- Page 1 EZIMIG 205 / ADVANCEMIG 255 MULTI-PROCESS MIG WELDER OPERATING INSTRUCTIONS ADVANCEMIG 255 only www.strata.co.nz...
-
Page 2: Table Of Contents
MMA Welding.................7 Installation and Setup for MMA (Stick Welding)......7 MIG Welding................8 Installation and Setup for MIG Welding........8 EZIMIG 205 Synergic MIG Program Chart.......9 ADVANCEMIG 255 Synergic MIG Program Chart....9 MIG Welding Manual Selection..........11 Save and Recall User Set Welding Parameters.......13 Gasless Welding Setip and Operation........13... - Page 3 EZIMIG 205 / ADVANCEMIG 255 Congratulations on the purchase of your new Stata Welding Product! The Strata range of Welding Products from Euroquip utilises the latest design technology and is engineered to produce welding products that combine market leading value, features and durability.
-
Page 4: Specifications
Strata Professional MT250-40ER MIG Torch 4m MMA lead with heavy duty twist lock electrode holder 3m Earth Lead with heavy duty earth clamp Strata 2 Stage Flowmeter Argon Gas Regulator Argon Regulator/CO2 Cylinder Adaptor 4m Gas Hose Gas Inlet Quick Connector Gas Hose Clamp x2 Wire Drive Roller 0.6/0.8mm ‘v’... -
Page 5: Getting To Know Your Machine
EZIMIG 205 / ADVANCEMIG 255 Getting to Know Your Machine Welding Machine MIG torch Euro Connection Positive (+) Welding Power Output Connection Socket Mig Torch Power Connection Remote Connection Plug TIG Gas Outlet Connector Negative (-) Welding Power Output Connection Socket... - Page 6 EZIMIG 205 / ADVANCEMIG 255 40 39 27 28 29 23 24 30 31 32 Control Panel 31. Parameter (Current) Selection Light 17. Programme Selection Button 32. Parameter (Job) Selection Light 18. Secondary Function 33. Fast Wire Feed Button 19. MIG Mode Light 34.
-
Page 7: Mma Welding
EZIMIG 205 / ADVANCEMIG 255 MMA Welding should be paid to the polarity. Refer to the electrode Manual Metal Arc (MMA) welding is the most flexible, and manufacturers’ information for the correct polarity. one of the most widely used welding processes. It involves... -
Page 8: Mig Welding
EZIMIG 205 / ADVANCEMIG 255 MIG Welding 6. Push the wire through the first wire guide tube, over the first drive roller, through the middle wire guide Metal Inert Gas (MIG) welding refers to a welding process tube, over the second drive roller and into the last wire that uses the heat generated by an electric arc to fuse the guide tube. -
Page 9: Ezimig 205 Synergic Mig Program Chart
EZIMIG 205 / ADVANCEMIG 255 7.1040.103 EZIMIG 205 Synergic MIG Program Chart SYN Parmeter Solid Fe 98%Ar+2% AL Mg Cu si 7.1040.073 ADVANCEMIG 255 Synergic MIG Program Chart SYN Parmeter Solid Fe 材质为不干胶，表面覆膜 Solid Fe 98%Ar+2% AL Mg Cu si... - Page 10 EZIMIG 205 / ADVANCEMIG 255 Programme Selection Screen Press the Programme selection button to enter the programme selection screen. Rotate the RH knob to select the desired programme relevant to (Welded material, wire type, shielding gas and wire diameter). The previous chart listing the synergic programmes can be found located inside the wire drive door.
-
Page 11: Mig Welding Manual Selection
EZIMIG 205 / ADVANCEMIG 255 17.5 6.6 MIG Welding Manual Selection Additional Mig weld parameters can be accessed and set using the Function button. www.strata.co.nz... - Page 12 EZIMIG 205 / ADVANCEMIG 255 Pre-Gas Time: Gap: (0.1-5.0) The time in seconds of no Weld Arc (0-2S) Time in seconds that gas is released after before the next Weld Arc begins when the trigger the torch has been triggered but before the arc is held and spot mode is selected.
-
Page 13: Save And Recall User Set Welding Parameters
Welding Parameters 7. Select Programme Zero for manual mode MIG The Strata EZIMIG 205 and ADVANCEMIG 255 have the operation ability to save and recall 20 different user chosen settings. Within each function, a setting can be saved and then later 8. -
Page 14: Lift Tig Setup And Operation
3m push the clamp to workpiece connection is with clean torch when welding aluminium. The Strata EziMig205 and bare metal, without corrosion, paint or scale at the ADVANCEMIG 255 are spool gun capable. -
Page 15: Care & Maintenance
EZIMIG 205 / ADVANCEMIG 255 Care & Maintenance 1. Connect the earth cable quick connector to the negative welding power output socket. Keep your Welding Machine in Top Condition 2. Connect the earth clamp to the work piece ensuring The ADVANCEMIG 250 does not require any special... -
Page 16: Storing The Welder
EZIMIG 205 / ADVANCEMIG 255 Keep your Welding Machine in Top Condition • Check for damaged parts. Do not use the welder with damaged parts. The EZIMIG205 and ADVANCEMIG 255 do not require any special maintenance, however the user should •... -
Page 17: Safety
EZIMIG 205 / ADVANCEMIG 255 Safety 6. Protect yourself from electric shock. Do not use the welder outdoors. Insulate yourself from the work Store and Retain this Manual piece and the ground. Use non-flammable, dry insulating material if possible, or use dry rubber mats, dry wood or... - Page 18 EZIMIG 205 / ADVANCEMIG 255 Welding Safety Instructions & Warnings trash, and other debris. Do not use equipment in ar- eas near flammable chemicals, dust, and vapours. WARNING! Do not use this product in a damp or wet location. Protect yourself and others from possible serious injury or death.
- Page 19 EZIMIG 205 / ADVANCEMIG 255 metal parts touching the welding wire are electrically live. When possible, move the work to a location well Incorrectly installed or improperly grounded equipment is away from combustible materials. If relocation is not a hazard.
- Page 20 EZIMIG 205 / ADVANCEMIG 255 Fumes And Gases WARNING! Read the Safety Data Sheets (SDS) and the manufac- Welding produces fumes and gases. Breathing turer’s instruction for the metals, consumables, coat- these fumes and gases can be hazardous to your ings, and cleaners.
- Page 21 EZIMIG 205 / ADVANCEMIG 255 Cylinders Do not weld on coated metals, such as galvanized, lead, or cadmium plated steel, unless the coating is WARNING! removed from the weld area, the area is well venti- Gas cylinders contain gas under high pressure. If lated, and if necessary, while wearing an air- supplied damaged, a cylinder can explode.
-
Page 22: Notes
EZIMIG 205 / ADVANCEMIG 255 Notes www.strata.co.nz... -
Page 23: Warranty
EZIMIG 205 / ADVANCEMIG 255 Warranty As part of an on-going commitment to excellence in prod- Warranty does not cover pre delivery service and adjust- uct support, Euroquip offers a comprehensive product ment, or failure that may occur as a result of lack of/ incor- warranty program. - Page 24 Congratulations on your new STRATA product. We are proud to have you as our customer and will strive to provide you with the best service and reliability in the industry. This product is backed by our extensive warranty and world-wide service network. To locate your nearest distributor or service agency visit www.
