Leviton GreenMAX DRC TS004-E Installation Instructions

Ratings: Input Voltage/Frequency: +12-24V DC Input Current: 200mA at 12V DC, 120mA at 24V DC
WARNINGS:
• TO AVOID FIRE, SHOCK OR DEATH: TURN OFF POWER AT CIRCUIT BREAKER OR
FUSE AND TEST THAT THE POWER IS OFF BEFORE WIRING!
• To be installed and/or used in accordance with electrical codes and regulations.
• For indoor applications only.
• If you are not sure about any part of these instructions, consult an electrician.
Product Description
Leviton's 4 in. Single Gang Touch Screen is an integral component as part of a DRC (Distributed Room Control System). It's used to place one or more multi-button keypads with the
flexibility of push-button style control, on-the-fly labeling and additional user interface components like sliders, scene control, group control, and bi-directional communication with your
lighting control system.
Before Installation
• Requires a standard 1-gang device backbox or low-voltage mounting ring. No faceplate is required. Multi-gang installations with more than one touch screen in a common backbox, are
not supported.
• Requires Category 6A or better cabling.
• Maximum run length may be reduced based on wire gauge and total network load. To determine maximum run length and minimum wire gauge:
- Determine total network current by adding up the device load of each individual connected device on your network.
- Using the chart below, find the row corresponding to the next highest load from your maximum calculating in the step above, and, the column corresponding to your actual run length to
the longest 100 ft.
- Your maximum supported run length can be found in the Max Run column.
- The intersection of the row and column indicate the minimum power supply size required to successfully power your network. If your power supply is not large enough, source a larger
supply, or contact your Leviton representative to assist with a solution.
- Cat 6 wire gauge may be 24 AWG if the intersection of your row and column falls within the shaded conditions below, otherwise you must use 23 AWG.
NOTES:
• Leviton supplied patch cables are 24 AWG. If your system requires 23 AWG cabling, then all cables must be 23 AWG. Even a single 24 AWG, reduces the capacity of your system and
potentially cause it to malfunction.
• Source voltage for conditions listed below is 24V DC.
• Network runs greater than 1600 ft require repeaters. Contact your design team for details if needed.
Total Max Run 50 ft 100 ft
Device
Load
50mA 10,859 ft 60mA 60mA
100mA
5,429 ft 110mA 110mA
150mA 3,619 ft 160mA 160mA
200mA
2,714 ft 210mA 210mA
250mA 2,171 ft 260mA 260mA
300mA
1,809 ft 310mA 310mA
350mA 1,551 ft 360mA 370mA
400mA 1,357 ft 410mA 420mA
450mA 1,206 ft 460mA 470mA
500mA 1,085 ft 520mA 530mA
550mA 987 ft 570mA 580mA
600mA 904 ft 620mA 640mA
650mA 835 ft 680mA 700mA
700mA 775 ft 730mA 750mA
750mA 723 ft 780mA 810mA
800mA 678 ft 840mA 870mA
850mA
638 ft 890mA 930mA
900mA 603 ft 940mA 990mA
950mA
571 ft 1,000mA 1,050mA
1,000mA 542 ft 1,050mA 1,110mA
1,050mA
517 ft 1,110mA 1,170mA
1,100mA 493 ft 1,160mA 1,230mA
1,150mA
472 ft 1,220mA 1,290mA
1,200mA 452 ft 1,280mA 1,350mA
1,250mA
434 ft 1,330mA 1,420mA
1,300mA 417 ft 1,390mA 1,480mA
1,350mA
402 ft 1,440mA
1,400mA 387 ft 1,500mA
1,450mA
374 ft -
1,500mA 361 ft -
NOTE: Conditions in the above table that are indicated with "-", are not supported.
Single-Gang Touch Screen
INSTALLATION INSTRUCTIONS
Actual Run Length & Minimum Power Supply Sizing
200 ft 300 ft 400 ft
60mA 60mA 60mA
110mA 110mA 110mA
160mA 160mA 160mA
210mA 220mA 220mA
270mA 270mA 280mA
320mA 330mA 340mA
380mA 390mA 410mA
440mA 450mA 470mA
500mA 520mA 540mA
560mA 590mA 620mA
620mA 650mA 690mA
680mA 720mA 780mA
740mA 800mA 860mA
810mA 870mA 950mA
880mA 950mA 1,040mA
940mA 1,030mA 1,140mA
1,010mA 1,120mA 1,240mA
1,080mA 1,200mA 1,350mA
1,160mA 1,290mA 1,470mA
1,230mA 1,390mA -
1,310mA 1,480mA -
1,380mA - -
1,460mA - -
- - -
- - -
- - -
- - - -
- - - -
- - - -
- - - -
Cat. Nos. TS004-E, TS004-W
CAUTIONS:
• No user serviceable components. DO NOT attempt to service or repair.
• Use this device WITH COPPER OR COPPER-CLAD WIRE ONLY.
• SAVE THESE INSTRUCTIONS.
500 ft 600 ft 700 ft 800 ft
60mA 60mA 60mA 60mA
110mA 110mA 110mA 110mA
170mA 170mA 170mA 170mA
230mA 230mA 230mA 240mA
290mA 300mA 300mA 310mA
350mA 360mA 380mA 390mA
420mA 440mA 460mA 480mA
500mA 520mA 540mA 570mA
570mA 600mA 640mA 680mA
650mA 700mA 740mA 800mA
740mA 800mA 860mA 930mA
830mA 900mA 980mA 1,080mA 1,200mA
930mA 1,020mA 1,120mA 1,250mA
1,040mA 1,150mA 1,280mA -
1,150mA 1,290mA 1,460mA -
1,270mA 1,440mA - -
1,400mA - - -
- - - -
- - - -
- - - -
- - - -
- - - -
- - - -
- - - -
- - - -
- - - -
- - - -
- - - -
- - - -
- - - -
900 ft 1,000 ft 1,100 ft 1,200 ft 1,300 ft
60mA 60mA 60mA 60mA
110mA 120mA 120mA 120mA 120mA
180mA 180mA 180mA 180mA 190mA
240mA 250mA 260mA 260mA 270mA
320mA 330mA 340mA 350mA 360mA
400mA 420mA 440mA 450mA 470mA
500mA 520mA 550mA 580mA 610mA
600mA 640mA 680mA 720mA 770mA
720mA 770mA 830mA 900mA
860mA 930mA - -
1,020mA - - -
- - -
- - - -
- - - -
- - - -
- - - -
- - - -
- - - -
- - - -
- - - -
- - - -
- - - -
- - - -
- - - -
- - - -
- - - -
- - - -
- - - -
- - - -
- - - -
DI-000-TS004-02A-X2
ENGLISH
1,400 ft 1,500 ft 1,600 ft
60mA 60mA 60mA 60mA
120mA 120mA 120mA
190mA 190mA 200mA
270mA 280mA 290mA
370mA 390mA 400mA
490mA 520mA 540mA
640mA 680mA -
- - -
- - - -
- - - -
- - - -
- - - -
- - - -
- - - -
- - - -
- - - -
- - - -
- - - -
- - - -
- - - -
- - - -
- - - -
- - - -
- - - -
- - - -
- - - -
- - - -
- - - -
- - - -
- - - -
