- Page 1 UPC-F12M1-RPLP MODEL: UPC-F12M1-RPLP 12.1” 600cd/m² XGA Fanless Panel PC with Intel® Core™ Raptor Lake-P i3-1315URE CPU, 8GB LPDDR4x RAM, PCAP touch, M12 I/O User Manual User Manual Page I Rev. 1.00 - January 16, 2025 [MODEL NAME]...
-
Page 2: Revision
UPC-F12M1-RPLP Revision Date Version Changes January 16, 2025 1.00 Initial release Page II [MODEL NAME]... -
Page 3: Safety Instructions
UPC-F12M1-RPLP Safety Instructions Warning! Read the user manual before connecting the system to the power source. Vorsicht! Bitte lesen Sie die Bedienungsanleitung, bevor Sie das System an eine Stromquelle anschließ en. Attention! Avant de brancher le système à la source d'alimentation, consultez le mode d'emploi. - Page 4 UPC-F12M1-RPLP Warning! Use only the adapter and power cord approved for this system. Use of another type of adapter may risk fire or explosion. Please refer to the user manual for the power adapter specifications. Vorsicht! Nur zugelassene Netzteile und Netzkabel dürfen verwendet werden.
- Page 5 UPC-F12M1-RPLP Warning! Ultimate disposal of this product should be handled according to all national laws and regulations. Vorsicht! Die Entsorgung dieses Produkts sollte gemäß allen Bestimmungen und Gesetzen des Landes erfolgen. Attention! La mise au rebut ou le recyclage de ce produit sont généralement soumis aux lois et/ou directives de respect de l'environnement.
-
Page 6: Copyright
UPC-F12M1-RPLP Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manu- facturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequen- tial damages arising out of the use or inability to use the product or documentation, even if ad- vised of the possibility of such damages. -
Page 7: Manual Conventions
UPC-F12M1-RPLP Manual Conventions WARNING Warnings appear where overlooked details may cause damage to the equipment or result in personal injury. Warnings should be taken seriously. CAUTION Cautionary messages should be heeded to help reduce the chance of losing data or damaging the product. -
Page 8: Table Of Contents
UPC-F12M1-RPLP Table of Contents REVISION ........................II SAFETY INSTRUCTIONS ................III COPYRIGHT ........................VI MANUAL CONVENTIONS ..................VII TABLE OF CONTENTS ..................... VIII LIST OF FIGURES ......................XI LIST OF TABLES ......................XII 1 INTRODUCTION ......................1 1.1 O ........................2 VERVIEW 1.2 M... - Page 9 UPC-F12M1-RPLP 3.4.4 M12 Lan Connector ..................20 3.4.5 M12 USB Connector ..................20 3.5 I I/O C ..................21 NTERNAL ONNECTORS 3.5.1 Internal RS-232 Connector (COM1) ............... 22 3.5.2 Internal RS-232/422/485 Connector (COM2) ..........22 3.5.3 Internal LAN Connector .................. 23 3.5.4 Internal CANBUS Connector ................
- Page 10 UPC-F12M1-RPLP 4.3.4 CAN BUS Connector RJ45(CAN2) ..............41 4.3.5 LAN Connector (LAN1/LAN2) ................. 41 4.3.6 Dual USB2.0 Connector (USB1) ..............41 4.3.7 Dual USB 3.2 gen2 Connector (USB2) ............42 4.3.8 Single USB 3.2 gen1 Connector (USB3) ............42 4.3.9 RS232 Connector (RJ45 COM1) ..............43 4.3.10 RS232/422/485 Connector (RJ45 COM2) ..........
-
Page 11: List Of Figures
UPC-F12M1-RPLP List of Figures Figure 1-1: UPC-F12M1-RPLP Panel PC ..................2 Figure 1-2: Front View ........................4 Figure 1-3: Rear View ................... 錯誤! 尚未定義書籤。 Figure 1-4: Dimensions (mm) ......................8 Figure 3-1: SSD Slot Cover Retention Screws ................16 Figure 3-2: Remove SSD Bracket ....................16 Figure 3-3: Secure the M.2 Module .....................17... - Page 12 UPC-F12M1-RPLP List of Tables Table 1-1: Model Variations ......................3 Table 1-2: System Specifications ....................6 Table 3-1: M12 Power Connector Pinouts ..................18 Table 3-2: M12 CANBUS Connector Pinouts ................19 Table 3-3: M12 COM Connector Pinouts ..................19 Table 3-4: M12 Lan Connector Pinouts ..................20 Table 3-5: M12 USB Connector Pinouts ..................20...
- Page 13 UPC-F12M1-RPLP Table 4-17: Power input Connectors (PWR2) Pinouts ..............40 Table 4-18:CAN BUS Connector RJ45 (CAN1) ................40 Table 4-19: CAN BUS Connector RJ45 (CAN2) .................41 Table 4-20:RJ45 LAN Connector (LAN1/LAN2) .................41 Table 4-21: USB 2.0 Connector(USB 2.0) ...................42 Table 4-22: USB 3.2 gen2 Connector (USB2) ................42 Table 4-23: Single USB 3.2 gen1 Connector (USB 3) ..............42...
-
Page 14: Introduction
UPC-F12M1-RPLP Chapter Introduction Page 1... -
Page 15: Overview
Raptor Lake-P powered panel PC with a rich variety of functions and peripherals. The aluminum die-casting design and the IP66 enclosure make the UPC-F12M1-RPLP an ideal system for use in harsh environment. The Intel® Raptor Lake-P Core™ i3-1315URE is a System-on-Chip (SoC) that ensures optimal memory, graphics, and peripheral I/O support. -
Page 16: Model Variations
UPC-F12M1-RPLP 1.2 Model Variations There are several models in the UPC-F12M1-RPLP series. The model numbers and model variations are listed below. Model Processor Touchscreen UPC-F12M1-RPLP-i3/PC/8G-R10 Intel Raptor Lake-P Core™ ® Projected capacitive i3-1315URE Table 1-1: Model Variations 1.3 Features The UPC-F12M1-RPLP features are listed below: ... -
Page 17: Front View
UPC-F12M1-RPLP 1.4 Front View The front side of the UPC-F12M1-RPLP is a panel with a TFT LCD touchscreen surrounded by an aluminum die-casting frame (Figure 1-2). Figure 1-2: Front View 1.5 Rear View The rear side of the UPC-F12M1-RPLP contains VESA mount screw holes. The rear view also provides access for installing M.2 SSD. -
Page 18: System Specifications
UPC-F12M1-RPLP 1.6 System Specifications The technical specifications for the UPC-F12M1-RPLP systems are listed in Table 1-2. Specification UPC-F12M1-RPLP LCD Size 12.1" Max. Resolution 1024 (W) x 768 (H) Brightness (cd/m Contrast Ratio 1000:1 LCD Color 16.7M Pixel Pitch (H x V) (mm) 0.24 x 0.24... -
Page 19: Table 1-2: System Specifications
UPC-F12M1-RPLP Operating Temperature -20ºC ~ 60ºC Storage Temperature -20ºC ~ 70ºC Humidity 10% to 95%@40°C (non-condensing) IP Level Full body IP66 Safety/EMC CE/FCC/UKCA Power Input 9 ~ 36 V Internal I/O Ports 1 x 9V ~ 36 V DC input jack... - Page 20 UPC-F12M1-RPLP WARNING! This equipment complies with CE radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 cm between the radiator and your body. 5G WiFi alerts and restricted country codes The device is restricted to indoor use only when operating in the 5150 to 5350 MHz frequency range.
-
Page 21: Dimensions
UPC-F12M1-RPLP 1.7 Dimensions The dimensions of the UPC-F12M1-RPLP are shown below. Figure 1-4: Dimensions (mm) Page 8... -
Page 22: Unpacking
UPC-F12M1-RPLP Chapter Unpacking Page 9... -
Page 23: Unpacking
If any of the components listed in the checklist below are missing, do not proceed with the installation. Contact the IEI reseller or vendor the UPC-F12M1-RPLP was purchased from or contact an IEI sales representative directly by sending an email to sales@ieiworld.com. -
Page 24: Optional Items
UPC-F12M1-RPLP The UPC-F12M1-RPLP panel PC is shipped with the following components: Quantity Item Image UPC-F12M1-RPLP panel PC 2 meter M12 power cable 3 meter M12 to USBx2 cable 2.3 Optional Items The following are optional components which may be separately purchased:... - Page 25 UPC-F12M1-RPLP Item and Part Number Image CANBUS M12 cable (P/N: 32005-006600-100-RS) COM M12 cable (P/N: 32005-006500-100-RS) LAN M12 cable (P/N: 32013-007400-100-RS) Wall Mount Kit (P/N: AFLWK-19B) Stand for VESA 75/VESA 100 (P/N: STAND-C12-R10) If any of these items are missing or damaged, contact the distributor or sales representative immediately.
-
Page 26: Installation
UPC-F12M1-RPLP Chapter Installation Page 13... -
Page 27: Anti-Static Precautions
Electrostatic discharge (ESD) can cause serious damage to electronic components, including the UPC-F12M1-RPLP. Dry climates are especially susceptible to ESD. It is therefore critical that whenever the UPC-F12M1-RPLP is accessed internally, or any other electrical component is handled, the following anti-static precautions are strictly adhered ... -
Page 28: Installation Precautions
UPC-F12M1-RPLP 3.2 Installation Precautions CAUTION: The UPC-F12M1-RPLP series has more than one power supply connection point. To reduce the risk of electric shock, disconnect all power sources before installing or servicing the UPC-F12M1-RPLP series. When installing the panel PC, please follow the precautions listed below: ... -
Page 29: Ssd Installation
UPC-F12M1-RPLP 3.3 SSD Installation To install the SSD into the system, please follow the steps below: Step 1: Remove the SSD slot cover located on the rear panel by removing the two retention screws. Figure 3-1: SSD Slot Cover Retention Screws Step 2: Pull out the SSD bracket from the system for installing SSD. -
Page 30: Figure 3-3: Secure The M.2 Module
UPC-F12M1-RPLP Step 3: Remove the M.2 retention screw. Slide the M.2 module into the socket at an angle of about 20°. Push the M.2 module down and secure it with a screw. (Figure 3-3). Figure 3-3: Secure the M.2 Module... -
Page 31: M12 I/O Connectors
UPC-F12M1-RPLP 3.4 M12 I/O Connectors Take off M12 connector nut, you can find Pin define of each M12 connector as below. 3.4.1 M12 DC-in Power Connector M12 power coonector is 5 pins M12A MALE connector, pin definitions are described in the table below. -
Page 32: M12 Canbus Connector
UPC-F12M1-RPLP 3.4.2 M12 CANBUS Connector M12 CANBUS connector is 8 pins M12A MALE connector, pin definitions are described in the table below. PIN NO. DESCRIPTION PIN NO. DESCRIPTION CAN_L CAN_H DIO OUT5 Table 3-2: M12 CANBUS Connector Pinouts 3.4.3 M12 COM Connector M12 COM connector is 8 pins M12A MALE connector, pin definitions are described in the table below. -
Page 33: M12 Lan Connector
UPC-F12M1-RPLP 3.4.4 M12 Lan Connector M12 Lan connector is 8 pins M12X MALE connector, pin definitions are described in the table below. PIN NO. DESCRIPTION PIN NO. DESCRIPTION MDX0+ MDX3+ MDX0- MDX3- MDX1+ MDX2- MDX1- MDX2+ Table 3-4: M12 Lan Connector Pinouts 3.4.5 M12 USB Connector... -
Page 34: Internal I/O Connectors
First remove six screws on the cable cover, then take off the cable cover and you will see the internal connectors. Figure 3-4: Cable Cover Screw The UPC-F12M1-RPLP series is equipped with several I/O connectors for peripheral device connection. The pinouts of some of the internal connectors are listed below. Figure 3-5: Internal Connector Definition... -
Page 35: Internal Rs-232 Connector (Com1)
UPC-F12M1-RPLP 3.5.1 Internal RS-232 Connector (COM1) The pinouts for the RS-232 connector (COM1) are listed in the figure and table below. PIN NO. DESCRIPTION PIN NO. DESCRIPTION -NDCD NSOUT -NDSR -NCTS NSIN -NDTR -NRTS -XRI Table 3-6: Internal RS-232 Connector (COM1) Pinouts 3.5.2 Internal RS-232/422/485 Connector (COM2) -
Page 36: Internal Lan Connector
UPC-F12M1-RPLP 3.5.3 Internal LAN Connector The pinouts for the Lan1/2 connector (RJ45) are listed in the figure and table below. PIN NO. DESCRIPTION PIN NO. DESCRIPTION MDI3- MDI1- MDI3+ MDI1+ MDI2- MDI0- MDI2+ MDI0+ Table 3-8: Internal Lan1/2 Connector (RJ45) Pinouts 3.5.4 Internal CANBUS Connector... -
Page 37: Internal Power Connector
UPC-F12M1-RPLP 3.5.5 Internal Power Connector The pinouts for the power terminal pinout is showed in the figure. Figure 3-6: VESA Mounting Retention Screw Holes Page 24... -
Page 38: Mounting The System
100 mm interface pad. The UPC-F12M1-RPLP VESA mount retention screw holes are shown in 錯誤! 找不到參照來 源。. Refer to the installation guide that came with the mounting device to mount the UPC-F12M1-RPLP. -
Page 39: Powering On The System
UPC-F12M1-RPLP 3.7 Powering On the System To power on the UPC-F12M1-RPLP panel PC, follow the steps below: Step 1: Use the attached M12 power cable to connect the M12 power connector to the power source. Figure 3-8: M12 Power Connector Location... -
Page 40: Table 3-11: Power Cable Pinouts
LED lights up in green to power up the system. In AT mode, the UPC-F12M1-RPLP will turn on automatically once power is connected to the power connector; short press the power button to turn Step 0: off/on the system. -
Page 41: Power Switch
UPC-F12M1-RPLP 3.8 Power Switch AT or ATX power mode can be selected in UPC. The selection is made through an AT/ATX switch located on the bottom panel. The cable cover have to removed to be able to access the AT/ATX switch. - Page 42 UPC-F12M1-RPLP NOTE: Since the ACC switch is not commonly used, it is off by default. If you need to turn it on, you need to remove the back cover and manually setup the ACC switch, or contact your dealer. NOTE: When the car key is turned to ACC, power has been started.
-
Page 43: Available Drivers
UPC-F12M1-RPLP 3.10 Available Drivers All the drivers for the UPC-F12M1-RPLP are available on IEI Resource Download Center (https://download.ieiworld.com). Type UPC-F12M1-RPLP and press Enter to find all the relevant software, utilities, and documentation. Figure 3-11: IEI Resource Download Center 3.10.1 Driver Download To download drivers from IEI Resource Download Center, follow the steps below. - Page 44 UPC-F12M1-RPLP Step 2: All product-related software, utilities, and documentation will be listed. You can choose Driver to filter the result. Step 3: Click the driver file name “UPC-xxx-RPLP” on the page and you will be prompted with the following window. You can download the entire ISO file, or double click an individual item to find its driver file and click the file name to download.
-
Page 45: Motherboard Interface
UPC-F12M1-RPLP Chapter Motherboard Interface Page 32... -
Page 46: Peripheral Interface Connectors
UPC-F12M1-RPLP 4.1 Peripheral Interface Connectors The UPC-F12M1-RPLP panel PC motherboard comes with a number of peripheral interface connectors and configuration jumpers. The connector locations are shown in Figure 4-1. The Pin 1 locations of the on-board connectors are also indicated in the 930H diagram below. -
Page 47: Internal Peripheral Connectors
Internal peripheral connectors are found on the motherboard and are only accessible when the motherboard is outside of the chassis. The table below shows a list of the peripheral interface connectors on the UPC-F12M1-RPLP’s motherboard. Pinouts of these connectors can be found in the following sections. -
Page 48: Bios Programmer Connector (J_Spi1)
UPC-F12M1-RPLP Reset BTN Connector 2-pin wafer RST1 HDD LED Connector 2-pin wafer HDD_LED1 CPU FAN Connector 4-pin wafer CPU_FAN1 Panel Inverter Connector 5-pin wafer J_INV1 Power LED / Power BTN Connector 5-pin wafer PWR_BTN1 Heater Power Connector 2-pin wafer J_HEATER1... -
Page 49: Debug Connector (Dbg_Port1)
UPC-F12M1-RPLP 4.2.2 Debug Connector (DBG_PORT1) PIN NO. DESCRIPTION PIN NO. DESCRIPTION VCC5V SMCLK_EC SMDAT_EC RST# Table 4-3: Debug Connector (DBG_PORT1) 4.2.3 EC Programmer Connector (EC_FLASH1) PIN NO. DESCRIPTION EC_FLASH_DAT EC_FLASH_CLK Table 4-4: EC Programmer Connector (EC_FLASH1) 4.2.4 Flash Descriptor Security Override (ME_FLASH1) PIN NO. -
Page 50: Reset Btn Connector (Rst1)
UPC-F12M1-RPLP 4.2.6 Reset BTN Connector (RST1) PIN NO. DESCRIPTION RST+ Table 4-7: Reset BTN Connector (RST1) 4.2.7 HDD LED Connector (HDD_LED11) PIN NO. DESCRIPTION HDD_LED+ HDD_LED- Table 4-8: HDD LED Connector (HDD_LED11) 4.2.8 CPU FAN Connector (CPU_FAN1) PIN NO. DESCRIPTION... -
Page 51: Power Led / Power Btn Connector (Pwr_Btn1)
UPC-F12M1-RPLP 4.2.10 Power LED / Power BTN Connector (PWR_BTN1) PIN NO. DESCRIPTION PW_LED+ PWR_BTN Table 4-11: Power LED / Power BTN Connector (PWR_BTN1) 4.2.11 Heater Power Connector Connector (J_HEATER1) PIN NO. DESCRIPTION Table 4-12: Heater Power Connector Connector (J_HEATER1) 4.2.12 RFID Connector (J_RFID1) PIN NO. -
Page 52: External Interface Panel Connectors
UPC-F12M1-RPLP 4.3 External Interface Panel Connectors The table below lists the rear panel connectors on the motherboard. Pinouts of these connectors can be found in the following sections. Connector Type Label Power input Connector DC Jack PWR1 Power input Connector... -
Page 53: Power Input Connectors (Pwr2)
UPC-F12M1-RPLP PIN NO. DESCRIPTION PIN NO. DESCRIPTION Table 4-16: PWR Connector (PWR1) Pinouts 4.3.2 Power input Connectors (PWR2) PIN NO. DESCRIPTION VCCIN Table 4-17: Power input Connectors (PWR2) Pinouts 4.3.3 CAN BUS Connector RJ45 (CAN1) PIN NO. DESCRIPTION PIN NO. -
Page 54: Can Bus Connector Rj45(Can2)
UPC-F12M1-RPLP 4.3.4 CAN BUS Connector RJ45 (CAN2) PIN NO. DESCRIPTION PIN NO. DESCRIPTION DIO_IN5 CAN_H DIO_IN6 CAN_L Table 4-19: CAN BUS Connector RJ45 (CAN2) 4.3.5 LAN Connector (LAN1/LAN2) PIN NO. DESCRIPTION PIN NO. DESCRIPTION LINK 1000 MDI3+ +3.3V sus MDI0+... -
Page 55: Dual Usb 3.2 Gen2 Connector (Usb2)
UPC-F12M1-RPLP Table 4-21: USB 2.0 Connector(USB 2.0) 4.3.7 Dual USB 3.2 gen2 Connector (USB2) PIN NO. DESCRIPTION PIN NO. DESCRIPTION USB_DATA- USB_DATA- USB_DATA+ USB_DATA+ USB3_RX- USB3_RX- USB3_RX+ USB3_RX+ USB3_TX- USB3_TX- USB3_TX+ USB3_TX+ Table 4-22: USB 3.2 gen2 Connector (USB2) 4.3.8 Single USB 3.2 gen1 Connector (USB3) PIN NO. -
Page 56: Rs232 Connector (Rj45 Com1)
UPC-F12M1-RPLP 4.3.9 RS232 Connector (RJ45 COM1) PIN NO. DESCRIPTION Table 4-24: RS232 Connector (RJ45 COM1) 4.3.10 RS232/422/485 Connector (RJ45 COM2) PIN NO. DESCRIPTION Table 4-25: RS232/422/485 Connector (RJ45 COM2) Page 43... -
Page 57: Regulatory Compliance
UPC-F12M1-RPLP Appendix Regulatory Compliance Page 44... - Page 58 UPC-F12M1-RPLP DECLARATION OF CONFORMITY This equipment is in conformity with the following EU directives: EMC Directive 2014/53/EU Low-Voltage Directive 2014/35/EU RoHS II Directive 2015/863/EU If the user modifies and/or install other devices in the equipment, the CE conformity declaration may no longer apply.
- Page 59 UPC-F12M1-RPLP Ελληνική [Greek] IEI Integration Corp ΔΗΛΩΝΕΙ ΟΤΙ ΕΞΟΠΛΙΣΜΟΣ ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ2014/53/EU. Français [French] IEI Integration Corp déclare que l'appareil est conforme aux exigences essentielles et aux autres dispositions pertinentes de la directive 2014/53/EU.
- Page 60 UPC-F12M1-RPLP Slovensko [Slovenian] IEI Integration Corp izjavlja, da je ta opreme v skladu z bistvenimi zahtevami in ostalimi relevantnimi določili direktive 2014/53/EU. Slovensky [Slovak] IEI Integration Corp týmto vyhlasuje, že zariadenia spĺňa základné požiadavky a všetky príslušné ustanovenia Smernice 2014/53/EU.
- Page 61 UPC-F12M1-RPLP commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.
-
Page 62: Safety Precautions
UPC-F12M1-RPLP Appendix Safety Precautions Page 49... -
Page 63: General Safety Precautions
Do not apply voltage levels that exceed the specified voltage range. Doing so may cause fire and/or an electrical shock. Electric shocks can occur if the UPC-F12M1-RPLP chassis is opened when it is running. If considerable amounts of dust, water, or fluids enter the device, turn off the power supply immediately, unplug the power cord, and contact the UPC-F12M1-RPLP vendor. - Page 64 Electrostatic discharge (ESD) can cause serious damage to electronic components, including the UPC-F12M1-RPLP. Dry climates are especially susceptible to ESD. It is therefore critical that whenever the UPC-F12M1-RPLP is opened and any of the electrical components are handled, the following anti-static precautions are strictly adhered to.
-
Page 65: Product Disposal
UPC-F12M1-RPLP B.1.3 Product Disposal CAUTION: Risk of explosion if battery is replaced by an incorrect type. Only certified engineers should replace the on-board battery. Dispose of used batteries according to instructions and local regulations. Outside the European Union–If you wish to dispose of used electrical and electronic products outside the European Union, please contact your local authority so as to comply with the correct disposal method. -
Page 66: Maintenance And Cleaning Precautions
Some components in the UPC-F12M1-RPLP may only be cleaned using a product specifically designed for the purpose. In such case, the product will be explicitly mentioned in the cleaning tips. Below is a list of items to use when cleaning the UPC-F12M1-RPLP. ... - Page 67 UPC-F12M1-RPLP Water or rubbing alcohol–A cloth moistened with water or rubbing alcohol can be used to clean the device. Using solvents–The use of solvents is not recommended when cleaning the device as they may damage the plastic parts.
- Page 68 UPC-F12M1-RPLP Appendix Hazardous Materials Disclosure Page 55...
- Page 69 UPC-F12M1-RPLP C.1 RoHS II Directive (2015/863/EU) The details provided in this appendix are to ensure that the product is compliant with the RoHS II Directive (2015/863/EU). The table below acknowledges the presences of small quantities of certain substances in the product, and is applicable to RoHS II Directive (2015/863/EU).
- Page 70 UPC-F12M1-RPLP C.2 China RoHS 此附件旨在确保本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符 合中国 RoHS 标准规定的限量要求。 本产品上会附有”环境友好使用期限”的标签，此期限是估算这些物质”不会有泄漏或突变”的 年限。本产品可能包含有较短的环境友好使用期限的可替换元件，像是电池或灯管，这些元 件将会单独标示出来。 部件名称 有毒有害物质或元素 壳体 显示 印刷电路板 金属螺帽 电缆组装 风扇组装 电力供应组装 电池 O: 表示该有毒有害物质在该部件所有物质材料中的含量均在 SJ/T11364-2014 與 GB/T26572-2011 标准规定的限量要求以下。 X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T11364-2014 與 GB/T26572-2011 标准规定的限量要求。 Page 57...
