Strata ADVANCEMIG400C Operating Instructions Manual

Mig/arc/lift tig
Hide thumbs

Advertisement

Quick Links

Download this manual
ADVANCEMIG400C
MIG/ARC/Lift TIG
OPERATING INSTRUCTIONS
IMPORTANT!
Read these Operating Instructions Completely before attempting to use this machine. Save this manual and keep
it handy for quick reference. Pay particular attention to the safety instructions we have provided for your
protection. Contact your distributor if you do not fully understand anything in this manual.
www.strata.co.nz

Advertisement

loading
Need help?

Need help?

Do you have a question about the ADVANCEMIG400C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Strata ADVANCEMIG400C

Summary of Contents for Strata ADVANCEMIG400C

  • Page 1 ADVANCEMIG400C MIG/ARC/Lift TIG OPERATING INSTRUCTIONS IMPORTANT! Read these Operating Instructions Completely before attempting to use this machine. Save this manual and keep it handy for quick reference. Pay particular attention to the safety instructions we have provided for your protection. Contact your distributor if you do not fully understand anything in this manual.

  • Page 2: Table Of Contents

    ADVANCEMIG400C CONTENTS Know your Machine................5 Quick Start Guide ..................9 Basic Operation ..................9 Care & Maintenance................12 Safety......................13 Warranty...................... 18 www.strata.co.nz...
  • Page 3 400A ADVANCEMIG400C 400A 400V Max Ouput (MIG) Max Electrode Size THREE-PHASE 400A Three-Phase Compact Synergic MIG/ARC/Lift TIG Inverter Welder Powerful 400A high duty cycle output in a compact size - Ideal for heavy duty site work Can be used as compact unit, or with separate wirefeeder - Ultimate flexibility for every job...
  • Page 4 MIG Inverter Welder Accessories & consumables Standard Optional Common Consumables Welding Magnets ACCESSORY: ADVANCEMIG400C 3” Welding Magnet WT-WMG03 Arc Leads WT-WMG05 5” Welding Magnet 17479 Earth Leads Chipping Hammer 17478 Heavy duty chipping hammer for the trade MT360-4E MIG Torch...

  • Page 5: Know Your Machine

    ADVANCEMIG400C Know your Machine 1. Remote control 9 pin connection socket 2. MIG Torch Power Connection Lead 3. TIG Torch Gas Connector 4. Negative (-) welding power output connection socket 5. Positive (+) welding power output connection socket 6. MIG Torch Euro Connection Socket...
  • Page 6 ADVANCEMIG400C 23 24 25 19 20a 20b 20c 20 21 7. Welding Mode Control Selector Button 14. LH Control Knob – Turn to adjust, depress to a. MIG Synergic Mode* change to next parameter. Controls parameter b. MIG Manual Mode* displayed on the RH display (15) c.
  • Page 7 To reset the voltage for machine damage, in which case please contact Strata a synergic program back to factory default, change customer service.
  • Page 8 ADVANCEMIG400C dSL- Downslope - TIG mode only (7d) - When the 23 Secondary function control access - Accesses trigger is released, the welding current will reduce additional control features available in various gradually over the time selected down to 0. This allows welding modes, as listed below.

  • Page 9: Quick Start Guide

    With the heavy duty 4 roll geared wire feeder, the AdvanceMig400c will have a more steady 1.2 Set the spool brake tension by adjusting the and consistent wire feed when ‘push’ feeding soft wire,...
  • Page 10 ADVANCEMIG400C 1.7 Adjusting wire feed tension: this is accomplished 1.13 Connect the MIG power connection lead to the by turning the knob on the tension adjustment positive output socket (5). Without this step there lever. Clockwise will increase tension, will be no welding power connection to the torch! anti-clockwise will decrease drive tension.
  • Page 11 You are now ready to weld! 4.3 Connect the machine to suitable mains power Note - The AdvanceMig400C has TIG remote current using the mains input power lead. Switch the control function when fitted with a suitable torch with mains power switch to ‘on’...

  • Page 12: Care & Maintenance

    Use only in Top Condition genuine replacement parts. Do not use modified or non-genuine parts. The ADVANCEMIG400C does not require any special maintenance, however the user should take care of the machine as follows: Storing the Welder When not in use the welder should be stored in the •...

  • Page 13: Safety

    ADVANCEMIG400C Safety 6. Protect yourself from electric shock. Do not use the welder outdoors. Insulate yourself from the work piece and the ground. Use non-flammable, dry insulating material if possible, or use dry rubber mats, dry wood or Store and Retain this Manual...
  • Page 14 ADVANCEMIG400C Welding Safety Instructions & Warnings trash, and other debris. Do not use equipment in ar - eas near flammable chemicals, dust, and vapours. WARNING! Do not use this product in a damp or wet location. Protect yourself and others from possible serious injury or death.
  • Page 15 ADVANCEMIG400C When possible, move the work to a location well wire welding, the wire, wire reel, drive roll housing, and all away from combustible materials. If relocation is not metal parts touching the welding wire are electrically live. possible, protect the combustibles with a cover made Incorrectly installed or improperly grounded equipment is of fire resistant material.
  • Page 16 ADVANCEMIG400C Personal Safety CAUTION! Keep the work area well lit. Make sure there is adequate space surrounding the work area. Al- ways keep the work area free of obstructions, grease, oil, trash, and other debris. Do not use equipment in areas near flammable chemicals, dust, and vapours.
  • Page 17 ADVANCEMIG400C Cylinders Do not weld on coated metals, such as galva nized, lead, or cadmium plated steel, unless the coating is WARNING! removed from the weld area, the area is well venti- Gas cylinders contain gas under high pressure. If lated, and if necessary, while wearing an air- supplied damaged, a cylinder can explode.

  • Page 18: Warranty

    Registered warranty period for the AdvanceMig400C: Warranty does not cover any incidental, indirect or conse - quential loss, damage or expense that may result from any Commercial Use: 48 Months defect, failure or malfunction of a product.
  • Page 19 ADVANCEMIG400C www.strata.co.nz...
  • Page 20 Congratulations on your new STRATA product. We are proud to have you as our customer and will strive to provide you with the best service and reliability in the industry. This product is backed by our extensive warranty. To locate your nearest distributor or service agency visit www.strata.co.nz, or email us at...
