- Page 1 Hallmark V4H Series Owners Manual With SL2, WiFi, Bluetooth & Piccolo Mini Heater 185 F...
-
Page 2: Table Of Contents
Table of Contents Description Pg No. Precautions Before Use Read Before Installation Room Assembly Electrical / Heater Assembly Backrest / Bench / Interior Assembly SL2 Control Operations Bluetooth Sound System Operation Wi-Fi Pairing User Maintenance Instructions Page 1 71-0177 Rev. A 9/29/2023... -
Page 3: Precautions Before Use
Read all instructions carefully before installation including instructions packaged separately with the sauna heater. Please leave all instructions and warranty with the owner. WARNING: When using electrical sauna heaters and associated sauna products, basic precautions must be followed, including the following: 1. -
Page 4: Read Before Installation
Read Before Installation The portable sauna unit comes with an option of two heater sizes; 1.7kW or 2.2kW Piccolo Mini. The 1.7kw can be used on all 15 amp or 20 amp household outlets (the standard 120 volt outlet found in all homes). A dedicated circuit is advisable to avoid unnecessary tripping of the breaker. The 2.2kW unit can only be used on dedicated 120 volt, 20 amp circuit. -
Page 5: Room Assembly
Room Assembly INSTALLATION OF SAUNA ROOM 1. Place the floor panel in the desired location on a level surface (Note: The floor panel must be level before installing wall and ceiling panels. If the surface is not level, you may need to shim the bottom panel to get it level.) The number 1 should be orientated to the front of the room. - Page 6 4. Place the left wall in slot of the floor panel and latch to the back wall. 5. Place the front panel in the slot of floor panel. All 4 panels should be flush at the top. If not, the pin/socket connections are not fully engaged. 6.
- Page 7 7. Place the ceiling panel on the four wall panels. • Make sure the trim of the top panel fits completely around the four side panels. • Make sure the connection wires from the front panel, right wall panel, and back wall panel protrude through the hole of the ceiling panel.
-
Page 8: Electrical / Heater Assembly
ELECTRICAL / HEATER ASSEMBLY 9. Place CB Box on the floor for easy access. Remove the cover to access the electrical connections. 10. Connect all the quick connections according to the picture and installation manual into the CB Box. Note: All the low voltage connections have unique connectors. - Page 9 13. Mount the CB Box to the right wall with 4 screws provided by locating the lower left corner of the box to wood corner trim on wall. (For clarity, CB box alignment trim is shown in yellow) 14. Place cover on CB Box with the four screws provided. 15.
-
Page 10: Backrest / Bench / Interior Assembly
16. Remove the rock grill from the heater. Remove the two screws on the top front of heater. 17. Follow instructions included in heater guard kit, (PN: 7200-186) to install wood heater guard to heater. (Heater guard is attached directly to the upper part of the heater shroud) 18. - Page 11 23. Place the backrest on top bench and connect the lighting from the right edge of the back to the back rest. Note: Test lights before mounting the back rest. 24. Install the backrests above the upper benches according to the predrilled holes, using the Philips screws provided.
-
Page 12: Sl2 Control Operations
SL2 (SaunaLogic 2) Control Operation Operating Instructions for Heater Default settings for temperature are preset to 194°F, the bath time is set to 60 minutes and 0-minute delay to start to heat. These settings are adjustable (as described below) from 119°F to 194°F. -
Page 13: Bluetooth Sound System Operation
Choose the color of choice and then set lighting brightness. The brightness will be on display for 3 seconds. Press the + or - icons to increase or decrease the light setting. Setting options are 25, 50, 75, and 100% light output. AUDIO OPERATION Audio Power On •... - Page 14 Heater Model Heater Serial Number Date of installation Dealer purchased from Enjoy Your Sauna! Follow Finnleo (@Finnleosauna) on social media. Tag Finnleo & include #MyFinnleo for a chance to be featured on our page. https://www.finnleo.com Page 13 71-0177 Rev. A...
