RTD Embedded Technologies IM35100HR
Mini-PCI Express Card Carrier Module
A l l t r a d e m a r k s , b r a n d n a m e s , a n d b r a n d s a p p e a r i n g h e r e i n a r e t h e p r o p e r t y o f t h e i r r e s p e c t i v e o w n e r s .
• C r i t i c a l a n d e x p e d i t e d s e r v i c e s
• I n s t o c k / R e a d y - t o - s h i p
Artisan Scientific Corporation dba Artisan Technology Group is not an affiliate, representative, or authorized distributor for any manufacturer listed herein.
In Stock
Used and in Excellent Condition
Open Web Page
https://www.artisantg.com/96279-1
• We b u y y o u r e x c e s s , u n d e r u t i l i z e d , a n d i d l e e q u i p me n t
• F u l l - s e r v i c e , i n d e p e n d e n t r e p a i r c e n t e r

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IM25100HR and is the answer not in the manual?

Questions and answers

Related Manuals for rtd IM25100HR

Summary of Contents for rtd IM25100HR

  • Page 1 RTD Embedded Technologies IM35100HR Mini-PCI Express Card Carrier Module In Stock Used and in Excellent Condition Open Web Page https://www.artisantg.com/96279-1 A l l t r a d e m a r k s , b r a n d n a m e s , a n d b r a n d s a p p e a r i n g h e r e i n a r e t h e p r o p e r t y o f t h e i r r e s p e c t i v e o w n e r s .
  • Page 2 IM25100HR IM35100HR Mini-PCI Express Card Carrier Module User’s Manual BDM-610020086 Rev. D RTD Embedded Technologies, Inc. AS9100 and ISO 9001 Certified...
  • Page 3 RTD Embedded Technologies, Inc. 103 Innovation Boulevard State College, PA 16803 USA Telephone: 814-234-8087 Fax: 814-234-5218 www.rtd.com sales@rtd.com techsupport@rtd.com...

  • Page 4: Revision History

    Failure to follow the instructions found in this manual may result in damage to the product described in this manual, or other components of the system. The procedure set forth in this manual shall only be performed by persons qualified to service electronic equipment. Contents and specifications within this manual are given without warranty, and are subject to change without notice. RTD Embedded Technologies, Inc. shall not be liable for errors or omissions in this manual, or for any loss, damage, or injury in connection with the use of this manual.

  • Page 5: Table Of Contents

    Connector and Jumper Functionality ............................12 3.5.1 Bus Connectors PCIe Connectors (CN1 – Top, CN2 - Bottom) PCI Connector (CN3) - IM25100HR only 3.5.2 Internal and External I/O Connectors Mini PCI Express Sockets A and B (CN6, CN7) MCX Connectors (CN5, CN9, CN10, CN11, CN13, CN15)
  • Page 6 Figure 2: Example 104™Stack ....................................10 Figure 3: Board Connections ....................................11 Figure 4: IM25100HR Block Diagram ..................................12 Figure 5: SIM Card Socket (U5) for Slot B................................16 Figure 6: IM25410HR Link Repopulation Diagram (I/O Connectors Not Shown) ....................17 Figure 7: IDAN Dimensions –...

  • Page 7: Introduction

    Card, Mini PCIe, mPCIe, and PEM) is a form factor for devices which supports both PCI Express and USB 2.0 connectivity. An onboard PCIe Gen 2 switch provides a x1 PCI Express connection to each of the dual sockets on the IM25100HR and IM35100HR, using only one upstream x1 PCI Express link from the bus.

  • Page 8: Ordering Information

    If you are having problems with you system, please try the steps in the Troubleshooting section of this manual. For help with this product, or any other product made by RTD, you can contact RTD Embedded Technologies technical support via the...

  • Page 9: Specifications

    Board Electrical Characteristics The bus connectors on the IM25100HR and IM35100HR offer several voltage inputs. Only +5V is required for operation, and is used to generate the voltage requirements for both Mini PCI Express sockets. All other bus connector supply voltages are pass-through and unused by the IM25100HR and IM35100HR.

  • Page 10: Pci Express Mini Card Operating Conditions

    Installing third party Mini PCI Express modules on the IM25100HR can affect the overall operating temperature of the system. Make sure to verify the operating conditions of third party Mini PCI Express modules before using the IM25100HR in extreme conditions.

  • Page 11: Board Connections And Functionality

    10. Attach any necessary cables to the PC/104 stack. 11. Re-connect the power cord and apply power to the stack. 12. Boot the system and verify that all of the hardware is working properly. Figure 2: Example 104™Stack | www.rtd.com IM25100HR User’s Manual RTD Embedded Technologies, Inc.

  • Page 12: Connector And Jumper Locations

    The tables in this section list designator callouts for the various functions of the bus connectors, I/O connectors, and jumpers found on the IM25100HR and IM35100HR. Also included are the size and pitch of each connector as well as mating connector information. The following top-side photo provides a reference for designators and their locations.

  • Page 13: Functional Diagram

    PCIe Connectors (CN1 – Top, CN2 - Bottom) The IM25100HR is a “Universal” board, and can connect to either a Type 1 or Type 2 connector of a PCIe/104 or PCI-104 Express system. The position and pin assignments are compliant with the PCI/104-Express Specification. (See PC/104 Specifications on page 23) PCI Connector (CN3) - IM25100HR only The PCI connector is the connection to PCI peripheral modules.

  • Page 14: Internal And External I/O Connectors

    ONNECTORS The IM25100HR offers two sockets for installing a third party Mini PCI Express module, Socket A (CN6) and Socket B (CN7). For each socket, three onboard U.FL antennae connectors are offered to easily bring out any connections from the installed module to the IM25100HR, allowing the user to easily interface to these connections using a rugged MCX connector.

  • Page 15: Mini Pci Express Sockets A And B (Cn6, Cn7)

    The IM25100HR offers two soldered-down connectors that support third party Mini PCI Express modules. Sockets A and B on the IM25100HR (or designators CN6 and CN7) each offer one downstream x1 PCI Express Gen 2 link and one downstream USB 2.0 link from the host cpuModule to the Mini PCI Express device installed in the socket. For maximum flexibility, the IM25100HR provides mounting holes for cards designed to both the Full-Mini and Half-Mini card Mini PCI Express form factors.

  • Page 16: Led Status Indicators And Socket W_Disable# Inputs (Cn4)

    For more information, refer to the PCI Express Mini Card Electromechanical specification. CN4 is a 2x8 0.1” DIL connector. Pin 1 is indicated with a square solder pad. Pins are numbered as follows. | www.rtd.com IM25100HR User’s Manual RTD Embedded Technologies, Inc.

  • Page 17: User Identity Module Connection For Slot A (Cn20)

    SIM card. As an alternative to the SIM card socket, the board may be built with a 2x5 0.1” DIL connector (CN21). The standard board configuration comes with U5 installed and CN21 not populated. Contact RTD if you are interested in changing this configuration. The pinout of CN21 matches CN20.

  • Page 18: Repopulation Of Pci Express And Usb Links

    Repopulation of PCI Express and USB Links The Mini PCI Express sockets on the IM25100HR each operate using a x1 PCI Express link and/or USB 2.0 link. To relieve some of the stress on the system, the IM25100HR has an onboard PCI-Express Gen 2 switch and a USB 2.0 hub to generate these links, reducing the number of resources needed from the host cpuModule for the IM25100HR to operate.

  • Page 19: Idan Connections

    Dimensions: 152.0 mm L x 130.0 mm W x 17.0 mm H (5.98 in L x 5.12 in W x 0.67 in H) Figure 7: IDAN Dimensions – L x W x H | www.rtd.com IM25100HR User’s Manual RTD Embedded Technologies, Inc.

  • Page 20: External I/O Connectors

    For improved signal transmission, six SMA connectors on the IDAN frame (labeled: 1, 2, 3, 4, 5, 6) allow the user to connect external antennae to GSM, GPS, and/or Wi-Fi Mini PCIe modules installed on the IM25100HR and IM35100HR. This connection is accomplished via the onboard MCX connectors (CN5, CN9, CN10, CN11, CN13, CN15).

  • Page 21: Led Status Indicators And Socket W_Disable# Inputs

    W_DISABLE# input, see page 15. The pin mapping of the 15-pin DSUB connector to connector CN4 on the IM25100HR and IM35100HR is shown in the following table: Table 12: IDAN Pinout of LED Status and W_DISABLE# Connector (CN4)

  • Page 22: Steps For Installing

    10. Attach any necessary cables to the IDAN system. 11. Re-connect the power cord and apply power to the stack. 12. Boot the system and verify that all of the hardware is working properly. Figure 10: Example IDAN System | www.rtd.com IM25100HR User’s Manual RTD Embedded Technologies, Inc.

  • Page 23: Troubleshooting

    If problems persist, or you have questions about configuring this product, contact RTD Embedded Technologies via the following methods: Phone: +1-814-234-8087 E-Mail: techsupport@rtd.com Be sure to check the RTD web site (http://www.rtd.com) frequently for product updates, including newer versions of the board manual and application software. | www.rtd.com IM25100HR User’s Manual RTD Embedded Technologies, Inc.

  • Page 24: Additional Information

    PCI Express Mini Card Electromechanical Specification A copy of the latest PCI Express Mini Card Electromechanical Specification can also be found on the webpage for the PCI Special Interest Group: www.pcisig.com | www.rtd.com IM25100HR User’s Manual RTD Embedded Technologies, Inc.

  • Page 25: Limited Warranty

    During the one year warranty period, RTD Embedded Technologies will repair or replace, at its option, any defective products or parts at no additional charge, provided that the product is returned, shipping prepaid, to RTD Embedded Technologies. All replaced parts and products become the property of RTD Embedded Technologies.
  • Page 26 RTD Embedded Technologies, Inc. 103 Innovation Boulevard State College, PA 16803 USA Telephone: 814-234-8087 Fax: 814-234-5218 www.rtd.com sales@rtd.com techsupport@rtd.com Copyright 2016 by RTD Embedded Technologies, Inc. All rights reserved.
