Strata ADVANCEMIG400C Operating Instructions Manual page 3

400A
Max Ouput (MIG)
*Available in
package versions.
Description Details
POWER SOURCE DIMENSIONS (LxWxH) 670 x 250 x 445mm
WEIGHT
23kg
INPUT POWER SUPPLY
400V AC 3 Phase 32A
50/60Hz
INPUT POWER SUPPLY TOLERANCE
+/- 20%
MAXIMUM INPUT CURRENT
30A
GENERATOR CAPACITY
20kVA
MIG CURRENT OUTPUT
40-400A
MIG OUTPUT VOLTAGE
16V-34V
MMA O/C VOLTAGE
67V
MIG DUTY CYCLE 400A@60%
310A@100%
WIRE FEEDING SPEED
2.4-18m/min
MMA CURRENT OUTPUT
10-400A
MMA DUTY CYCLE
400A@60%
310A@100%
TIG CURRENT OUTPUT
10-400A
TIG DUTY CYCLE
400A@60%
310A@100%
4.0
mm
Max Electrode Size
400A Three-Phase
Compact Synergic
MIG/ARC/Lift TIG
Inverter Welder
Powerful 400A high duty cycle output in a compact size - Ideal for heavy duty site work
Can be used as compact unit, or with separate wirefeeder - Ultimate flexibility for every job
Intelligent synergic system - Easily set parameters by material type, wire size and work thickness
Arc air gouging capability
IGBT Module Inverter Technology - Smooth & stable output, increased reliability, high duty cycle
4 Roll Geared Industrial Wire Feed Unit - Powerful and smooth wirefeeding
MIG Waveform (Inductance) Control - Greater control of the arc for smoother welding results
Adjustable secondary settings such as pre flow, post flow, burn back and soft start - Greater control for
MIG welding operation
2T/4T/ Bi - Level, Spot Weld Trigger Modes
Lift TIG operation with down slope and remote current control ability
Spool Gun Ready
Production tested with 550V - Extreme stress testing in production for rugged reliability.
Intelligent Protection System - Temperature, voltage and current sensors for increased reliability & safety
Generator Friendly - Designed to work with generator power supply and protect from power surges.
Phase Loss Protection - Machine automatically shuts down if power supply phase loss occurs, to prevent damage.
Power Source Wind Tunnel Cooling Construction - Protection against environmental contamination
Quick connect inlet gas fitting - Tool-less easy connection of gas supply to machine
Description
TIG SYSTEM
MIG DRIVE ROLLERS
INSULATION CLASS
MIG WIRE SPOOL SIZE
POWER EFFICIENCY
POWER FACTOR
STANDARDS
WARRANTY
www.strata.co.nz
ADVANCEMIG400C
32A
400V
THREE-PHASE
Includes:
Details
Internal Solenoid
Gas Control, Lift Ignition
0.6/0.8/0.9/1.0/1.2mm V Groove
0.8/0.9/1.0/1.2mm Knurled
0.8/1.0/1.2mm U Grooved
IP23
D200/D300, 5KG/15KG
80%
0.7
AS/ IEC60974-1:2012
48 Months
ADVANCEMIG400C
400A
MIG
ARC
TIG
5m 2m QC Gas Hose Kit
Arc Lead
Wire Drive Rollers
5m
2x 0.8/0.9mm V Groover
Earth Lead
2x 1.0/1.2mm V Groove
2x 1.2/1.6mm Flux Cored
Strata professional
MT360 4m MIG Torch
32A 400V 3 Phase
Supply Plug
2-Stage Flowmeter
Argon Gas Regulator
& Adapter
User guide, specs, videos
