- Page 1 LAN24710/LAN34710 PCI/104-Express Dual 10Gb/s Fiber Ethernet Controller User’s Manual BDM-610020157 Rev. A RTD Embedded Technologies, Inc. AS9100 and ISO 9001 Certified...
- Page 2 RTD Embedded Technologies, Inc. 103 Innovation Boulevard State College, PA 16803 USA Telephone: 814-234-8087 Fax: 814-234-5218 www.rtd.com sales@rtd.com techsupport@rtd.com...
- Page 3 Failure to follow the instructions found in this manual may result in damage to the product described in this manual, or other components of the system. The procedure set forth in this manual shall only be performed by persons qualified to service electronic equipment. Contents and specifications within this manual are given without warranty, and are subject to change without notice. RTD Embedded Technologies, Inc. shall not be liable for errors or omissions in this manual, or for any loss, damage, or injury in connection with the use of this manual.
-
Page 4: Table Of Contents
Fiber Ethernet Connection ................................ 16 5.2.1 Intel X710 10 Gigabit Ethernet Controller 5.2.2 SFP+ Sockets Driver Support ................................... 17 Troubleshooting Additional Information PC/104 Specifications ................................19 PCI and PCI Express Specification ............................19 Limited Warranty | www.rtd.com BRG2110 User’s Manual RTD Embedded Technologies, Inc. - Page 5 Figure 4: IDAN Dimensions ....................................13 Figure 5: IDAN Front Panel Connectors ................................. 14 Figure 7: Example IDAN System .................................... 15 Figure 7: LAN24710/34710 Block Diagram ................................16 Table of Tables Table 1: Ordering Options ......................................6 Table 2: Operating Conditions ....................................8 Table 3: Electrical Characteristics ....................................
-
Page 6: Introduction
Ethernet connections using a single integrated controller chip. Fiber connectivity is provided by standard SFP+ modules (specific modules listed below have been validated by RTD to work with the LAN24710 and LAN34710). These boards run completely off of the PCI Express bus, utilizing Intel’s X710 10 Gigabit Ethernet controller. -
Page 7: Contact Information
If you are having problems with your system, please try the steps in the Troubleshooting section of this manual. For help with this product, or any other product made by RTD, you can contact RTD Embedded Technologies technical support via the following methods:... -
Page 8: Specifications
= 5.0V 5V Input Supply Current Active 1.02 PCIe/104 Bus Differential Output Voltage DC Differential TX Impedance Ω Differential Input Voltage 0.175 DC Differential RX Impedance Ω Electrical Idle Detect Threshold | www.rtd.com BRG2110 User’s Manual RTD Embedded Technologies, Inc. -
Page 9: Board Connection
Physical Characteristics • Weight: Approximately 158.76 g (0.35 lbs.) • Dimensions: 90.17 mm L x 95.89 mm W (3.550 in L x 3.775 in W) Figure 1: Board Dimensions | www.rtd.com BRG2110 User’s Manual RTD Embedded Technologies, Inc. -
Page 10: Connectors And Jumpers
Connectors and Jumpers CN16: PCI Connector *Not Populated on the LAN34710* CN4: Fiber Transceiver CN7: Link/Activity LED Connector CN6: Fiber Transceiver CN1 & CN2: PCIe Connector | www.rtd.com BRG2110 User’s Manual RTD Embedded Technologies, Inc. -
Page 11: External I/O Connectors
The PCIe connector is the connection to the system CPU. The position and pin assignments are compliant with the PCI/104-Express Specification. (See PC/104 Specifications on page 19) The LAN24710/34710 is a Type 2 board, and can connect only to Type 2 PCIe/104 connector. | www.rtd.com BRG2110 User’s Manual... -
Page 12: Steps For Installing
10. Attach any necessary cables to the PC/104 stack. 11. Re-connect the power cord and apply power to the stack. 12. Boot the system and verify that all of the hardware is working properly. Figure 2: Example PC/104 Stacks | www.rtd.com BRG2110 User’s Manual RTD Embedded Technologies, Inc. -
Page 13: Idan Connections
Weight: Approximately 0.453 Kg (1 lbs.) • Dimensions: 152.0 mm L x 130.0 mm W x 17.0mm H (5.98 in L x 5.12 in W x 0.67 in H) Figure 3: IDAN Dimensions | www.rtd.com BRG2110 User’s Manual RTD Embedded Technologies, Inc. -
Page 14: External I/O Connectors
XTERNAL ONNECTORS The Diagram below shows the connector locations for the transceivers of the LAN24710 as they are brought out on the front panel of the IDAN-LAN24710. For more information on of each connector on the LAN24710, refer to section 5.2 “Fiber Ethernet Connection”... -
Page 15: Steps For Installing
10. Attach any necessary cables to the IDAN system. 11. Re-connect the power cord and apply power to the stack. 12. Boot the system and verify that all of the hardware is working properly. Figure 5: Example IDAN System | www.rtd.com BRG2110 User’s Manual RTD Embedded Technologies, Inc. -
Page 16: Functional Description
Functional Description Block Diagram The Figure below shows the functional block diagram of the LAN24710/34710. The various parts of the block diagram are discussed in the following sections. SFP+ socket PCIe x4 Intel X710-BM2 Ethernet controller SFP+ socket Link/Speed/Activity LED connector... -
Page 17: Driver Support
The Intel® X710 Ethernet Controller uses open firmware designed to optimize compatibility with compliant SFP+ modules. RTD has validated board operation with the following modules: • Intel e10gsfpsr (0-70°C, SR module) • Intel e10gsfplr (0-70°C, LR module) • Netgear AXM761 (0-70°C, SR module) Driver Support The Ethernet controller is supported by a driver provided by Intel, but only in Windows Server Editions. -
Page 18: Troubleshooting
If problems persist, or you have questions about configuring this product, contact RTD Embedded Technologies via the following methods: Phone: +1-814-234-8087 E-Mail: techsupport@rtd.com Be sure to check the RTD web site (http://www.rtd.com) frequently for product updates, including newer versions of the board manual and application software. | www.rtd.com BRG2110 User’s Manual RTD Embedded Technologies, Inc. -
Page 19: Additional Information
A copy of the latest PC/104 specifications can be found on the webpage for the PC/104 Consortium: www.pc104.org PCI and PCI Express Specification A copy of the latest PCI and PCI Express specifications can be found on the webpage for the PCI Special Interest Group: www.pcisig.com | www.rtd.com BRG2110 User’s Manual RTD Embedded Technologies, Inc. -
Page 20: Limited Warranty
RTD Embedded Technologies, Inc. warrants the hardware and software products it manufactures and produces to be free from defects in materials and workmanship for one year following the date of shipment from RTD Embedded Technologies, Inc. This warranty is limited to the original purchaser of product and is not transferable. - Page 21 RTD Embedded Technologies, Inc. 103 Innovation Boulevard State College, PA 16803 USA Telephone: 814-234-8087 Fax: 814-234-5218 www.rtd.com sales@rtd.com techsupport@rtd.com Copyright 2020 by RTD Embedded Technologies, Inc. All rights reserved.
