- Page 1 T330 Handheld Two-Way Radio Service Manual Version: V1.1 Fujian Kirisun Communications Co.,Ltd...
-
Page 2: Table Of Contents
Contents 1 Overview....................................1 1.1 Range of Application..............................1 1.2 Safety Precaution................................1 1.3 Maintenance Service..............................2 2 External View and LED Indicator............................3 2.1 External View.................................. 3 2.2 LED Indicator.................................. 3 3 Circuit Description...................................4 3.1 Circuit Diagram................................4 3.2 RF Circuit..................................4 3.3 GPS Circuit..................................5 3.4 Baseband Circuits................................ -
Page 3: Overview
1.1 Range of Application This manual is applicable to the maintenance and repair of the T330 handheld two-way radio based on public network. The manual is intended for use only by the engineers and professional technicians who have received training from Kirisun. The manual is subject to change because of technology development. For the latest technical data of the product, please contact Kirisun or a local agent. -
Page 4: Maintenance Service
T330 Handheld Two-Way Radio Service Manual Pay attention to the model when you replace a part. Do not use a part incompliant with the requirements stated in the materials provided by the company. 1.3 Maintenance Service The Chinese standard of “guarantee of repair, replacement and refund” is provided to wireless two-way radios. -
Page 5: External View And Led Indicator
T330 Handheld Two-Way Radio Service Manual 2 External View and LED Indicator 2.1 External View 2.2 LED Indicator LED State Radio State Red light on Signals being transmitted, or charging in progress Green light on Signals being received, or charging finished... -
Page 6: Circuit Description
T330 Handheld Two-Way Radio Service Manual 3 Circuit Description 3.1 Circuit Diagram 3.2 RF Circuit... -
Page 7: Gps Circuit
T330 Handheld Two-Way Radio Service Manual 3.3 GPS Circuit 3.4 Baseband Circuits 3.4.1 Power Supply Circuit... - Page 8 T330 Handheld Two-Way Radio Service Manual 3.4.2 Audio Frequency Circuit 3.4.3 SIM Card Interface Circuit...
- Page 9 T330 Handheld Two-Way Radio Service Manual 3.4.4 MIC Circuit 3.4.5 Key Circuit...
-
Page 10: Functions And Parameters
T330 Handheld Two-Way Radio Service Manual 3.4.6 LCM Circuit 4 Functions and Parameters 4.1 Basic Functions Voice: Individual call, group call SMS: Sending and receiving short messages coded by the platform GPS: Positioning and data submission Graphic UIs ... -
Page 11: Advanced Functions
The radio has been set before delivery. However, to meet customers’ requirements, further configuration may be necessary, for example, programming of a function key, Bluetooth, roaming and Pin lock. This can be achieved by the programming software PC Tool developed by Kirisun. It is user-friendly and easy to operate, and supports Chinese, English and Turkish. -
Page 12: Installing/Uninstalling The Antenna
T330 Handheld Two-Way Radio Service Manual Uninstalling the Battery 1. Press the battery latch at the back of the radio. 2. Take down the battery. 5.2 Installing/Uninstalling the Antenna Installing the Antenna Insert the whorled end into the slot at the top of the radio, and then turn the antenna clockwise to tighten it. -
Page 13: Detaching Main Board From Aluminum-Alloy Holder
T330 Handheld Two-Way Radio Service Manual 2. Take down the antenna. See 5.2 Installing/Uninstalling the Antenna for details. 3. Take down the battery. See 5.1 Installing/Uninstalling the Battery for details. 4. Take down the two bolts at the bottom of the radio, the nut fixing the antenna, and take down the two screws fastening the battery holder using a tool. - Page 14 T330 Handheld Two-Way Radio Service Manual Multilayer chip capacitor ±10﹪/16V C1AP 0603-475P Multilayer chip capacitor ±5﹪/50V C45, C46 0402-22P Multilayer chip capacitor ±5﹪/50V C3M, C5M, C6M, C14, C14AP, C15, C22, C23, C24 0402-33P Multilayer chip capacitor ±10﹪/50V C2AP, C9AP, C15AP, C27, C37...
- Page 15 T330 Handheld Two-Way Radio Service Manual Diode 1N4148W SOD-523/0603，T4 D3, D4, D5, D8 LED0603 100-150，620-625 LED0603 250-300，525-530 SOD-323B,120-150 D9, D10 ， LED0603 0.27-0.28 Multilayer Inductor ±5% L1AP 0402-100nH R Multilayer Inductor 0402-47nH ±5% 2*12PIN，3.0，0.5mm， CBAC203-1202B005B1AF SOCKET H2.2mm Triode DDTC123JE SOT-523, DIODES...
- Page 16 T330 Handheld Two-Way Radio Service Manual R chip resistor 0402-1.2K ±5% R chip resistor 0402-1.8K ±5% R chip resistor 0402-2.2K ±5% R18, R53 R chip resistor 0402-10K ±5% R1AP, R2AP, R3AP, R29, R47, R58, R61, R65, R70 R chip resistor 0402-47K ±5%...
- Page 17 T330 Handheld Two-Way Radio Service Manual IC GT31L16S2W80 SOP8-B IC ETA7008S2G SOT23-6 LDO3V ， SOT23-5 ， LC1463CB5ATR30 LEADCHIP 7V16000012 XTAL-3225，16MHz 1.77,128RGB*160Dots,I LCD1 LCD 17QS476-02 C:ST7735S MIC BY6050F0P2.8-0PK ，-38dB,Φ6*5 layers ， K35A-KEY-PCB V1.0 9.627*47.177mm 3.5,5PIN ， PJ-328A JAKK3.5D-TP-N55 PJ-208B 2.5,5PIN，JAKK2.5D RP08110SNHX-V02-1112...
- Page 18 T330 Handheld Two-Way Radio Service Manual Multilayer chip ±10﹪/50V capacitor0402-103P Multilayer chip ±10﹪/16V C6C, C8, C8C, C10, C10C, C13, C28, C29, C60 capacitor0402-104P Multilayer chip ±10﹪/16V C2C, C5C, C7C, C9C,C7 capacitor0402-475P Multilayer chip ±10﹪/10V capacitor1206-476P 8PIN MUP-C791-3 Hinge Type J2, J3 ，...
-
Page 19: Debugging
T330 Handheld Two-Way Radio Service Manual IC NAU88C10YG QFN20,NUVOTON 6 Debugging 6.1 Preparation Prepare the followings. Antenna interface converter Universal interface Test card General-purpose tester CWM500/8960 6.2 Index Verification 6.2.1 Frequency Bands Model T330 Frequency Band B2(1900MHz）... - Page 20 T330 Handheld Two-Way Radio Service Manual HIGH HIGH HIGH HIGH Test ID 13232 13262 13317 23230 23230 23230 23230 23230 23230 132022 133297 133422 Model T330 Frequency Band WCDMA-B2(1900MHZ) WCDMA-B4(1700MHZ) WCDMA-B5(850MHZ) HIGH HIGH HIGH Test ID 9662 9800 9938 1537...
- Page 21 T330 Handheld Two-Way Radio Service Manual...
-
Page 22: Technical Specifications
T330 Handheld Two-Way Radio Service Manual 7 Technical Specifications General Specifications LTE FDD:B2 B4 B5 B12 B13 B14 B66 B71 Frequency Range WCDMA:B2 B4 B5 Weight ≤280g (include battery and antenna) Rated Operating Voltage 3.7V Average battery duration (5-5-90, high-power emission), 3600mAh ≥20 hrs... -
Page 23: Troubleshooting
T330 Handheld Two-Way Radio Service Manual 9 Troubleshooting Failure Description Troubleshooting Reason 1: Low battery. Solution: Charge or replace the battery. Reason 2: SIM card improperly installed or overdue. Solution: Make sure the Startup failed SIM card is installed properly, or replace it.
