Table 2: Port Status LEDs

LED
RJ-45 Gigabit Ethernet Ports (Ports 1-8)
Link/Activity/Speed
SFP Gigabit Ethernet Ports (Ports 9-10)
(Link/Activity)

Table 3: System Status LEDs

LED
Power
Diag
PoE
Condition Status
On/Flashing Port has established a valid 10/100 Mbps network
Amber connection. Flashing indicates activity.
On/Flashing Port has established a valid 1000 Mbps network
Green connection. Flashing indicates activity.
Off There is no valid link on the port.
On/Flashing Port has established a valid 10 or 100 Mbps network
Amber connection. Flashing indicates activity.
On/Flashing Port has established a valid 1000 Mbps network
Green connection. Flashing indicates activity.
Off There is no valid link on the port.
Condition Status
On Green The unit's internal power supply is operating normally.
Off The unit has no power connected.
On Green The system diagnostic test has completed successfully.
Flashing The system boot up is in progress.
Green
On Amber / The system diagnostic test is in progress.
Flashing
Amber
Off The system diagnostic has completed.
On Amber Powered device connected.
Off No powered device connected.
– 26 –
