Disable Http Proxy - SMC Networks 7904BRA Manual

C C
ONFIGURING
3. If "Using DHCP Server" is
already selected in the
Configure field, your
computer is already
configured for DHCP. If
not, select this Option.
4. Your new settings are shown on the TCP/IP tab. Verify that your IP
Address is now 192.168.2.xxx, your Subnet Mask is 255.255.255.0 and
your Default Gateway is 192.168.2.1. These values confirm that your
Barricade ADSL Router is functioning.
5. Close the Network window.
Now your computer is configured to connect to the Barricade ADSL
Router.

Disable HTTP Proxy

You need to verify that the "HTTP Proxy" feature of your web browser is
disabled. This is so that your browser can view the Barricade ADSL
Router's HTML configuration pages. The following steps are for Internet
Explorer.
Internet Explorer
1. Open Internet Explorer and click the Stop
button. Click Explorer/Preferences.
2. In the Internet Explorer Preferences window,
under Network, select Proxies.
3-18
