NorthStar Outdoor Series Owner's Manual
Maintenance and Troubleshooting
71-0165
Rev. 01
NS 46, NS 56, NS 57
with SL2 Control and CB 16-1
and Bluetooth Sound Sytem (Optional)
NS 46, NS 56 Room
(4' x 6' , 5' x 6')
Precautions Before Use
Read Before Installation
Exterior Paint Requirements
Room Summary
Room Assembly
Roof Assembly
Electrical Installation
Sound Bar Installation
Interior Installation
Control Operation
Page 1
NS 57 Room (5' x 7')
2
2
3
4
5
10
14
18
20
22
24
4215-137
09/07/2021

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NorthStar Outdoor Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Finnleo NorthStar Outdoor Series

Summary of Contents for Finnleo NorthStar Outdoor Series

  • Page 1 NorthStar Outdoor Series Owner’s Manual NS 46, NS 56, NS 57 with SL2 Control and CB 16-1 and Bluetooth Sound Sytem (Optional) NS 57 Room (5’ x 7’) NS 46, NS 56 Room (4’ x 6’ , 5’ x 6’)

  • Page 2: Room Assembly

    Read all instructions carefully before installation including instructions packaged separately with the sauna heater. Please leave all instructions and warranty with the owner. WARNING: When using electrical sauna heaters and associated sauna products, basic precautions must be followed, including the following: 1.
  • Page 3 WARNING! The raw wood exterior of this sauna MUST be sealed with an approved exterior coating immediately! Exposure to rain in the “raw” state can permanently damage the wood and void your warranty! 4126-126 Rev A NorthStar Outdoor Sauna Wood Water vs.
  • Page 4 Trim Profiles Hardware Package Window/Door Casing (normally pre-installed) Carriage Bolts, Washers, Inside Cove Molding & Nuts (for saunas with L-benches) 9 x 2 Wood Screw Exterior Fascia Trim 9 x 3 Wood Screw Eve Trim / Exterior Cove Molding Torx Bit Description Location Quantity...
  • Page 5 INSTALLATION OF SAUNA ROOM 1. Place the floor panel in the desired location on a level surface Note: The floor panel must be level before installing wall and roof panels. If the surface is not level, you may need to shim the floor panel to get it level. The base is numbered to correspond with the panels for correct locations.
  • Page 6 5. Install the next wall panel of the right wall. Ensure the tongue and groove are fully engaged between panels. 6. Secure the two wall panels together with a 3” screw where the panels meet on top. Ensure tongue and groove are fully engaged. 7.
  • Page 7 9. Install the next panel in the number series. Secure to the back wall with three 3” Torq screws. Ensure the tongue and groove are tight at the interior corner when screws are installed. Install the next wall panel of the left wall. Repeat step 6 between the wall panels.
  • Page 8 14. Install top plates to the corresponding wall panels on front and back sides with the notched ends facing up. Install the left and right-side top plates so they fit into the notches. Note: Before installing top plate, ensure all panels are connected together on top and on the corners.
  • Page 9 17. Install the lower bench supports to the right and left side walls between pencil marks on red sticker labeled “Lower Bench Support”. Secure with 3” Torq screws in the provided predrilled holes. Install a 3” Torq screw into each access opening to secure the walls to the base plate and floor.
  • Page 10 INSTALLATION OF ROOF Note: The 4 x 6 and 5 x 6 rooms have a two-panel roof system and the 5 x 7 room has a three-panel roof system. The two-panel system is shown below, but the process is the same for the three-panel system. 20.
  • Page 11 26. Nail fascia trim to the exterior edge of roof starting with the back edge. Next the two side edges, and lastly the front edge. The fascia top should be flush with the top of the roof panel. Note: Trim is sent long to be cut on site for proper fit.
  • Page 12 33. Cut metal drip edge to the length of the roof and install to the back side of roof so the side with three grooves is on top of roof . Secure to roof with roofing nails or staples (not supplied). 34.
  • Page 13 38. Secure metal roofing with one row of screws at the back of roof at every other rib and another row of screws across the middle of roof at every other rib. Mark and cut the left and right-side flashing so it is flush with front edge of roof.

  • Page 14: Electrical / Heater Assembly

    ELECTRICAL / HEATER ASSEMBLY Place CB Box on the floor for easy access. Remove the cover to access the electrical connections. Connect all the quick connections into the CB Box according to the picture and installation manual. Note: All the low voltage connections have unique connectors.
  • Page 15 50. Determine power requirements and wire size needed based on the room model. WIRE SIZE Sauna Room Sauna Heater Phase Power Supply to CB 16-1 to Amps CB 16-1 Traditional Heater NS 46 Viki 4.5 18.8 2 #10AWG + GR 2 #10AWG + GR NS 56 Viki 6.0...
  • Page 16 Install plastic wire raceway on right side wall. Peel adhesive strip off the back side of raceway and attach to the wall, flush with the floor and about 12” from the front of the room. Make sure the open slot is facing up so wires can be inserted. Open slot facing up Insert the large black main power cable into the open slot of the wire raceway.
  • Page 17 Install two of the shorter screws to the control. Place a black plastic wing on the end of each screw longer screws are not used). 62. Mount control on to wall so the wires are inside the wall. Secure control to wall with the previously installed screws and wings.
  • Page 18 User and installation manual for SL2 Sound Bar (Optional) This Bluetooth Audio system has been designed exclusively for use with the SL2 and SL2-C sauna control systems. Do not attempt to connect to any other control system. Record the product serial number, found on the back of the sound bar in the space designated on the back of this document and save for future reference.
  • Page 19 Using your SL2 Sound Bar • Touch the Bluetooth button on your SL2 or SL2-C control to activate power to the SL2 Sound Bar. o A confirmation tone will be heard on your sound bar speakers when power is applied. Bluetooth Activation Button •...

  • Page 20: Interior Installation

    INTERIOR INSTALLATION 72. Install interior cove to front wall so it is flush to left and right edges of the wall. 73. Install cove to left and right side walls so it is flush to front cove and back wall. 74.
  • Page 21 The NS 57 bench system has three benches (Upper Main Bench, Upper Return Bench, Lower Main Bench). The upper main bench and lower main bench span from left to right walls. The upper return bench butts up to the upper main bench and spans to the front wall.
  • Page 22 SL2 (SaunaLogic 2) Control Operation Operating Instructions for Heater Default settings for temperature are preset to 194°F, the bath time is set to 60 minutes and 0-minute delay to start to heat. These settings are adjustable (as described below) from 119°F to 194°F. Length of sauna can be set from 0 to 60 minutes.

  • Page 23: User Maintenance Instructions

    AUDIO OPERATION Audio Power On • Press icon to toggle On or Off the Bluetooth System. Note: The control does not have to be active for Sound System to operate. Pairing • Refer to your mobile device to pair to the unit. •...

  • Page 24: Troubleshooting

    Date of Purchase: _______________________ Place of Purchase: ____________________________ Record Serial Number Here Enjoy Your Sauna! Follow Finnleo (@finnleosauna) on social media. Tag Finnleo & include #MyFinnleo for a chance to be featured on our page. • www.finnleo.com 575 East Cokato St., Cokato, MN 55321...
