: For ease of installing the panels, tilt the top of each panel back to get the tongue and groove alignment started. Then tilt forward for an easy fit. 6. Secure the back wall to the right wall with three 3” Torq screws (screws and bit provided). Install one screw on the top of the wall, one in the middle, and one on the bottom. -
Page 6: Ceiling Panel & Bench
13. The top of the plate should be flush with the top of the interior tongue and groove. 14. Secure top plates using the 2” Torque screws (screws included). Install one screw in each corner and one screw in the center of each wall. Ceiling Panel Installation 15. -
Page 7: Leg Support
Right wall length of 2 supports: Top: 16” qty 1 Bottom: 38” qty 1 Left wall length of 3 supports: Top: 16” qty 2 Bottom: 63” (cut at wall joint) Qty 2 No leg support has been installed. Do not put weight on front of lower platform. -
Page 8: Back Rest & Heater Placement
23. Attach each leg with 2 screws (provided) to the front of the lower bench. Backrest Installation 24. Locate the backrest and remove the backrest mounting hardware from the backside of the backrest. The longest backrest will be installed on the back wall, the other will be on the left wall. -
Page 9: Glass Panel
29. The Himalaya Heater must be installed with the logo facing the front of the room. This is so the safety sensor is in the correct location. 30. A licensed electrician should wire the heater according to the specifications provided with the heater. *Rocks will be placed after testing the heater. -
Page 10: Door Panel
40. Carefully lower the ceiling panel onto the glass panels and bring both panels to the corner on the top and bottom. Be careful not to damage the tongue or the groove section of the panel. Make sure the front ceiling corner seats securely into place. -
Page 11: Door Handel & Temp Sensor
Door Handle Installation 49. Locate the door handle box. Separate the handle using the hex wrench to loosen the set screw found on the side of the metal door assembly. 50. Once separated use a Phillips screwdriver to separate the inner assembly. 51. -
Page 12: Sl2 Control Mounting
SL2 Control Mounting 62. Feed cable from the hole in the ceiling panel (yellow control cable access sticker) down to the first support bar on the open panel on the right wall. 63. Use a flat-blade screwdriver to carefully pry the front glass off the control body. - Page 13 73. Confirm everything is working. After confirmation, do the final installation of the control and see Himalaya installation manual for complete heater instructions. Note: At this point, prior to the completion of the room assembly, apply power to the heater and control panel to verify that the proper wiring connections have been made throughout the sauna assembly process.
-
Page 14: Audio Operations
AUDIO OPERATION Audio Power On ▪ Press icon to toggle On or Off the Bluetooth System. Note: The control does not have to be active for Sound System to operate. Pairing ▪ Refer to your mobile device to pair to the unit. ▪... -
Page 15: Saunalogic 2 Control Operations
SL2 (SAUNALOGIC 2) CONTROL OPERATION Operating Instructions for Heater Default settings for temperature are preset to 194°F, the bath time is set to 60 minutes and 0-minute delay to start to heat. These settings are adjustable (as described below) from 119°F to 194°F. Length of sauna can be set from 0 to 60 minutes. -
Page 16: Maintenance And Troubleshooting
COMMONLY ASKED QUESTIONS CLEANING Yes, cleaning is needed. Perspiration and dirt may absorb into the wood, so periodic cleaning is needed. Scrubbing the benches and floorboards with a stiff brush and mild detergent is normally sufficient. Light sanding with 220 grit is another option. INTERIOR PAINT OR STAIN You should never apply any paint or stain to the interior of your sauna! Off-gassing from these products could be harmful to your... - Page 17 Date of Purchase: _______________________ Place of Purchase: ____________________________ Record Serial Number Here Enjoy Your Sauna! Follow Finnleo (@finnleosauna) on social media. Tag Finnleo & include #MyFinnleo for a chance to be featured on our page. www.finnleo.com • 575 East Cokato St., Cokato, MN 55321...
- Page 18 Page Description Date Person Created Manual 06/09/2022 71-0169 4215-140 Rev. 01 Page 18 Revision Date 06/09/2022...
