Manufacturer's Declaration of Conformity
This product has been manufactured in accordance with the harmonized
European standards, following the provisions of the below stated directives:
93/42/EEC as amended by
2007/47/EC
Medical Device Directive
2014/31/EU
Non-automatic Weighing Instruments
Directive
Please see separate document showing on sticker of
device for above CE marking.
Authorized EU Representative:
Manufactured by:
Charder Electronic Co., Ltd.
No.103, Guozhong Rd., Dali Dist.,
Taichung City 412 ,Taiwan (R.O.C.)
CD-IN-1147 [9097N] 04/2019
35
Please keep the instruction manual at hand all the time for future reference.
MS5810/5811
Medical Scale
USER MANUAL
0
