- Page 1 IS 440 V4 Owner’s Manual with SL2, CB15-1, BlueTooth and Piccolo Mini Heater 185 F...
-
Page 2: Table Of Contents
Table of Contents Description Pg No. Read Before Installing Precautions Before Use Room Assembly Electrical / Heater Assembly Bench/Interior Assembly Heater Installation SL2 Control Operations Bluetooth Sound System Operation Wi-Fi Pairing User Maintenance Instructions Product Serial Number Log Page 1 71-0178 Rev. -
Page 3: Read Before Installing
READ BEFORE INSTALLATION! Read all instructions carefully before installation including instructions packaged separately with the sauna heater and heater guard. Please leave all instructions and warranty with the owner. WARNING: When using electrical sauna heaters and associated sauna products, basic precautions must be followed, including the following: 1. -
Page 4: Room Assembly
ROOM ASSEMBLY The portable sauna unit comes with an option of two heater sizes; 1.7kW or 2.2kW. The 1.7kw can be used on all 15 amp or 20 amp household outlets (the standard 120 volt outlet found in all homes). A dedicated circuit is advisable to avoid unnecessary tripping of the breaker. The 2.2kW unit can only be used on dedicated 120 volt, 20 amp circuit. - Page 5 ROOM ASSEMBLY (CONT.) 1. Place the floor panel in the desired location on a level surface. Note: The floor panel must be level before installing the wall and ceiling panels. If the surface is not level, you may need to shim the bottom panel to get level. The base is numbered to correspond with the panels for correct locations.
-
Page 6: Electrical / Heater Assembly
4. Place and latch the front wall to right and left side walls. Be careful as the glass door may swing open unexpectedly. Place the ceiling panel on the wall panels. Tip: placing some of the foam packing material between the ceiling and wall panels will make it easier to route the wires up and into the ceiling. - Page 7 7. Connect the IR wires from the back wall to the Red connector on the two side walls. 8. Place cover over the connections and secure it with 4 screws to the wall. 9. Place CB15-1 Box on the floor for easy access. Remove the cover to access the electrical connections.
- Page 8 CAUTION: Loose wire connections can cause heat damage to wires, terminal blocks and other components and may void the warranty. 11. Connect electrical supply wires from back wall to the lower terminal block labeled L1, N, and GND. 12. Connect wires from the heater to upper terminal block labeled T1, T2, and GND to the sauna heater.
-
Page 9: Bench/Interior Assembly
BENCH / INTERIOR ASSEMBLY Note: Install benches after electrical work is completed and the control is working by testing the lights. Note: Bench supports are already installed in the proper location for the upper and lower benches, so no assembly of bench supports is required. -
Page 10: Heater Installation
HEATER INSTALLATION Refer to the Piccolo Mini Heater manual (included with heater) for the heater installation instructions. HARDWARE INCLUDED WITH HEATER: Piccolo Mini 1.7 or 2.1kW Htr Location Lag Screws (1/4” x 3/4”) Heater box Sheet Metal Screws (#6 x 12”) Heater box Installation Manual Heater box... - Page 11 30. Install door handle with Torq tip screws provided in the door handle package. Note: The Finnleo logo on the handle goes on the outside of room. Note: The glass surfaces should be cleaned prior to the first sauna use. Any household window cleaning product will work to remove any film/debris that may be present from shipping/handling.
-
Page 12: Sl2 Control Operations
SL2 IS (SaunaLogic 2) CONTROL OPERATION Traditional Sauna Operation Press the control POWER icon to turn on the sauna control. Press the SL2 IS icon for Traditional Sauna. The default settings for the temperature is 194°F, the bath time is 60 minutes. These settings are adjustable (as described below) from 119°... -
Page 13: Bluetooth Sound System Operation
Pre-Set Delayed Start Function First choose the heating system desired, then press the icon and delay time will appear in the display and will toggle between “dlay” and the amount of time remaining. The maximum time is 24 hours. If no delay is desired, press icon to toggle off the function. - Page 14 JP = Means a jumper CN 6 is missing from the Main PCA in CB15-1 box. This jumper should be pre- installed by our factory. If it is missing, contact your dealer for a jumper. For troubleshooting or service questions, please contact your Finnleo Sauna Dealer. Page 13 71-0178 Rev.
-
Page 15: Product Serial Number Log
Heater Model Heater Serial Number Date of installation Dealer purchased from Enjoy Your Sauna! Follow Finnleo (@Finnleosauna) on social media. Tag Finnleo & include #MyFinnleo for a chance to be featured on our page. https://www.finnleo.com Page 14 71-0178 Rev. A...
