- Page 1 Solace w/ SL2 Control Installation Guide 185 F *Actual sauna may vary slightly from image displayed...
- Page 2 Please Immediately check for any hidden damage that may have occurred in shipping. If any damage is found, you must notify the delivering carrier within 7 days. A few minutes with the following instructions will ensure quick and proper assembly, and many years of enjoyment and relaxation. By reviewing all the instruction steps ahead of time, you will have a better feel for the whole process.
- Page 3 Contents Accessories/Interior Components General Installation Information Base Rail Assembly Wall Panel Installation Top Plate Installation Electrical Assembly 8- 9 Mounting of Designer 6kw Heater Interior Installation 10-13 Heater Guard Assembly/Installation Backrest Installation 12-13 Middle Platform Installation Ceiling Installation Door/Handle Installation Adding Interior/ Exterior Trim Serial Number Recording Sheet WARNING: When using electric sauna heaters and associated sauna products, basic precautions must be...
- Page 4 Accessories/Interior Components Lower Bench (Qty.2) Upper Bench (Qty.2) Backrest (Qty.2) Middle Platform Lower Bench Support (Qty2.) Interior Cove Moulding (cut to fit) Exterior Facia Trim Step (cut to fit) Corner trim cap (pre-cut to length) 3-sided heater guard (needs Foam ceiling gasket assembly) (roll) Hardware Packs...
- Page 5 Foam Gasket Installation of Sauna Room If the sauna is to be placed against existing walls, panel installation should begin away from the wall starting with the right panel. After these panels are all in place, the sauna can be slid back towards the walls, keeping 1”...
- Page 6 Base Rail Assembly 1. Position the base frame in the desired location on a level surface. The stamped numbers on the base frame should be readable from inside the room and the sequence will run counter- clockwise. (Photo A) 2. Fasten the corners of the base frame using a 3” screw at each corner in the pre-drilled holes.
- Page 7 Wall Panel Installation 4. Starting with a back wall corner panel, position a wall panel over its corresponding numbered location on the base rail and hold it in place. Remove protective foam block from bottom of wall panel before placing on base rail). 5.
- Page 8 10. Secure the remaining back corner panels together using the pre-drilled holes and supplied 3” screws. Top Plate Installation NOTE: Before installing top plates, ensure that all panels are fully connected on top and on the corners. 11. Install the back top plate first. Matching the numbered top plate to the corresponding wall panel number.
- Page 9 Electrical Assembly 17. Before installing the interior benches, mount the CB16 Contactor Box on the side wall, 3.5” from the floor and 10”-12” from corner of wall. (Use scrap 2x4 material to easily set height of CB Box). The CB Box should always be mounted to the same side of the sauna as the location of the control.
- Page 10 21. Layout and dress the wires as shown in photo N. Any excess wire can be fed back into the access holes. 22. Remove the Designer 6kw heater from its packaging. Locate and uncoil the red/black high limit wire from the heater. connect the white connector to the CB16 Box as shown in photo O.
- Page 11 When you have all the wires connected, you can move on to the interior bench assembly, but beforehand you may want to have your electrician install the main electrical service and power cable from the heater to the CB16 Box. HOWEVER, do not energize the service until the sauna is fully assembled and ready to test with the heater connected! Follow the instructions included with the heater.
- Page 12 27. Position the left lower bench as shown and guide the bench down and into the lower interlock tab on the arm rest support (photo T1). Fully seat the bench so it is flush with the lower support rail. The decorative bull nose molding should face out at the front of the room as shown in photo T2.
- Page 13 Heater Guard Assembly and Installation 30. Assemble the heater guard with 1-1/2” screws provided using the pre-drilled holes. (Photo W) 31. Install the heater guard around the heater making sure that it is evenly spaced around the heater, (refer to the heater instructions for appropriate spacing).
- Page 14 33. Rotate the backrest back towards you and position approximately 20” off the bench surface to the top off the backrest. The important part here is to make sure the wire access hole is completely hidden behind the backrest. Hold level and screw to the back wall using the hardware that was attached to the back of the backrest.
- Page 15 Front Glass Panel Installation 36. At a slight angle, insert the left front glass panel into the front bottom rail slot and continue to carefully insert the glass panel into the left wall slot. Ensure the glass panel is fully seated into the slots.
- Page 16 Door Installation NOTE: The following instructions are for a right hinged door but the same applies to a left hinge door. 39. Install door hinges to the stationary glass panel. The articulating portion of the hinge should swing out of the sauna, not inward. Be sure to install the included gaskets on both sides of the glass.
- Page 17 Adding Trim 42. Locate the rear corner trim pieces and match the numbered corner trim to the corresponding numbered sauna frame corners. Position each corner trim piece into place so the T&G has an even reveal top to bottom. Secure with trim nails (Photo II) 43.
- Page 18 Frequently Asked Questions CLEANING Yes, cleaning is needed! Perspiration and dirt may absorb into the wood so periodic cleaning is needed. Scrubbing the benches and floorboards with a stiff brush and mild detergent is normally sufficient. Light sanding with 220 grit sandpaper can also be used for heavy staining or water marks. INTERIOR PAINT OR STAIN You should never apply any paint or stain to the interior of your sauna! Off-gassing from these products could be harmful to your health when the room is heated.
- Page 19 Heater Serial Number Date of installation Dealer purchased from Enjoy Your Sauna! Follow Finnleo (@Finnleosauna) on social media. Tag Finnleo & include #MyFinnleo for a chance to be featured on our page. https://www.finnleo.com 575 Cokato Street East., Cokato, MN 55321...
