Charder MS5980 User Manual

Infant scale
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Infant Scale
USER MANUAL
MS5980
Infant Scale
Please keep the instruction manual at hand and follow instruction for use.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MS5980 and is the answer not in the manual?

Questions and answers

Related Manuals for Charder MS5980

Summary of Contents for Charder MS5980

  • Page 1 Infant Scale USER MANUAL MS5980 Infant Scale Please keep the instruction manual at hand and follow instruction for use.

  • Page 3: Table Of Contents

    CONTENTS Explanation of Graphic Symbols on Label/Packaging ... 4 I. Safety Notes ............. 7 A. General Information ..........7 B. EMC GuidanceandManufacturer's Declaration ..... 10 II. Installation .............. 14 A. Column Installation ..........14 B. Optional Accessories ..........15 C. Using adapter and charging battery ......17 D.

  • Page 4: Explanation Of Graphic Symbols On Label/Packaging

    Explanation of Graphic Symbols on Label/Packaging Meaning Text/Symbol Caution, consult accompanying documents before use Separate collection for waste of electrical and electronic equipment, in accordance with Directive 2002/96/EC. Do not dispose of device with everyday waste Name and address of device manufacturer, and year/country of manufacture Carefully read user manual before installation and usage, and follow instructions for use.
  • Page 5 Device complies with EC directives (verified models only) M: Conformity label in compliance with Directive 2014/31/EU for non-automatic weighing instruments 20: Year in which conformity verification was performed and the CE label was applied. (ex: 16=2016) 0122: Identifier for metrology Notified Body Device is a Class III scale in compliance with Directive 2014/31/EU (verified models only) Name and address of entity importing device (if applicable)
  • Page 6 This user manual is protected by international copyright law. All content is licensed, and usage is subject to written authorization from Charder Electronic Co., Ltd. (hereinafter Charder) Charder is not liable for any damage caused by a failure to adhere to requirements stated in this manual.

  • Page 7: Safety Notes

    I. Safety Notes A. General Information Thank you for choosing this Charder Medical device. It is designed to be easy and straightforward to operate, but if you encounter any problems not addressed in this manual, please contact your local Charder service partner.

  • Page 8: General Handling

    (b) Minimum knowledge: - To be able to read at a high-school level and understand Arabic numerals (e.g. 1, 2, 3, 4...) - Basic hygiene knowledge - Trained in device's operation - Read the instruction manual (c) Language - Able to read the language of instruction manual and on-screen instructions (d) Qualifications - No special certifications or qualifications required...
  • Page 9 Charder service partner, using original Charder accessories and spare parts. Charder is not liable for any damages arising from improper maintenance or usage. Dismantlement of the device will void the warranty.

  • Page 10: Emc Guidanceandmanufacturer's Declaration

    B. EMC GuidanceandManufacturer's Declaration Guidance and manufacturer’s declaration-electromagnetic emissions The product isintended for use in the electromagnetic environment specified below. The customer or the user of the product should assure that it is used in such an environment. Electromagnetic Emission test Compliance environment-guidance RF emissions...
  • Page 11 Guidance and manufacturer’s declaration-electromagnetic immunity The product is intended for use in the electromagnetic environment specified below. The customer or the user of the product should assure that it is used in such an environment. Immunity test IEC 60601 Compliance Electromagnetic test level environment-guidance...
  • Page 12 Guidance and manufacturer’s declaration-electromagnetic immunity Theproduct is intended for use in the electromagnetic environment specified below. The customer or the user of the product should assure that is used in such and environment. Immunity test IEC 60601 test Compliance Electromagnetic level level environment-guidance...
  • Page 13 Recommended separation distance between portable and mobile RF communications equipment and the product The product is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the product can help preventelectromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the product as recommended below, according to the maximumoutput power of the communications equipment.

  • Page 14: Installation

    II. Installation A. Column Installation 1. Attach DP4800 indicator to bracket (1) 2. Align column base with screw holes at bottom of platform (2) 3. Insert and tighten screws (3)

  • Page 15: Optional Accessories

    B. Optional Accessories Assemble digital stadiometer 1. Align stadiometer’s bracket with screw holes on the column and tighten hand knobs (1) 2. Screw brackets onto column, and insert transfer cable into brackets (2) 3. Plug-in stadiometer transfer cable connector into the display (3). 4.
  • Page 16 Assembly completed. Accessories a. Height Stadiometer HM80DT Digital Height Stadiometer ◼ HM80D Digital Height Stadiometer ◼ HM80M Mechanical Height Stadiometer ◼ b. Barcode Scanner AS-9300 Infrared Barcode Scanner ◼...

  • Page 17: Using Adapter And Charging Battery

    C. Using adapter and charging battery The rechargeable battery should be recharged at least once every 3 months, regardless of if the device has been used. Battery can be charged by plugging device's exclusive adapter into AC Connector Port. After a long period in storage (e.g. >3 months), the battery should run a full cycle (charge/discharge) to allow it to restore full capacity.

  • Page 18: Replacing Rechargeable Battery Pack

    D. Replacing Rechargeable Battery Pack 1. Open battery housing cover 2. Accessing batteries 3. Place new battery pack into housing, and insert into indicator...
  • Page 19 4. Close battery housing compartment cover. Turn on power to confirm that battery is correctly installed.

  • Page 20: Indicator

    III. Indicator A. Indicator and Key Functions Key Function POWER: Power on or power off. 2. TARE/ZERO: Reset display to 0.0 kg display. Press and hold for 6 seconds to enter device settings. 3. HOLD: Determine stable weighing value - used when weight is unstable.

  • Page 21: Display Layout

    B. Display layout Quantity of Patient ID data Information PRE-TARE awaiting Nurse ID transfer Wi-Fi Battery status Transfer HOLD Scanner Stable Weight Zero Unit Height Capacity Graduation Definitions Quantity of data awaiting transfer: If device is not connected wirelessly, measurement results will be temporarily stored in device. Once device is connected, operator can press Transfer to send results wirelessly.

  • Page 22: Basic Operation

    IV. Basic Operation 1. Switch on the device using key. The device will automatically perform self-calibration 2. Once "0.0" appears on indicator, device is ready for use NOTE: If "0.0" does not display on indicator, press [TARE/ZERO] key to zero the device. A.

  • Page 23: Weight Measurement

    3. After the phone/tablet/PC is connected to the device, the wireless symbol will change from 4. Device is now ready to send results wirelessly to phone/tablet/PC. 5. Before or after measurement, press the [HOLD] key. "HOLD" will be displayed on the indicator. HOLD must be active, to transfer results. NOTE: by default, patient ID, weight, and height must be filled in to transfer results.
  • Page 24 2. Enter height using numeral keys (ex: to input 170 cm, press 1-7-0-0). Press [CLEAR] key to re-input. NOTE: If digital height rod is attached to device, manual input will be disabled, and height result will be transferred automatically to indicator. 3.
  • Page 25 Input Pre-Tare Value DESCRIPTION EXAMPLE Press [PRE-TARE] key. Input pre-tare weight value, starting from the left Enter pre-tare weight using 0~9 keys. Ex: to pre-tare 5.0 kg of weight, press 0-0-5-0. Ex: to pre-tare 13.5 kg of weight, press 0-1-3-5. Press [Enter] key to confirm the pre-tare weight.
  • Page 26 Save a Pre-Tare value DESCRIPTION EXAMPLE Press and hold [MEMORY] key for 3 seconds. Input the number for this pre-tare setting (between 01-10). Ex: To save memory set 3, press 0-3. Press the weight value box on the screen (marked in the red box to the right) Enter pre-tare weight using 0~9 keys.
  • Page 27 Recall Pre-Tare Value DESCRIPTION EXAMPLE Press [MEMORY] key to toggle between Pre-Tare settings saved in device (between 01-10). NOTE: to add new Pre-Tare value, please press and hold [MEMORY] key for 3 seconds to enter settings (see "Save Pre-Tare value" above) F.
  • Page 28 Recall Pre-Tare Value Press [MEMORY] key to save infant's pre-feeding weight memory. After feeding DESCRIPTION SCREEN Input patient ID. Screen will automatically display previously saved pre-feeding weight. (5.000 kg in this example) *If you need to clear previously saved weight, press and hold [TARE/ZERO] key for 3 seconds.

  • Page 29: Device Setup

    V. Device Setup Press and hold [TARE/ZERO] key for 6 seconds to enter General Setting mode. Press menu options on the touchscreen to adjust settings. Auto Off Time: Instruct device to shut off automatically after a certain period of time. Auto off options: 120 sec / 180 sec / 240 sec / 300 sec / off Backlight: adjust backlight brightness.

  • Page 30: Connecting Scale To Receiving Device

    Date/Time: Set device time. (Format: YYYY/MM/DD HH:M) WiFi: Send results via direct transfer or via network (set Access Point if selected) G-Compensation: Authorized distributor can adjust gravity compensation value (password required) URL Host:Set IP address (ex: 192.168.0.1). Please note that if server is restarted, another IP may be automatically assigned.

  • Page 31: Troubleshooting

    VII. Troubleshooting Before contacting your local Charder distributor for repair service, we recommend considering the following troubleshooting procedures: Self-inspection 1. Device will not power on If battery power is depleted, replace with new batteries ◼ If batteries are not used, check if the power adapter is plugged into ◼...
  • Page 32 Error Messages Error Message Action Please charge battery using adapter, or replace battery Maximum weight exceeded. Reduce weight on platform before attempting measurement If problem persists, please contact distributor Re-calibration may be required. If problem persists, please contact distributor Re-calibration may be required. If problem persists, please contact distributor If problem persists, please contact...

  • Page 33: Product Specifications

    VIII. Product Specifications A. Device Information Model MS5980 Indicator DP4800 (15 kg model) (20 kg model) Capacity 0-6 kg x 2g 0-10 kg x 5g 6-15 kg x 5g 10-20 kg x 10g Weight Measurement Accuracy ±1.5e LCD Screen Color LCD touchscreen...
  • Page 34 B. Power Adapter Standards Warning Only the original adapter should be used with the device. Using an adapter other than the one provided by Charder may cause malfunction. Amp Voltage: 5V/2A Drawing No: CD-AD-00023 DRAWING CE APPROVED TYPE Adapter TYPE VOLTAGE NO.:...
  • Page 35 Notes _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________...

  • Page 36: Declaration Of Conformity

    IX. Declaration of Conformity This product has been manufactured in accordance with the harmonized European standards, following the provisions of the below stated directives: (EU) 2017/745 Regulation on Medical Devices 2014/31/EU Non-automatic Weighing Instruments Directive (OIML models only) RoHS Directive 2011/65/EU and Delegated Directive (EU) 2015/863 Radio Equipment Directive 2014/53/EU (applicable if wireless module is used)
