C
ONFIGURING THE
Summary
The Summary page shows a summary of the configuration parameters.
Check ADSL operation mode (WAN), Network Layer Parameters (WAN)
and DHCP parameters are correct.
Parameter
ADSL Operation Mode
(WAN)
ISP
Protocol
VPI/VCI
AAL5 Encapsulation Shows the packet encapsulation type. Go to page 4-21 for
Network Layer
Parameters (WAN)
DNS Server
ISP Parameters
User Name
Password
DHCP Parameters
Function
4-6
B
ADSL R
ARRICADE
Description
The type of ISP you have selected.
Indicates the protocol used.
Virtual Path Identifier (VPI) and Virtual Circuit Identifier
(VCI).
a detailed description.
The IP address of the DNS server.
ISP assigned user name.
The configured password.
Shows the DHCP function is enabled or disabled.
OUTER
