We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this royce 60 in. hall tree. We strive
to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home
Item #1008665151
Model #SK18905R4-PW-1
Item #1008665152
Model # SK18905R4-PW-2
USE AND CARE GUIDE
ROYCE 60 in. HALL TREE
Questions, problems, missing parts? Before returning to the store,
call Home Decorators Collection Customer Service.
8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-800-986-3460
HOMEDEPOT.COM/HOMEDECORATORS
improvement needs. Thank you for choosing Home Decorators Collection!
Item #1008658734
Model # SK18905R4-SB-1
Item #1008658733
Model # SK18905R4-SB-2
THANK YOU
Item #1008675050
Model # SK18905R4-BK-1
Item #1008675051
Model # SK18905R4-BK-2
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Home Decorators Collection ROYCE SK18905R4-PW-1
Summary of Contents for Home Decorators Collection ROYCE SK18905R4-PW-1
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this royce 60 in. hall tree. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home...
-
Page 2: Table Of Contents
Table of Contents Table of Contents ............2 Pre-assembly (continued) ..........4 Safety Information ............2 Package Contents ..............4 Warranty ................. 2 Assembly Note .................5 3 Year Warranty ...............2 Touble Shooting ...............5 What is Covered ...............2 ... -
Page 3: Pre-Assembly
Pre-assembly PLANNING ASSEMBLY Keep children and pets away from build area. Make sure your area is large enough to unpack, sort and assemble the unit. TOOLS REQUIRED Large head Small head Phillips Phillips screwdriver screwdriver HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity... -
Page 4: Pre-Assembly (Continued)
Pre-assembly (continued) PACKAGE CONTENTS Part Description Quantity Part Description Quantity Top panel Adjustable shelf Top left side panel Bottom middle fixed panel Top right side panel Bottom divider Small left partition Bottom partition Small right partition Bottom panel Bottom side panel Top left side door Large left partition Top right side door... -
Page 5: Assembly Note
Pre-assembly (continued) ASSEMBLY NOTE Upon opening, thoroughly clean all wood surfaces to remove dust and dirt that may have settled onto the finish during shipment. In order to prevent damage during assembly, Please assemble this item with at least two people. NOTE: Turn the cam-bolt screws until they are tight, the shoulder should be against the surface of the part. - Page 6 Pre-assembly (continued) We strongly urge a minimum of three or more people for assembly. The assembly of this elegant piece consists of complex steps that require multiple assemblers for proper part alignment. Additional assistance would greatly increase the chance of a smooth assembly process and reduce the chance for assembly related damages. ...
-
Page 7: Assembly
Assembly Attaching the magnet and pothook □ a) Attach magnet (g) to panels (N), (O) and braces (I) and (J) with screw (h) as shown. □ b) Attach pothook (j) to cross brace (M) with screw (i) as shown. HOMEDEPOT.COM/HOMEDECORATORS Please contact 1-800-986-3460 for further assistance. - Page 8 Assembly (continued) Attaching the small right partition the top middle fixed panel □ □ a) Install bolt (b) into partition (E). c) Join partition (E) to the panel (L) with dowel (a). □ b) Insert lock (c) into panel (L). □...
- Page 9 Assembly (continued) Attaching the small left partition and cross brace □ □ a) Install bolt (b) into partition (D). c) Join partition (D), brace (K) and (M) to the panel (L) and partition (E) with dowel (a). □ □ b) Insert lock (c) into panel (L). d) Tighten bolt (b) with lock (c) in the pre-drilled holes.
- Page 10 Assembly (continued) Attaching the top side panel, left side cross brace and right cross brace □ a) Join panel (B) and brace (J) to the partition (D) with dowel (a). □ b) Join panel (C) and brace (I) to the partition (E) with dowel (a).
- Page 11 Assembly (continued) Attaching the fixed panel □ a) Join panel (N) to the panel (B) and partition (D) with dowel (a). □ b) Join panel (O) to the panel (C) and partition (E) with dowel (a). □ c) Tighten panels (N) and (O) with screw (f). HOMEDEPOT.COM/HOMEDECORATORS Please contact 1-800-986-3460 for further assistance.
- Page 12 Assembly (continued) Attaching the top panel □ □ a) Install bolt (b) into panel (A). c) Join panel (A) to the assembled body with dowel (a). □ b) Insert lock (c) into panels (B) and (C), partitions (D) and □ d) Tighten bolt (b) with lock (c) in the pre-drilled holes.
- Page 13 Assembly (continued) Assembling the bottom partition and bottom divider □ Insert the bottom partition (S) into the bottom divider (R) as shown. HOMEDEPOT.COM/HOMEDECORATORS Please contact 1-800-986-3460 for further assistance.
- Page 14 Assembly (continued) Attaching the bottom middle fixed □ c) Join panel (Q) to the partition (S) with dowel (a). panel □ a) Install bolt (b) into panel (Q). □ □ d) Tighten bolt (b) with lock (c) in the pre-drilled holes. b) Insert lock (c) into partition (S).
- Page 15 Assembly (continued) Attaching the large right partition □ □ a) Install bolt (b) into partition (H). c) Join partition (H) to the assembled body with dowel (a). □ b) Insert lock (c) into panels (Q) and (R). □ d) Tighten bolt (b) with lock (c) in the pre-drilled holes. ARROW HOMEDEPOT.COM/HOMEDECORATORS Please contact 1-800-986-3460 for further assistance.
- Page 16 Assembly (continued) Attaching the large left partition □ □ a) Install bolt (b) into partition (G). c) Join partition (G) to the assembled body with dowel (a). □ b) Insert lock (c) into panels (Q) and (R). □ d) Tighten bolt (b) with lock (c) in the pre-drilled holes. ARROW...
- Page 17 Assembly (continued) □ c) Join panel (T) to the assembled body with dowel (a). Attaching the bottom panel Join panel (F) to the panel (T) with dowel (a). □ a) Install bolt (b) into panel (T). □ □ b) Insert lock (c) into panel (F), partitions (G), (H) and (S). d) Tighten bolt (b) with lock (c) in the pre-drilled holes.
- Page 18 Assembly (continued) Attaching the hutch □ □ a) Install bolt (b) into panels (N) and (O). c) Join panels (N) and (O) to the assembled body with dowel (a). □ b) Insert lock (c) into panel (F), partitions (G) and (H). ARROW □...
- Page 19 Assembly (continued) Attaching the back panel □ Tighten panels (Y), (Z), (AA), (BB) and (CC) to the assembled body with screws (h) and metal plates (k) as shown. HOMEDEPOT.COM/HOMEDECORATORS Please contact 1-800-986-3460 for further assistance.
- Page 20 Assembly (continued) Assembling the adjustable shelf □ Insert shelf supports (o) in desired positions and place shelf (P) on the support.
- Page 21 Assembly (continued) Attaching the door □ a) Attach doors (U), (V), (W) and (X) to the assembled body with screw (i) as shown. NOTE: Metal plate needs to be to the top. □ b) Tighten handle (l) to doors (U), (V), (W) and (X) with bolt (m). NOTE: A helper who can hold the door in position makes the door installation easier.
- Page 22 Assembly (continued) Assembling the cushion □ Place cushion (DD) above the panel (Q).
- Page 23 Assembly (continued) Finalizing the assembly □ Install the anti-tipping hardware as shown. HOMEDEPOT.COM/HOMEDECORATORS Please contact 1-800-986-3460 for further assistance.
- Page 24 Questions, problems, missing parts? Before returning to the store, call Home Decorators Collection Customer Service. 8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday 1-800-986-3460 HOMEDEPOT.COM/HOMEDECORATORS Retain this manual for future use.
