Installing a Splitterless Connection
If you are using a splitterless (G.lite) connection, then your service
provider will attach the outside ADSL line directly to your phone system.
In this case you can connect your phones and computer directly to the
incoming ADSL line, but you will have to add low-pass filters to your
phones as shown below:
Plain Old
Telephone
System (POTS)
Residential
Connection
Point [Network
Interface
Device (NID)]
Figure 2-4. Installing without a Splitter
Voice
Filter
Voice
& Data
Voice
& Data
ADSL Router
Data
or
hub or switch
C
ONNECT THE
Ethernet
S
YSTEM
2-7
